Dell QLogic QLE2772L 32Gb Dual Port Fibre Channel (FC) SFP+ Host Bus Adapter (HBA) PCIe 4.0 x8 MA2810401-24 0NMDJF NMDJF

R$ 8.534,85

Dell QLogic QLE2772L 32Gb Dual Port Fibre Channel (FC) SFP+ HBA PCIe 4.0 x8 MA2810401-24 0NMDJF NMDJF

The Dell QLogic QLE2772L (0NMDJF / NMDJF) is a high-performance dual-port 32Gb Fibre Channel Host Bus Adapter (HBA) built on the Marvell QLogic 2770 series architecture. Designed for enterprise storage environments, it delivers ultra-fast throughput, low latency, and advanced NVMe over Fibre Channel support for modern data centers.


Related Part Numbers

QLE2772L-DEL, 0NMDJF, NMDJF, MA2810401-24


Core Technical Specifications

  • Ports: Dual-Port 32Gb Fibre Channel (SFP+)
  • Data Rate: 32Gbps per port (auto-negotiates to 16Gb / 8Gb)
  • Host Interface: PCIe Gen4 x8
  • Form Factor: Low-profile PCIe card
  • Dimensions: Approx. 6.6" x 2.73"

Performance

  • Throughput: Up to 25.6 Gbps full duplex
  • IOPS: Up to 4 million IOPS (aggregate)
  • Low Latency: Optimized for high-speed SAN environments

Key Features

  • NVMe over Fibre Channel (FC-NVMe):
    Supports both traditional FCP (SCSI) and NVMe, enabling seamless transition to next-gen storage
  • Port Isolation Architecture:
    Each port operates independently with its own CPU, DMA channels, and firmware to prevent cross-port failures
  • High Scalability:
    • Up to 2,048 concurrent logins per port
    • Up to 2,048 active exchanges per port
  • Marvell StorFusion™ Technology:
    Simplifies deployment, enhances diagnostics, and improves SAN performance
  • Energy Efficiency:
    Up to 3x better IOPS per watt compared to previous-generation HBAs

Compatibility

  • Designed for Dell PowerEdge servers and other enterprise systems with PCIe Gen4/Gen3 x8 slots
  • Compatible with Fibre Channel SAN environments
  • Supports major operating systems:
    • Windows Server
    • Linux (RHEL, SLES, Ubuntu)
    • VMware ESXi

Important Notes

  • Requires SFP+ Fibre Channel transceivers and fiber cables (sold separately)
  • Backward compatible with 16Gb and 8Gb FC infrastructure
  • Ensure SAN switch compatibility for full 32Gb performance

Summary

The Dell QLogic QLE2772L 32Gb FC HBA is an enterprise-grade solution for high-performance storage networking. With dual-port connectivity, PCIe Gen4 bandwidth, and support for both traditional Fibre Channel and NVMe, it is ideal for virtualization, cloud infrastructure, and mission-critical workloads requiring maximum speed and reliability.
