UCSC-PCIE-QD16GF - Refurbished - Qlogic QLE2692 Dual Port 16G Fibre Channel HBA

​The Cisco UCSC-PCIE-QD16GF is a dual-port 16Gb Fibre Channel Host Bus Adapter (HBA) based on the QLogic QLE2692 chipset, designed to deliver high-performance storage connectivity for Cisco UCS C-Series Rack Servers.​

Key Specifications:

• Chipset: QLogic QLE2692​

• Host Interface: PCI Express 3.0 x8​

• Ports: Two Fibre Channel ports​

• Data Transfer Rate: Up to 16 Gbps per port​

• Fiber Mode Supported: Multi-mode​

• Form Factor: Plug-in card​

• Dimensions:

  • Height: 2.7 inches​

  • Width: 6.6 inches​

Performance:

The adapter delivers up to 1.3 million IOPS, supporting over 650,000 I/O transactions per second per port, making it suitable for high-demand applications in virtualized and private cloud environments. ​

Advanced Features:

• Enhanced Gen 5 Fibre Channel Technology: Offers higher per-port performance with low power consumption.​

• QLogic StorFusion Technology: Provides streamlined provisioning, quality of service (QoS), and improved resiliency.​

• Virtualization Support: Supports standards-based virtualization features, including N_Port ID Virtualization (NPIV).​

Compatibility:

The UCSC-PCIE-QD16GF is compatible with various Cisco UCS C-Series Rack Servers, including:​

• UCS C220 M5​

• UCS C240 M5​

• UCS C460 M5​

Environmental Compliance:

• Environmentally Friendly: Yes​

• Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)

This HBA is designed to meet the demands of mission-critical enterprise applications, providing reliable and high-speed connectivity for storage area networks (SANs).
