The Ruijie RG-S6980-64QC is a high-performance, fixed-configuration 4 RU core switch designed for next-generation data centers.
It houses 64 × 400 GE QSFP-DD ports, delivering up to 51.2 Tbps of non-blocking switching capacity and 10 300 Mpps line-rate forwarding—ideal for AI/ML, high-performance computing, big-data, and distributed storage environments.
Leveraging PFC, ECN, and MMU-based buffer enhancements, the RG-S6980-64QC ensures lossless RDMA fabrics, while 2+2 hot-swappable power and 7+1 hot-swappable fan modules guarantee carrier-class reliability without service interruption
Overview
Highlights
-
High-Density Port Configuration: 64 × 400GE QSFP-DD ports in a 4RU chassis, supporting up to 51.2 Tbps switching capacity.
-
Advanced Architecture: Clos orthogonal design delivers non-blocking forwarding and high-speed transmission without packet loss.
-
Lossless Ethernet: Supports RDMA, PFC, and ECN technologies for zero packet loss and low-latency data transmission.
-
Robust Redundancy: 2+2 hot-swappable power modules and 7+1 hot-swappable fan modules ensure continuous operation and service reliability.
-
Telemetry-Based Monitoring: Real-time network monitoring with sub-second granularity for efficient management.
-
Comprehensive Protocol Support: Supports IPv4/IPv6 dual-stack, BGP, OSPF, IS-IS, RIP, and various tunneling technologies.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6980-64QC:
| Product Name | Category | Description |
| M2EFAN II-F | Fan Module |
High-efficiency fan module with intelligent speed adjustment for optimal cooling. |
| RG-PA3000I-F | Power Supply Module |
3000W AC/HVDC power supply module, supporting 2+2 redundancy for uninterrupted power. |
| 400GE ZR/ZR+ Optical Modules | Optical Transceivers |
Support long-distance interconnection up to 120 km, ideal for data center interconnect (DCI) scenarios. |
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6980-64QC | 64 × 400 GE QSFP-DD | 51.2 Tbps | 10 300 Mpps |
| RG-S6580-24DC8QC | 24 × 200 GE QSFP56 + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5 350 Mpps |
| RG-S6580-48CQ8QC | 48 × 100 GE DSFP + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5 350 Mpps |
| RG-S6510-48VS8CQ | 48 × 25 GE SFP28 + 8 × 100 GE QSFP28 | 4.0 Tbps | 2 000 Mpps |
| RG-S6250-48XS8CQ | 48 × 10 GE SFP+ + 8 × 100 GE QSFP28 | 4.8 Tbps | 2 000 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6980-64QC |
| Ports | 64 × 400GE QSFP-DD |
| Switching Capacity | 51.2 Tbps |
| Packet Forwarding Rate | 10,300 Mpps |
| Buffer Capacity | 113.66 MB |
| VLANs | 4,094 |
| Routing Entries | IPv4: 1,000K; IPv6: 640K |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Power Module Slots | 4 |
| Fan Module Slots | 8 |
| Dimensions (W × D × H) | 442 mm × 735 mm × 173.6 mm (17.40 in. × 28.94 in. × 6.83 in., 4 RU) |
| Weight | Approximately 48 kg (including fan and power modules) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Altitude | Operating: up to 5,000 m (16,404 ft.) |
| MTBF | ≥ 200,000 hours |
