- Ruijie RG-S6910-3C High-Density 100GE/400GE Modular Core Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The RG-S6910-3C is a next-generation, high-performance modular core switch in a 4 RU chassis that delivers 96 × 100 GbE ports or 24 × 400 GbE ports with 16 GB of buffer capacity—ideal for small to large data center gateways and DCI applications.
Designed for mission-critical environments, it supports 2 + 2 hot-swappable power redundancy and 5 + 1 hot-swappable fan redundancy, with per-module fault detection and automatic thermal control to ensure uninterrupted operation
Overview
Highlights
-
High-Density Port Configuration: Supports up to 96 × 100GE or 24 × 400GE ports, providing flexibility for diverse networking requirements.
-
Advanced Architecture: Employs a Clos orthogonal design, delivering non-blocking forwarding and high-speed transmission without packet loss.
-
Lossless Ethernet: Supports RDMA, PFC, and ECN technologies for zero packet loss and low-latency data transmission.
-
Robust Redundancy: Features 2+2 hot-swappable power modules and 5+1 hot-swappable fan modules, ensuring continuous operation and service reliability.
-
Telemetry-Based Monitoring: Provides real-time network monitoring with sub-second granularity, enhancing management efficiency.
-
Comprehensive Protocol Support: Supports IPv4/IPv6 dual-stack, BGP, OSPF, IS-IS, RIP, and various tunneling technologies.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6910-3C:
| Product Model | Category | Description |
| M6900-32CQ | Line Card Module |
Provides 32 × 100GE QSFP28 ports, supporting high-density 100GE connectivity. |
| RG-PA1200I-F | Power Supply Module |
1200W AC/HVDC power supply module, supporting 2+2 redundancy and hot-swapping. |
| M2EFAN I-F | Fan Module |
High-efficiency fan module with 5+1 redundancy and intelligent speed adjustment. |
| 100G-QSFP-SR-MM850 | Optical Transceiver |
100G SR module, QSFP28 form factor, MPO connector, 850 nm, 100 m over OM4 MMF. |
| 100G-QSFP-iLR4-SM1310 | Optical Transceiver |
100G iLR4 module, QSFP28 form factor, LC connector, 1310 nm, 2 km over SMF. |
| 100G-QSFP-LR4-SM1310 | Optical Transceiver |
100G LR4 module, QSFP28 form factor, LC connector, 1310 nm, 10 km over SMF. |
Comparison with Similar Models
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6910-3C | 96 × 100 GbE or 24 × 400 GbE | 19.2 Tbps | 4000 Mpps |
| RG-S6930-2C | 144 × 100 GbE or 72 × 200 GbE | 28.8 Tbps | 5400 Mpps |
| RG-S6920-4C | 128 × 100 GbE or (64 × 100 GbE + 16 × 400 GbE) | 25.6 Tbps | 8000 Mpps |
| RG-S6980-64QC | 64 × 400 GbE | 51.2 Tbps | 10300 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6910-3C |
| Service Slots | 3 |
| Switching Capacity | 19.2 Tbps |
| Packet Forwarding Rate | 4,000 Mpps |
| Port Configurations | Up to 96 × 100GE or 24 × 400GE ports |
| Power Module Slots | 4 (supporting 2+2 redundancy) |
| Fan Module Slots | 6 (supporting 5+1 redundancy) |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Dimensions (W × D × H) | 442 mm × 735 mm × 173.6 mm (17.40 in. × 28.94 in. × 6.83 in., 4 RU) |
| Weight | Approximately 42 kg (including all modules) |
| Power Supply | AC 100–240V or HVDC 192–288V |
| Maximum Power Consumption | Max: 2,100 W |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Storage Humidity | 5% to 95% RH (non-condensing) |
| Altitude | Operating: up to 5,000 m (16,404 ft.) |
| MTBF | ≥ 200,000 hours |
