Ruijie RG-S6580-48CQ8QC 16Tbps AI-Optimized Data Center Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Ruijie RG-S6580-48CQ8QC Data Center 100GE Fixed Access Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The RG-S6580-48CQ8QC is a Fixed Configuration Data Center Access Switch provided by Ruijie, specifically optimized for next-generation high performance network requirements. With 48 × 100GE DSFP ports and 8 × 400GE QSFP-DD ports, this switch provides high-density access for large-capacity servers, enabling efficient data transmission in high-bandwidth scenarios.
The RG-S6580-48CQ8QC has a switching capacity of 16.0 Tbps and a packet forwarding entry rate of 5350 Mpps, allowing it to integrate seamlessly into AI/machine learning, high-performance computing, and big data applications.
With 1+1 redundant power supply modules as well as 5+1 redundant fans, the switch is built to deliver reliable operations even in the event of hardware failures. The system also features hotswappable access units and control units for service without interruption.
Lossless Ethernet supports technologies like Priority Flow Control (PFC) and Explicit Congestion Notification (ECN) to ensure lossless packets for RDMA end-to-end communication. That guarantees zero packet loss and low latency which are crucial requirements for high-performance applications.
Moreover, the switch includes telemetry network monitoring, enabling near real-time, sub-second level monitoring to make network management faster and more accurate.
Overview
Highlights
- High-Density Ports: 48 × 100GE DSFP ports and 8 × 400GE QSFP-DD ports for flexible networking.
- High Switching Capacity: 16.0 Tbps switching capacity and 5350 Mpps packet forwarding rate.
- Redundant Design: 1+1 power supply and 5+1 fan module redundancy for uninterrupted services.
- Lossless Ethernet: Supports PFC and ECN for zero packet loss in RDMA communication.
- Telemetry Monitoring: Provides real-time, sub-second-level network monitoring.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6580-48CQ8QC:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial-grade switches. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
| Ruijie RG-PA1000I-P-F | Power Supply Units |
1000W AC power supply module, offering robust power support for large-scale deployments. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
|
MokerLink 1U Rack Mount Kit |
Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S6580-48CQ8QC, for easy and secure rack installation. |
Comparison with Similar Models
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6580-48CQ8QC | 48 × 100 GE DSFP + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5350 Mpps |
| RG-S6580-24DC8QC | 24 × 200 GE QSFP56 + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5350 Mpps |
| RG-S6510-48VS8CQ | 48 × 25 GE SFP28 + 8 × 100 GE QSFP28 | 4.0 Tbps | 2000 Mpps |
| RG-S6520-64CQ | 64 × 100 GE QSFP28 | 12.8 Tbps | 4482 Mpps |
| RG-S6980-64QC | 64 × 400 GE QSFP-DD | 51.2 Tbps | 10300 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6580-48CQ8QC |
| Port Configuration | 48 × 100GE DSFP, 8 × 400GE QSFP-DD |
| Switching Capacity | 16.0 Tbps |
| Packet Forwarding Rate | 5350 Mpps |
| MAC Address Table | 256,000 entries |
| ARP Table Size | 8,000 entries |
| IPv4 Unicast Routes | 64,000 |
| IPv6 Unicast Routes | 32,000 |
| Access Control Entries | Ingress: 5,000; Egress: 2,500 |
| Operating Temperature | 0ºC to 40ºC (32ºF to 104ºF) |
| Storage Temperature | –40°C to +70°C (–40ºF to +158ºF) |
| Power Supply | 1+1 redundant, hot-swappable |
| Fan Modules | 5+1 redundant, hot-swappable |
| Dimensions (W × D × H) | 442 mm × 700 mm × 44 mm |
| Weight | 16.2 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.
Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.
Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.
Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.
Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.
Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.
Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.
