- Ruijie RG-S6580-24DC8QC Next-Generation Data Center 200GE Fixed Access Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The Ruijie RG-S6580-24DC8QC is a 1 RU, high-density, high-performance data center access switch engineered for next-generation AI, machine learning, and big-data environments.
It packs 24 × 200 GE QSFP56 ports alongside 8 × 400 GE QSFP-DD uplinks, delivering massive bandwidth in a compact form factor. Designed for spine-leaf architectures, it seamlessly interoperates with the RG-S6980-64QC to support scalable, high-throughput networks.
The switch excels in lossless, low-latency fabrics by leveraging priority-based flow control (PFC), explicit congestion notification (ECN), and advanced memory management unit (MMU) technologies—ideal for RDMA-based applications.
Carrier-class reliability is ensured through 1+1 hot-swappable power redundancy and 5+1 hot-swappable fan redundancy, with on-the-fly fault detection and automatic fan-speed adjustment.
Overview
Highlights
- High-Density Connectivity: Offers 24 × 200GE QSFP56 ports and 8 × 400GE QSFP-DD uplink ports, supporting flexible deployment scenarios.
- Fantastic Performance: Switching capacity of up to 16.0 Tbps and a packet forwarding rate of up to 5350 Mpps
- Lossless Ethernet Support: Combines RDMA, PFC, and ECN technologies for zero packet loss and ultra-low latency for the fastest network speeds.
- 5+1 fans redundancy with 1+1 hot swapping power supplies.
- Expansion Capabilities: Easily integrates with other systems, allowing for seamless expansion as business needs grow.
- Long-Dist Matrix InterConnectivity: 400GE ZR/ZR+ optical module compatibility, interconnection up to 120 km
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6580-24DC8QC:
| Product Name | Category | Description |
| RG-PA1200I-F | Power Supply Module |
1200W AC/HVDC power supply module, supporting 1+1 redundancy for uninterrupted power. |
| M1HFAN II-F | Fan Module |
High-efficiency fan module with front-to-rear airflow, supporting 5+1 redundancy. |
| 400G-QDD-SR8-MM850 | Optical Transceiver |
400G SR8 module, QSFP-DD form factor, MPO-16 APC, 850 nm, up to 100 m over MMF. |
| 400G-QDD-DR4-SM1310 | Optical Transceiver |
400G DR4 module, QSFP-DD form factor, MPO-12 APC, 1310 nm, up to 500 m over SMF. |
| 400G-QDD-FR4-SM1310 | Optical Transceiver |
400G FR4 module, QSFP-DD form factor, Duplex LC, 1310 nm, up to 2 km over SMF. |
| 100G-QSFP-SR-MM850 | Optical Transceiver |
100G SR module, QSFP28 form factor, MPO, 850 nm, up to 100 m over MMF. |
| 100G-QSFP-LR4-SM1310 | Optical Transceiver |
100G LR4 module, QSFP28 form factor, Duplex LC, 1310 nm, up to 10 km over SMF. |
Comparison with Similar Models
| Model | Port Configuration | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6580-24DC8QC | 24 × 200 GE QSFP56 + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5350 Mpps |
| RG-S6580-48CQ8QC | 48 × 100 GE DSFP + 8 × 400 GE QSFP-DD | 16.0 Tbps | 5350 Mpps |
| RG-S6510-48VS8CQ | 48 × 25 GE SFP28 + 8 × 100 GE QSFP28 | 4.0 Tbps | 2000 Mpps |
| RG-S6250-48XS8CQ | 48 × 10 GE SFP+ + 8 × 100 GE QSFP28 | 2.56 Tbps | 1920 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6580-24DC8QC |
| Port Configuration | 24 × 200GE QSFP56, 8 × 400GE QSFP-DD |
| Switching Capacity | 16.0 Tbps |
| Packet Forwarding Rate | 5350 Mpps |
| MAC Address Table | 256,000 entries |
| ARP Table Size | 8,000 entries |
| IPv4 Unicast Routes | 64,000 |
| IPv6 Unicast Routes | 32,000 |
| Access Control Entries | Ingress: 5,000; Egress: 2,500 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | –40°C to +70°C (–40°F to 158°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Power Supply | 1+1 redundant, hot-swappable |
| Fan Modules | 5+1 redundant, hot-swappable |
| Dimensions (W × D × H) | 442 mm × 670.8 mm × 43.6 mm |
| Weight | 11 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
