Ruijie RG-S6110-48MG4VS2QXS-UP 48×Multi-GE PoE++, 4×25G+2×40G
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Ruijie 1RU 48×100/1000/2.5G/5GBASE-T + 4×10/25 GE SFP28 + 2×40 GE QSFP+ PoE++ Multi-GE Access Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Ruijie RG-S6110-48MG4VS2QXS-UP is a next-gen high-performance Multi-GE access switch readily equipped with high-bandwidth solution for utilization of LAN network requirements for course to meet these demands.
Providing advanced connectivity with optimize 48 × 100M/1G/2.5G/5GBASE-T ports, 4 × 10G/25G SFP28 uplink ports, and 2 × 40G QSFP+ uplink ports.
As a network switch, it is equipped with all advanced features including Virtual Switch Unit (VSU) virtualization technology, rich Layer 3 routing protocols and security policies, which is suitable for high-density access scenarios. High bandwidth and high PoE++ power support.
Overview
Highlights
-
High-Density Multi-GE Ports: Provides 48 × 100M/1G/2.5G/5GBASE-T ports, supporting flexible deployment options for various access requirements.
-
VSU Virtualization: Supports Virtual Switch Unit (VSU) technology, allowing multiple physical switches to operate as a single logical unit, simplifying network management and enhancing reliability.
-
Advanced Layer 3 Routing: Offers comprehensive Layer 3 routing protocols, including static routing, RIP, OSPF, IS-IS, and BGP, supporting both IPv4 and IPv6 networks.
-
Robust Security Features: Incorporates multiple security mechanisms such as ACLs, DHCP Snooping, ARP inspection, and support for SSH and SNMPv3 for secure management.
-
High Reliability: Features hot-swappable power and fan modules with redundancy, ensuring continuous operation and service reliability.
-
Efficient Management: Supports various management methods, including CLI, web-based management, Telnet, and integration with Ruijie’s INC for simplified operations and maintenance.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S6110-48MG4VS2QXS-UP:
| Product Model | Category | Description |
| RG-PA600I-P-F | Power Supply Module |
600W AC power supply module, supporting hot-swapping and redundancy. |
| RG-PA1000I-P-F | Power Supply Module |
1000W AC power supply module, supporting hot-swapping and redundancy. |
| M2SFAN I-F | Fan Module |
High-efficiency fan module with intelligent speed adjustment and fault alarms. |
| 25G-SFP28-SR | Optical Transceiver |
25GE SR module, SFP28 form factor, LC connector, 850 nm, up to 100 m over OM4 MMF. |
| 25G-SFP28-LR | Optical Transceiver |
25GE LR module, SFP28 form factor, LC connector, 1310 nm, up to 10 km over SMF. |
| 40G-QSFP-SR4 | Optical Transceiver |
40GE SR4 module, QSFP+ form factor, MPO connector, 850 nm, up to 100 m over OM4 MMF. |
| 40G-QSFP-LR4 | Optical Transceiver |
40GE LR4 module, QSFP+ form factor, LC connector, 1310 nm, up to 10 km over SMF. |
Comparison with Similar Models
| Model | Access / Uplink Ports | Switching Capacity | Packet Forwarding Rate |
|---|---|---|---|
| RG-S6110-48MG4VS2QXS-UP | 48×100/1 000/2.5 G/5 G + 4×10/25 GE + 2×40 GE | 1 008 Gbps | 750 Mpps |
| RG-S6110-24MG4VS-UP | 24×100/1 000/2.5 G/5 G + 4×10/25 GE | 2.56 Tbps | 360 Mpps |
| RG-S6120-48XMG4VS2QXS-UP-H | 48×10/5/2.5/1 G + 4×25 GE + 2×40 GE | 1.32 Tbps | 982 Mpps |
Specifications
| Parameter | Specification |
| Model | RG-S6110-48MG4VS2QXS-UP |
| Service Ports | 48 × 100M/1G/2.5G/5GBASE-T (Ports 1–24 support PoE/PoE+/PoE++, Ports 25–48 support PoE/PoE+) |
| Uplink Ports | 4 × 10G/25G SFP28, 2 × 40G QSFP+ |
| Switching Capacity | 840 Gbps |
| Packet Forwarding Rate | 625 Mpps |
| MAC Address Table | 32,768 entries |
| ARP Table Size | 16,000 entries |
| IPv4 Unicast Routes | 16,000 entries |
| IPv6 Unicast Routes | 16,000 entries |
| IPv4 Multicast Routes | 4,000 entries |
| IPv6 Multicast Routes | 2,000 entries |
| IGMP Groups | 4,000 |
| ND Table Size | 4,000 entries |
| Power Module Slots | 2 (supporting 1+1 redundancy) |
| Fan Module Slots | 3 (supporting intelligent speed adjustment and fault alarms) |
| Management Ports | 1 × Management, 1 × Console, 1 × USB 2.0 |
| Dimensions (W × D × H) | 442 mm × 420 mm × 43.6 mm (17.40 in. × 16.54 in. × 1.72 in., 1 RU) |
| Weight | Approximately 6.11 kg (including all modules) |
| Power Supply | AC 100–240V, HVDC 192–290V |
| Maximum Power Consumption | < 600 W |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| MTBF | ≥ 200,000 hours |
