- Ruijie RG-S5350-48GT4SFP-P-E 48-Port GE Layer 3 Managed PoE+ Switch, 4×1 GE SFP Uplinks
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The RG-S5350-48GT4SFP-P-E from Ruijie’s S5350-E Essentials series is engineered for high-density campus-edge and enterprise LANs. It features 48 auto-negotiating 10/100/1000 BASE-T downlinks with IEEE 802.3af/at PoE+ (up to 30 W per port) and four fixed 1 GE SFP uplinks for fiber aggregation.
Powered by a dual-core 1.0 GHz CPU, 1 GB DDR4 memory, 512 MB flash, 16 MB BootROM, and a 4 MB packet buffer, it delivers 211 Gbps non-blocking switching capacity and 158 Mpps forwarding rate.
Housed in a fanless 1 RU, IP 40 chassis with a fixed 460 W AC power supply (100–240 VAC, 6 A), it supports VSU virtualization for sub-50 ms failover, IEEE 802.3az Energy-Efficient Ethernet, hardware CPU Protection Policy (CPP), Network Foundation Protection Policy (NFPP), and zero-touch O&M via Ruijie INC or Cloud.
Overview
Highlights
- Powerful Switching Performance: The RG-S5350-48GT4SFP-P-E boasts a switching capacity of 211 Gbps and a forwarding throughput of 158Mpps, enabling it to effectively manage high traffic loads and providing smooth and uninterrupted network performance.
- PoE+ Support: Ports 1 to 48 support IEEE 802.3af/at PoE/PoE+, with a maximum power supply of 30 W per port to supply power to terminals, such as VoIP phones, wireless access points, and IP cameras.
- 48*1 G ports and 4 SFP uplink ports: Provides you with plenty of outputs so you can build your network how you want to.
- Robust Protection: With support for IEEE 802.1X, IP Source Guard, and Dynamic ARP Inspection, the RG-S5350-48GT4SFP-P-E provides advanced security measures to keep your network safe from unauthorized users and potential security breaches.
- All-in-one Management: SNMP, Web, and CLI – this switch is supported via multiple management interfaces, enabling network administrators to configure, monitors, and maintain all from a single switch.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5350-48GT4SFP-P-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial switches like the RG-S5350-48GT4SFP-P-E. |
| Ruijie RG-PD150IB-F | Power Supply Units |
150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5350-48GT4SFP-P-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | Capacity / Forwarding | PoE+ Budget | VSU Members |
|---|---|---|---|---|
| RG-S5350-48GT4SFP-P-E | 48×GE PoE+ + 4×1 GE SFP | 211 Gbps / 158 Mpps | 405 W (max) | Up to 4 |
| RG-S5350-24GT4SFP-P-E | 24×GE PoE+ + 4×1 GE SFP | 67 Gbps / 50 Mpps | 720 W | Up to 4 |
| RG-S5350-48GT4SFP-E | 48×GE + 4×1 GE SFP | 211 Gbps / 158 Mpps | None | Up to 4 |
Specifications
| Parameter | Specification |
| Model | RG-S5350-48GT4SFP-P-E |
| Port Configuration | 48 x 10/100/1000BASE-T, 4 x 1GE SFP |
| PoE Support | Ports 1 to 48 support PoE/PoE+ (IEEE802.3af/at) power supply |
| Switching Capacity | 125 Gbps |
| Forwarding Rate | 158 Mpps |
| MAC Address Table | 16,000 entries |
| ARP Table Size | 4,000 |
| IPv4 Unicast Routes | 6,000 |
| IPv6 Unicast Routes | 2,000 |
| Access Control Entries | Ingress: 1,750; Egress: 800 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 52 W (without PoE load); 460 W (full PoE load) |
| Dimensions (W x D x H) | 442 mm x 220 mm x 43.6 mm |
| Weight | 4.0 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
