Ruijie RG-S5310-48SFP4XS-E 48×1G SFP & 4×10G SFP+ Layer 3 Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Ruijie RG-S5310-48SFP4XS-E 48-Port GE SFP Layer 3 Managed Access Switch, 4×1 GE/10 GE SFP+ Uplinks
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
High-performance Layer 3 Managed Access Switch for Enterprise and Campus Networks Ruijie RG-S5310-48SFP4XS-E It is equipped with 48 Gigabit SFP ports and 4 SFP+ uplink ports. In environments with heavy traffic load, it can effectively switch at 154 Gbps, or forward packets at the rate of 115 Mpps.
With an operating temperature of 0°C to 45°C, the RG-S5310-48SFP4XS-E is designed for harsh environments, meeting a variety of industrial and enterprise environments. This switch provides security-rich features such as CPU Protection Policy (CPP) and Network Foundation Protection Policy (NFPP).
It also provides extensive management capabilities with SNMP, Web, and CLI options for easy network setup and monitoring.
Overview
Highlights
- High Switching Capacity: The RG-S5310-48SFP4XS-E possesses a switching capacity of 154 Gbps and a forwarding rate of 115 Mpps, thus allowing it to process intensive data flows without causing performance lag.
- This SFP-based switch boasts 48 Gigabit SFP ports and 4 SFP+ uplink ports, providing flexibility for different network topologies and requirements.
- Advanced Security Features: With support for IEEE 802.1X authentication, IP Source Guard, and Dynamic ARP Inspection, the RG-S5310-48SFP4XS-E helps protect your network from unauthorized access and security threats.
- Extensive Management: This switch supports various management interfaces, such as SNMP, Web, and CLI, ensuring simple configuration, monitoring, and maintenance for network administrators.
- Redundant Power Supply:RG-S5310-48SFP4XS-E is equipped with hot-swappable dual power modules supporting 1+1 redundancy to ensure continuous operation in case of a power module failure.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5310-48SFP4XS-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units | 150W AC power supply module, suitable for industrial switches like the RG-S5310-48SFP4XS-E. |
| Ruijie RG-PD150IB-F | Power Supply Units | 150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units | 600W AC power supply module, providing higher power output for demanding applications. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits | Compatible with 19-inch switches, including the RG-S5310-48SFP4XS-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers | 10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | Capacity / Forwarding | Power-Redundancy |
|---|---|---|---|
| RG-S5310-48SFP4XS-E | 48× SFP + 4× SFP+ | 176 Gbps / 131 Mpps | 2× hot-swappable |
| RG-S5310-24SFP4XS-E | 24× SFP + 4× SFP+ | 154 Gbps / 115 Mpps | 2× hot-swappable |
| RG-S5310-48GT4XS-E | 48× RJ-45 + 4× SFP+ | 211 Gbps / 158 Mpps | 2× hot-swappable |
| Model | Downlinks | Uplinks | PoE | Capacity | Forwarding | Brand |
|---|---|---|---|---|---|---|
| Ruijie RG‑S5310‑24GT4XS‑E | 24 × 1 GbE | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24GT4XS‑E | 24 × 1 GbE | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Network‑Switch (OEM) |
| Ruijie RG‑S5310‑48GT4XS‑E | 48 × 1 GbE | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48GT4XS‑E | 48 × 1 GbE | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑24SFP4XS‑E | 24 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24SFP4XS‑E | 24 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑48SFP4XS‑E | 48 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48SFP4XS‑E | 48 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑24GT4XS‑P‑E | 24 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (740W) | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24GT4XS‑P‑E | 24 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (740W) | 208 Gbps | 155 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑48GT4XS‑P‑E | 48 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (1,480W) | 211 Gbps | 158 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48GT4XS‑P‑E | 48 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (1,480W) | 211 Gbps | 158 Mpps | Network‑Switch |
Specifications
| Parameter | Specification |
| Model | RG-S5310-48SFP4XS-E |
| Port Configuration | 48 x 1000BASE-X SFP, 4 x 1G/10G SFP+ |
| PoE Support | Not supported |
| Switching Capacity | 154 Gbps |
| Forwarding Rate | 115 Mpps |
| MAC Address Table | 32,000 entries |
| ARP Table Size | 4,000/16,000 (authorized) |
| ND Table Size | 2,000/8,000 (authorized) |
| IPv4 Unicast Routes | 8,000/12,000 (authorized) |
| IPv6 Unicast Routes | 4,000 |
| Access Control Entries | Ingress: 3,500; Egress: 1,500 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 85 W |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Weight | 4.2 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
