Ruijie RG-S5310-48GT4XS-P-E 48×1G PoE+ & 4×10G SFP+ Layer 3 Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Ruijie RG-S5310-48GT4XS-P-E 48-Port GE Layer 3 Managed PoE+ Switch, 4×10 GE SFP+ Uplinks
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The RG-S5310-48GT4XS-P-E from Ruijie’s S5310-E Essentials series is engineered for high-density, high-performance campus and enterprise LANs. It provides 48 auto-negotiating 10/100/1000 BASE-T ports with IEEE 802.3af/at PoE/PoE+ support and four fixed SFP+ slots for 1 GE or 10 GE uplinks.
Housed in a 1 RU, fanless, IP 40 chassis with two hot-swappable power-module slots, it delivers 211 Gbps of non-blocking switching capacity and a 158 Mpps forwarding rate.
It supports VSU virtualization for sub-50 ms failover, and integrates hardware CPU Protection Policy (CPP) and Network Foundation Protection Policy (NFPP) for enhanced control-plane stability—all manageable via CLI, SNMP, Web GUI, USB, or Ruijie INC/Cloud.
Overview
Highlights
- High Switching Capacity: With a switching capacity of 176 Gbps and a forwarding rate of 131 Mpps, the RG-S5310-48GT4XS-P-E provides high throughput to handle today's demanding network traffic.
- PoE+ Supported: Ports 1-48 Supports IEEE 802.3af/at PoE/PoE+ Power Supply, Up To 30 W Each Port, Which Is Sufficient To Meet The Power Supply Needs Of Terminals Such As VoIP Phones, Wireless Access Points, IP Cameras, Etc.
- Versatile Connectivity: With 48 Gigabit Ethernet ports and 4 SFP+ uplink ports, the RG-S5310-48GT4XS-P-E provides flexible connectivity options to support different network topologies and requirements.
- Use with: The RG-S5310-48GT4XS-P-E with advanced hardware security is capable of providing advanced protection against a wide range of attacks, including those against the wireless security protocol.
- Multi-Management Systems: The switch supports various management interfaces, such as SNMP, Web, and CLI, enabling straightforward configuration, monitoring, and types of maintenance.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5310-48GT4XS-P-E:
| Product Name | Category | Description |
| Ruijie RG-PA150IB-F | Power Supply Units |
150W AC power supply module, suitable for industrial switches like the RG-S5310-48GT4XS-P-E. |
| Ruijie RG-PD150IB-F | Power Supply Units |
150W DC power supply module, offering a compact solution for smaller setups. |
| Ruijie RG-PA600I-P-F | Power Supply Units |
600W AC power supply module, providing higher power output for demanding applications. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5310-48GT4XS-P-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
Comparison with Similar Models
| Model | Downlinks & Uplinks | PoE Budget | Capacity / Forwarding |
|---|---|---|---|
| RG-S5310-48GT4XS-P-E | 48×GE PoE/PoE+ + 4×10 GE SFP+ | 1 440 W | 211 Gbps / 158 Mpps |
| RG-S5310-24GT4XS-P-E | 24×GE PoE/PoE+ + 4×10 GE SFP+ | 740 W | 154 Gbps / 115 Mpps |
| RG-S5310-48GT4XS-E | 48×GE data-only + 4×10 GE SFP+ | None | 211 Gbps / 158 Mpps |
| Model | Downlinks | Uplinks | PoE | Capacity | Forwarding | Brand |
|---|---|---|---|---|---|---|
| Ruijie RG‑S5310‑24GT4XS‑E | 24 × 1 GbE | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24GT4XS‑E | 24 × 1 GbE | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Network‑Switch (OEM) |
| Ruijie RG‑S5310‑48GT4XS‑E | 48 × 1 GbE | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48GT4XS‑E | 48 × 1 GbE | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑24SFP4XS‑E | 24 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24SFP4XS‑E | 24 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 208 Gbps | 155 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑48SFP4XS‑E | 48 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48SFP4XS‑E | 48 × SFP (1 Gbps) | 4 × 10 Gbps SFP+ | No | 176 Gbps | 131 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑24GT4XS‑P‑E | 24 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (740W) | 208 Gbps | 155 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑24GT4XS‑P‑E | 24 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (740W) | 208 Gbps | 155 Mpps | Network‑Switch |
| Ruijie RG‑S5310‑48GT4XS‑P‑E | 48 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (1,480W) | 211 Gbps | 158 Mpps | Ruijie |
| Network‑Switch NS‑S5310‑48GT4XS‑P‑E | 48 × 1 GbE (PoE+) | 4 × 10 Gbps SFP+ | PoE+ (1,480W) | 211 Gbps | 158 Mpps | Network‑Switch |
Specifications
| Parameter | Specification |
| Model | RG-S5310-48GT4XS-P-E |
| Port Configuration | 48 x 10/100/1000BASE-T, 4 x 1G/10G SFP+ |
| PoE Support | Ports 1 to 48 support PoE/PoE+ (IEEE802.3af/at) power supply |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 131 Mpps |
| MAC Address Table | 32,000 entries |
| ARP Table Size | 4,000/16,000 (authorized) |
| ND Table Size | 2,000/8,000 (authorized) |
| IPv4 Unicast Routes | 8,000/12,000 (authorized) |
| IPv6 Unicast Routes | 4,000 |
| Access Control Entries | Ingress: 3,500; Egress: 1,500 |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to +70°C |
| Power Input | AC: 100V to 240V, 50/60Hz |
| Maximum Power Consumption | 55 W (without PoE load); 1570 W (full PoE load) |
| Dimensions (W x D x H) | 442 mm x 420 mm x 43.6 mm |
| Weight | 4.3 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by Ruijie RCNP Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Ruijie products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.
Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.
Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.
Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.
Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.
Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.
Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.
