- Ruijie RG-S5000-10GT2MS-E 10-Port Gigabit Layer 2+ Managed Switch with 2×2.5 GE Uplinks, Essentials
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The RG-S5000-10GT2MS-E is part of Ruijie’s Simplified Gigabit Switch (RG-S5000-E) series, designed for universities, hospitals, government, and enterprise campus deployments. It delivers 10 auto-negotiating 10/100/1000 BASE-T downlink ports and two 2.5 GE/1 GE SFP uplink ports, all in a fanless, IP40-rated chassis.
As an L2+ switch, it supports static routing and RIP, 10 kV port surge protection, Rapid Link Detection Protocol (RLDP), and Energy-Efficient Ethernet—ensuring high reliability, stability, and low noise operation.
Overview
Highlights
- The RG-S5000-10GT2MS-E supports high switching capacity, with a switching capacity of 36 Gbps and forwarding rate of 27 Mpps, making it suitable for use in high-traffic environments.
- Wide Temperature Range: With an operating range between 0°C to 45°C, the switch can be used in both industrial and enterprise environments.
- Features of RG-S5000-10GT2MS-E — A Powerful Network SwitchFlexible Connectivity: The RG-S5000-10GT2MS-E has 10 Gigabit Ethernet ports and 2 SFP+ uplink ports, providing flexible connectivity options for various network topologies and requirements.
- Robust Security Mechanisms: The RG-S5000-10GT2MS-E has features like IEEE 802.1X authentication, IP Source Guard, and Dynamic ARP Inspection to protect your network from hackers and malicious attacks.
- Supporting Multipoint Management: SNMP, Web, CLI multiple management interfaces provide easy configuration, monitoring, and maintenance for network administrators.
Recommended Accessories
Here are some compatible accessories to enhance the functionality of the Ruijie RG-S5000-10GT2MS-E:
| Product Name | Category | Description |
| Ruijie RG-PA240-48 | Power Supply Units |
240W DIN-Rail AC/DC power supply, suitable for industrial switches like the RG-S5000-10GT2MS-E. |
| Ruijie RG-PA120-48 | Power Supply Units |
120W DIN-Rail AC/DC power supply, offering a compact solution for smaller setups. |
| MokerLink 1U Rack Mount Kit | Rack Mount Kits |
Compatible with 19-inch switches, including the RG-S5000-10GT2MS-E, facilitating secure rack installation. |
| Ruijie XG-SFP-SR-MM850 | SFP Transceivers |
10G SFP+ transceiver with 850nm wavelength, suitable for short-range fiber connections. |
| Ruijie XG-SFP-LR-SM1310 | SFP Transceivers |
10G SFP+ transceiver with a 1310nm wavelength, designed for long-range single-mode fiber links. |
Comparison with Similar Models
| Model | Downlinks | Uplinks | PoE Support | Capacity |
|---|---|---|---|---|
| RG-S5000-10GT2MS-E | 10×1 GbE data-only | 2×1/2.5 GbE SFP | No | 30 Gbps / 22.5 Mpps |
| RG-S5000-10GT2MS-P-E | 10×1 GbE PoE+ (125 W) | 2×1/2.5 GbE SFP | Yes | 30 Gbps / 22.5 Mpps |
| RG-S5000-24GT4MS-E | 24×1 GbE data-only | 4×1/2.5 GbE SFP | No | 68 Gbps / 51 Mpps |
| RG-S5000-8GT4SFP | 8×1 GbE data-only | 4×1 GbE SFP | No | 24 Gbps / 41.7 Mpps |
| Model | Ports (Access / Uplink) | PoE Support | Capacity | Forward Rate | Key Features |
|---|---|---|---|---|---|
| Ruijie RG‑S5000‑10GT2MS‑E | 10 × 1 GbE, 2 × 2.5 GbE SFP | None | 36 Gbps | ~27 Mpps | L2+, RLDP, 10 kV protection |
| NS‑S5000‑10GT2MS‑E | Same | None | Same | Same | Same specs under your brand |
| Ruijie RG‑S5000‑10GT2MS‑P‑E | 10 × 1 GbE (8 PoE+), 2× SFP | PoE+ (125 W) | 36 Gbps | ~27 Mpps | L2+, PoE+, RLDP, surge protect |
| NS‑S5000‑10GT2MS‑P‑E | Same | Same | Same | Same | Brand equivalent PoE model |
| Ruijie RG‑S5000‑24GT4MS‑E | 24 × 1 GbE, 4 × 2.5 GbE SFP | None | ~68 Gbps | ~51 Mpps | High-density, fanless, L2+/RIP |
| NS‑S5000‑24GT4MS‑E | Same | None | Same | Same | Voice identical, brand-labeled |
| Ruijie RG‑S5000‑48GT4MS‑E | 48 × 1 GbE, 4 × 2.5 GbE SFP | None | ~139 Gbps | ~104 Mpps | Larger port count, high throughput |
| NS‑S5000‑48GT4MS‑E | Same | None | Same | Same | Equivalent 48‑port version |
| Ruijie RG‑S5000‑24GT4MS‑P‑E | 24 × 1 GbE PoE+, 4×2.5 GbE SFP | PoE+ (370 W) | ~68 Gbps | ~51 Mpps | High-power PoE, RLDP, L2+, surge protect |
| NS‑S5000‑24GT4MS‑P‑E | Same | Same | Same | Same | PoE budget high, under your label |
Specification
| Parameter | Specification |
| Model | RG-S5000-10GT2MS-E |
| Port Configuration | 10 x 10/100/1000BASE-T, 2 x SFP+ |
| PoE Support | Not supported |
| Switching Capacity | 36 Gbps |
| Forwarding Rate | 27 Mpps |
| MAC Address Table | 16,000 entries |
| ARP Table Size | 512 |
| ND Table Size | 256 |
| IPv4 Unicast Routes | 64 |
| IPv6 Unicast Routes | 64 |
| Access Control Entries | 500 |
| Operating Temperature | 0°C to 45°C |
| Power Input | 100V to 240V AC, 50/60Hz |
| Dimensions | 260 mm x 170 mm x 43.6 mm |
| Weight | Approx. 2.0 kg |
| Mounting | 19-inch rack mount |
| Ingress Protection | IP40 (Protection from solid objects larger than 1mm) |
| ESD Protection | Air discharge: 8 kV / Contact discharge: 6 kV |
| Surge Protection |
Service port: 10 kV / Power port: Common mode 6 kV, Differential mode 2 kV |
| Management |
Supports SNMP, Web, and CLI management, compatible with Ruijie Cloud management platform |
| MTBF | 200,000 hours |
