Capacities: 30.72 TB

Security: Non-Opal

Form Factor: U.2

PCIe Interface

PCIe Gen4x4

Dual Port: x2 lanes

PCIe AER: Advanced Error Reporting

128KB Sequential Read/Write (QD=32, Workers=1): 7000 MB/s / 6000 MB/s

4K Sustained Random Read/Write (QD=64, Workers=8): 1600K IOPS / 180K IOPS

4K Sustained Random Read/Write Latency (µs): 90/15 (QD=1, Workers=1); 100/200 (QD=32, Workers=1); 320/3150 (QD=64, Workers=8)

IOPS Consistency: 95%

4KB Sustained Random Read/Write QoS (99%) (µs): 100/12 (QD=1, Workers=1); 120/200 (QD=32, Workers=1); 600/3200 (QD=64, Workers=8)

Random Read Power (Typ): 18.5 W

Random Write Power (Typ): 20.6 W

Sequential Read Power (Typ): 13.7 W

Sequential Write Power (Typ): 20.1 W

Inrush Current: 1.5A

Idle Power (Typ): 8.16 W

DWPD: 1 DWPD

TBW: 56064 TB

LBAF: 512 / 512+8 / 4K / 4K+8 / 4K+64 Bytes

MTBF: 2,500,000 hours

UBER: < 1 sector per 10^18 bits read

ECC

Static and Dynamic Wear Leveling

Bad Block Management

Deallocate (TRIM) Command

SMART

Over-Provision

Firmware Upgrade

Operation Temperature: 0 °C - 70 °C with specified airflow

Storage Temperature: -40 °C - 85 °C

RoHS Compliant

Namespace

Dual Port

Reservation

Metadata Protection

Thermal Throttling

Power Loss Protection

Hardware AES-XTS 256-bit Encryption

Support SMBus

Support NVMe-MI (Management Interface)

Data Retention: 3 months

Compliance: PCIe Express Base 4.0

NVMe: 1.4

NVMe Management Interface: Rev 1.1
