Overview
The NSComm ST UPC to ST UPC Duplex Single Mode Fiber Patch Cable is a rugged OS2 interconnect solution designed for long-distance links in entrance facilities, telecommunications rooms, data centers, and industrial or legacy ST-based environments. Featuring ST UPC duplex connectors on both ends with bayonet-style coupling, this cable provides secure, quick-connect terminations ideal for applications where frequent mating and robust mechanical engagement are required.
Constructed with bend-insensitive G.657.A1 fiber and a 2.0mm riser-rated (OFNR) tight-buffered jacket, this duplex patch cable delivers low insertion loss, high return loss, and consistent performance even when routed through tight spaces. It supports 1G/10G/25G/40G/100G/400G Ethernet connections and is well-suited for long-distance transmission up to 10 km at 1310 nm or up to 40 km at 1550 nm, making it an excellent choice for single mode backbones, cross-connects, and point-to-point links.
Need help matching ST patch cords to your existing panels, test gear, or long-haul runs? Contact us now and our team will assist in validating your configuration before deployment.
Key Specifications
| Specification | Details |
|---|---|
| Vendor Name | NSComm |
| Product Type | ST UPC to ST UPC Duplex Single Mode Fiber Patch Cable |
| Connector A | ST UPC Duplex |
| Connector B | ST UPC Duplex |
| Fiber Count | 2 Fibers (Duplex) |
| Fiber Grade | G.657.A1 (Compatible with G.652.D) |
| Fiber Mode | OS2 9/125 μm |
| Wavelength | 1310 nm / 1550 nm |
| Polarity | A (Tx) to B (Rx) |
| Cable Type | Tight-buffered |
| Cable Outside Diameter (OD) | 2.0 mm |
| Flame Rating | Riser (OFNR) |
| Min. Bend Radius (Optical Fiber) | 10 mm |
| Min. Bend Radius (Fiber Cable) | 10/5D (Dynamic/Static) |
| Connector Durability | 1000 mating cycles |
| Tensile Strength | 90/150 N (Long/Short Term) |
| Insertion Loss | ≤ 0.30 dB |
| Return Loss | ≥ 50 dB |
| Attenuation @ 1310 nm | 0.4 dB/km |
| Attenuation @ 1550 nm | 0.3 dB/km |
| Operating Temperature | -10 to 70 °C (14 to 158 °F) |
| Storage Temperature | -20 to 70 °C (-4 to 158 °F) |
| Recommended Distance @ 1310 nm | Up to 10 km (application dependent) |
| Recommended Distance @ 1550 nm | Up to 40 km (application dependent) |
| Applications | 1G/10G/25G/40G/100G/400G Ethernet, industrial/legacy ST systems, DC/telecom backbones |
Why Choose NSComm ST UPC to ST UPC Duplex OS2 Patch Cables?
-
Secure bayonet-lock ST connectors – Fast, twist-lock coupling provides reliable connections in lab, industrial, and legacy telecom environments.
-
Long-distance OS2 performance – Supports extended reach links up to 10 km @ 1310 nm and 40 km @ 1550 nm.
-
Bend-insensitive G.657.A1 fiber – Reduced attenuation when bent or twisted, simplifying routing and ongoing maintenance.
-
Low loss & high return loss – Tight optical performance supports high-speed Ethernet services up to 400G.
-
Riser-rated 2.0mm construction – Durable tight-buffered OFNR jacket for use in riser spaces, racks, trays, and conduits.
Length Options
Standard stocked lengths:
Available in a range of common duplex lengths ideal for frame-to-frame, rack-to-rack, and equipment-to-panel connections in telecom rooms, data centers, and industrial sites.
Custom lengths:
Custom lengths, jacket colors, labeling, and polarity options are available on request to align with specific cabling standards, plant layouts, and routing paths.
