NSComm S5350-24GT4SFP-E 24x1G Ports & 4x1G SFP L3 Fiber Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- NS‑S5350‑24GT4SFP‑E – 24×1 Gbps SFP + 4×1/10 Gbps SFP+ Layer 2+ Fiber Access Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
As a top OEM partner alongside Cisco, H3C, Huawei, and Ruijie, NSComm offers the exact same hardware, software, and reliability of Ruijie’s RG‑S5350‑E series - with your brand label.
Our NS‑S5350‑E switches deliver enterprise‑grade Layer 3 routing, virtualization (VSU), robust security, high switching capacity, and PoE options across 12‑, 24‑, and 48‑port variants.
Overview
The NS‑S5350‑24GT4SFP‑E is an all‑fiber Layer 2+ access switch featuring 24 × 1 Gbps SFP downlinks and 4 × 1/10 Gbps SFP+ uplinks. Designed for noise‑immune, long‑reach connectivity in data centers or enterprise campuses, it delivers 154 Gbps switching capacity and 115 Mpps forwarding.
It supports VLAN, QinQ, LACP, STP/RSTP/MSTP, ERPS loop protection, RLDP link detection, and advanced security including DHCP snooping and ACLs—all managed via CLI, Web GUI, SNMP, or cloud-based zero‑touch provisioning.
Highlights
-
154 Gbps Switching Capacity & 115 Mpps Forwarding ensure wire‑speed performance for fiber‑only access.
-
24 × 1 Gbps SFP Downlinks provide flexible, long‑distance multimode or single‑mode fiber connectivity.
-
Comprehensive L2+ Feature Set: VLAN, QinQ, LACP, IGMP/MLD snooping, STP/RSTP/MSTP, ERPS, RLDP.
-
Robust Security: DHCP snooping, Dynamic ARP Inspection, IP Source Guard, port‑based ACLs.
-
Flexible Management & O&M: CLI, Web GUI, SNMP v1/2/3, RMON, SSH/Telnet, USB‑based config backup, and zero‑touch provisioning.
Recommended Accessories
| Product Name | Category | Description |
|---|---|---|
| NS‑PA150IB‑F | AC Power Module | 150 W hot‑swappable AC PSU slot |
| NS‑PD150IB‑F | DC Power Module | 150 W hot‑swappable DC PSU slot |
| NS‑SFP‑1G‑SX | SFP Transceiver | 1 Gbps multimode fiber (850 nm, up to 550 m) |
| NS‑SFP‑1G‑LX | SFP Transceiver | 1 Gbps single‑mode fiber (1310 nm, up to 10 km) |
| NS‑RMK‑1U | Rack Mount Kit | Standard 19″ 1U mounting brackets |
| NS‑Console‑Cable | Console Cable | RJ45 to USB/DB9 for CLI access |
Compare with Similar Models
| Model | Ports & Uplinks | PoE | Capacity/Forwarding |
|---|---|---|---|
| Ruijie RG‑S5350‑24GT4XS‑E | 24 × 1 GbE + 4 × 10 Gbps SFP+ | None | 154 Gbps / 115 Mpps |
| NS‑S5350‑24GT4XS‑E (NSComm) | Same | None | Same |
| Ruijie RG‑S5350‑48GT4XS‑E | 48 × 1 GbE + 4 × 10 Gbps SFP+ | None | 211 Gbps / 158 Mpps |
| NS‑S5350‑48GT4XS‑E (NSComm) | Same | None | Same |
| Ruijie RG‑S5350‑12GT4XS‑P‑E | 12 × 1 GbE PoE+ + 4 × 10 Gbps SFP+ | PoE+ | 125 Gbps / 94 Mpps |
| NS‑S5350‑12GT4XS‑P‑E (NSComm) | Same | PoE+ | Same |
| Ruijie RG‑S5350‑24GT4XS‑P‑E | 24 × 1 GbE PoE+ + 4 × 10 Gbps SFP+ | PoE+ | 154 Gbps / 115 Mpps |
| NS‑S5350‑24GT4XS‑P‑E (NSComm) | Same | PoE+ | Same |
| Ruijie RG‑S5350‑48GT4XS‑P‑E | 48 × 1 GbE PoE+ + 4 × 10 Gbps SFP+ | PoE+ | 211 Gbps / 158 Mpps |
| NS‑S5350‑48GT4XS‑P‑E (NSComm) | Same | PoE+ | Same |
| Ruijie RG‑S5350‑24GT4SFP‑E | 24 × 1 Gbps SFP + 4 × 1 Gbps SFP | None | 154 Gbps / 115 Mpps |
| NS‑S5350‑24GT4SFP‑E (NSComm) | Same | None | Same |
| Ruijie RG‑S5350‑48GT4SFP‑E | 48 × 1 Gbps SFP + 4 × 1 Gbps SFP | None | 211 Gbps / 158 Mpps |
| NS‑S5350‑48GT4SFP‑E (NSComm) | Same | None | Same |
| Ruijie RG‑S5350‑24GT4SFP‑P‑E | 24 × 1 Gbps SFP PoE+ + 4 × 1 Gbps SFP | PoE+ | 154 Gbps / 115 Mpps |
| NS‑S5350‑24GT4SFP‑P‑E (NSComm) | Same | PoE+ | Same |
| Ruijie RG‑S5350‑48GT4SFP‑P‑E | 48 × 1 Gbps SFP PoE+ + 4 × 1 Gbps SFP | PoE+ | 211 Gbps / 158 Mpps |
| NS‑S5350‑48GT4SFP‑P‑E (NSComm) | Same | PoE+ | Same |
Specification Summary
| Parameter | Specification |
|---|---|
| Model | NS‑S5350‑24GT4SFP‑E |
| Downlink Ports | 24 × 100/1000 Mbps SFP |
| Uplink Ports | 4 × 1 Gbps/10 Gbps SFP+ |
| Switching Capacity | 154 Gbps |
| Forwarding Rate | 115 Mpps |
| MAC Address Table | 16,000 entries |
| ARP Table Size | 4,000 entries |
| VLAN Support | Up to 4,094 VLANs |
| L2+ Features | QinQ, LACP, STP/RSTP/MSTP, ERPS, RLDP, IGMP/MLD snooping |
| Security Features | DHCP snooping, Dynamic ARP Inspection, IP Source Guard, ACLs |
| Buffer Memory | 4 MB |
| Power Input | AC 100–240 V |
| Operating Temperature | 0 °C to 45 °C |
| Dimensions (W×D×H) | 442 × 220 × 43.6 mm |
| Weight | ~ 3.1 kg |
| Mounting | Rack / Wall / Desktop |
| Management | CLI / Web GUI / SNMP v1/2/3 / SSH / Telnet / RMON / ZTP |
| MTBF | > 200,000 hours |
