Overview
The NSComm E530-24T8X is a high-performance Layer 2/Layer 3 managed Ethernet switch designed for TOR access, enterprise and metro networks, and Hyper-Converged Infrastructure (HCI) access or aggregation scenarios. It provides 24 x 10/100/1000Base-T Gigabit RJ45 ports and 8 x 10GE SFP+ uplink ports, giving network teams a compact 1U platform for secure access, high-speed aggregation, and scalable campus or branch deployments.
Powered by a dual-core ARM A53 SOC with 2GB memory, 8GB eMMC flash, and a 9MB packet buffer, the E530-24T8X supports both store-and-forward and cut-through switching. It delivers 208Gbps switching capacity, 154.75Mpps throughput, and low 660ns latency for business-critical network traffic.
Core Highlights
-
24 Gigabit RJ45 access ports
Provides 24 x 1GE Base-T ports for wired access, endpoint connectivity, and enterprise edge deployment. -
8 high-speed 10GE SFP+ uplinks
Built-in 10G optical uplink ports support aggregation to core switches, distribution layers, servers, or storage networks. -
Layer 2/Layer 3 managed switching
Suitable for VLAN segmentation, resilient Layer 2 access, routing-enabled aggregation, and managed enterprise network expansion. -
High-performance hardware platform
208Gbps switching capacity, 154.75Mpps throughput, 9MB packet buffer, and 660ns latency help maintain stable forwarding under burst traffic. -
Rich management interfaces
Includes 1 x RJ45 console port, 1 x RJ45 out-of-band management port, in-band management support, and 1 x Type-A USB port. -
Reliable 1U rack-mount design
Standard 19-inch rack-mountable hardware with fan cooling, intelligent fan speed control, dual power input support, and front-to-rear/rear-to-front airflow options.
Applications Scenarios
- Enterprise Access Networks: Connect wired users, workstations, printers, access controllers, and office endpoints with managed Gigabit access.
- Campus and Branch Aggregation: Use 10GE SFP+ uplinks to aggregate access traffic toward distribution or core layers.
- Metro and Service Provider Edge: Deploy as a compact managed platform for metro access or edge aggregation environments.
- HCI and Server Access: Support hyper-converged infrastructure access where Gigabit downlinks and 10G uplinks are required.
- Operations and Maintenance Networks: Use console, out-of-band, in-band, and USB management interfaces for flexible deployment and service workflows.
Comparison with Similar Models
| Model | Ports | PoE | Uplink | Platform | Best For |
|---|---|---|---|---|---|
| NSComm E530-24T8X | 24 x 1GE RJ45 | None | 8 x 10GE SFP+ | L2/L3 managed | Enterprise, metro, HCI access or aggregation |
| Cisco C9200-24T-A | 24 x 1GE RJ45 | None | Modular 1G/10G | Network Advantage | Campus access and branch data-only networks |
| Huawei S5735-L24T4X-A1 | 24 x 1GE RJ45 | None | 4 x 10GE SFP+ | CloudEngine S5735-L | SMB, campus access, and enterprise edge switching |
Specifications
| Parameter | Specification | Value |
|---|---|---|
| Model | Product model | NSComm E530-24T8X |
| Switch type | Managed Ethernet switch | Layer 2 / Layer 3 |
| Downlink ports | RJ45 electrical ports | 24 x 1GE Base-T |
| Uplink ports | Optical uplink ports | 8 x 10GE SFP+ |
| Switching capacity | Switching capability | 208 Gbps |
| Forwarding rate | Throughput | 154.75 Mpps |
| Latency | Hardware forwarding latency | 660 ns |
| Packet buffer | Buffer memory | 9 MB |
| CPU | Processor | Dual-core ARM A53 SOC |
| Memory / Flash | System memory and storage | 2GB memory / 8GB eMMC flash |
| Management ports | Console and management | 1 x RJ45 console, 1 x RJ45 out-of-band management, in-band management, 1 x Type-A USB |
| Switching method | Forwarding mode | Store-and-forward / cut-through |
| Power supply | AC power | 100-240V AC, 50/60Hz; maximum 90-264V AC, 47-63Hz |
| Power input | Redundancy support | Double power input supported |
| Power draw | Typical / maximum | 41W typical / 55W maximum |
| Surge protection | Protection level | 2 kV |
| Form factor | Rack deployment | Standard 1U 19-inch rack mountable |
| Dimensions | H x W x D | 4.4 x 44.2 x 24.5 cm (1.7 x 17.4 x 9.7 in.) |
| Weight | Device weight | 3.60 kg |
| Cooling | Fan design | Fan cooling, 2 fixed fans, intelligent speed control |
| Airflow | Airflow direction | Front-to-rear / rear-to-front airflow |
| Operating temperature | Environment | 0 deg C to 45 deg C |
| MTBF | Reliability | 215,299 hours / 24.58 years |
Why Choose NSComm E530-24T8X?
- 24-port Gigabit access with 8-port 10G SFP+ uplink capacity in one compact 1U switch.
- 208Gbps switching and 154.75Mpps forwarding for stable enterprise traffic handling.
- Designed for TOR access, enterprise, metro, HCI access, and aggregation deployments.
- Flexible management through console, out-of-band, in-band, and USB interfaces.
- Reliable fixed-fan cooling, intelligent fan speed control, and double power input support.
- Suitable for scalable campus, branch, data-center edge, and service-provider access networks.
