MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G IoT Gateway
Clique ou role para ampliar
Toque ou belisque para ampliar
MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G IoT Gateway
Clique ou role para ampliar
Toque ou belisque para ampliar
MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G IoT Gateway
MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G IoT Gateway

MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G IoT Gateway

por Mikrotik
R$ 2.136,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] Industrial-grade LoRa 868MHz IoT gateway featuring LTE Cat M1/NB2 support, GPS/GNSS tracking, dual Fast Ethernet with PoE-out, and Bluetooth 5.2 powered by RouterOS v7. [/shortdesc]

[properties]

Model KNOT LR8G kit
Product Code RB924iR-2nD-BT5&BG770A&R11e-LR8G
Product Type IoT Gateway
CPU QCA9531 650 MHz
CPU Architecture MIPSBE
RAM 64 MB DDR2
Storage 128 MB NAND
Ethernet Ports 2 x 100 Mbps
Wireless Standard 2.4 GHz 802.11b/g/n
Wireless Interface Model QCA9531
Antenna Gain 1.5 dBi
Antenna Beam Width 360 degree
Bluetooth Version 5.2
GNSS GPS (MT3337V)
LoRa Band 868 MHz
IoT Modem BG770A
CAT-M Support Cat M1
CAT-NB Support Cat NB2
Operating System RouterOS v7, License Level 4
Operating Temperature -40C to +70C
Dimensions 122 x 87 x 26 mm

[/properties]

[specifications]

USB Port 1 x microUSB type AB
Antenna Connector SMA female
Number of DC Inputs 3 (PoE-In, MicroUSB, DC jack)
PoE-In Input Voltage 18-57 V
MicroUSB Input Voltage 5 V
DC Jack Input Voltage 12-57 V
PoE-In Standard 802.3af/at
PoE-Out 802.3af (Ether2)
Power Adapter Nominal Voltage 24 V
Power Adapter Nominal Current 1.2 A
Max Output per Port (Input < 30 V) 650 mA
Max Output per Port (Input > 30 V) 450 mA
Max Power Consumption (Without Attachments) 6 W
Max Power Consumption 23 W
Wi-Fi Data Rates 1Mbit/s (22 dBm, -96 dBm), 11Mbit/s (22 dBm, -89 dBm), 6Mbit/s (20 dBm, -93 dBm), 54Mbit/s (18 dBm, -74 dBm), MCS0 (20 dBm, -93 dBm), MCS7 (16 dBm, -71 dBm)
CAT NB Bands B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66
CAT M Bands B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66

[/specifications]

[accesories]

Included 24 V 1.2 A Power Adapter; Wall Mount Set; DIN Rail Mount Set; USB OTG Cable

[/accesories]

The MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G kit is a compact industrial IoT gateway designed to connect sensors, assets, and remote equipment to modern cloud platforms. Combining LoRa connectivity, LTE Cat M1 and NB2 cellular networking, GNSS positioning, and WiFi, it provides reliable communication for distributed IoT deployments.

Built for environments where infrastructure is limited, the KNOT LR8G enables secure monitoring, automation, and data collection across industries such as healthcare, logistics, agriculture, and industrial automation. With RouterOS v7 and flexible powering options including PoE, MicroUSB, and DC input, it offers powerful edge connectivity in a compact and energy-efficient design.

  • LoRa 868 MHz IoT Connectivity: Designed for long-range, low-power IoT communication, enabling reliable data collection from sensors and devices across large industrial or outdoor environments.
  • LTE Cat M1 and NB2 Cellular Modem: Integrated BG770A modem provides low-bandwidth mobile connectivity optimized for IoT deployments, reducing operational costs compared to traditional LTE connections.
  • Concurrent GNSS and Cellular Tracking: Built-in GNSS GPS support allows accurate asset tracking while maintaining active LTE connectivity for real-time location and telemetry updates.
  • Flexible Network Interfaces: Dual 100 Mbps Ethernet ports support PoE-in and PoE-out, enabling network connectivity and the ability to power additional devices from the gateway.
  • RouterOS v7 Platform: MikroTik RouterOS provides advanced routing, scripting, monitoring, and remote management capabilities, giving administrators full control over IoT network infrastructure.
  • Industrial IoT monitoring and automation systems
  • Smart agriculture and environmental sensor networks
  • Cold chain monitoring and logistics tracking
  • Hospital equipment and asset tracking using Bluetooth beacons
  • Remote telemetry and infrastructure monitoring
  • Product Code: RB924iR-2nD-BT5&BG770A&R11e-LR8G
  • CPU: QCA9531 650 MHz
  • Memory: 64 MB DDR2 RAM
  • Storage: 128 MB NAND
  • Ethernet Ports: 2x 10/100 Mbps Fast Ethernet
  • Wireless: 2.4 GHz 802.11b/g/n WiFi
  • LoRa Band: 868 MHz
  • Bluetooth: Bluetooth 5.2
  • Cellular Modem: BG770A with LTE Cat M1 and NB2
  • Operating System: MikroTik RouterOS v7 License Level 4
  • Power Options: PoE In 18-57 V, MicroUSB 5 V, DC jack 12-57 V
  • Power Consumption: Up to 23 W maximum
  • Operating Temperature: -40C to +70C

Deploy the MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G gateway to connect sensors, assets, and industrial systems with secure and scalable IoT connectivity. Order today.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] Industrial-grade LoRa 868MHz IoT gateway featuring LTE Cat M1/NB2 support, GPS/GNSS tracking, dual Fast Ethernet with PoE-out, and Bluetooth 5.2 powered by RouterOS v7. [/shortdesc]

[properties]

Model KNOT LR8G kit
Product Code RB924iR-2nD-BT5&BG770A&R11e-LR8G
Product Type IoT Gateway
CPU QCA9531 650 MHz
CPU Architecture MIPSBE
RAM 64 MB DDR2
Storage 128 MB NAND
Ethernet Ports 2 x 100 Mbps
Wireless Standard 2.4 GHz 802.11b/g/n
Wireless Interface Model QCA9531
Antenna Gain 1.5 dBi
Antenna Beam Width 360 degree
Bluetooth Version 5.2
GNSS GPS (MT3337V)
LoRa Band 868 MHz
IoT Modem BG770A
CAT-M Support Cat M1
CAT-NB Support Cat NB2
Operating System RouterOS v7, License Level 4
Operating Temperature -40C to +70C
Dimensions 122 x 87 x 26 mm

[/properties]

[specifications]

USB Port 1 x microUSB type AB
Antenna Connector SMA female
Number of DC Inputs 3 (PoE-In, MicroUSB, DC jack)
PoE-In Input Voltage 18-57 V
MicroUSB Input Voltage 5 V
DC Jack Input Voltage 12-57 V
PoE-In Standard 802.3af/at
PoE-Out 802.3af (Ether2)
Power Adapter Nominal Voltage 24 V
Power Adapter Nominal Current 1.2 A
Max Output per Port (Input < 30 V) 650 mA
Max Output per Port (Input > 30 V) 450 mA
Max Power Consumption (Without Attachments) 6 W
Max Power Consumption 23 W
Wi-Fi Data Rates 1Mbit/s (22 dBm, -96 dBm), 11Mbit/s (22 dBm, -89 dBm), 6Mbit/s (20 dBm, -93 dBm), 54Mbit/s (18 dBm, -74 dBm), MCS0 (20 dBm, -93 dBm), MCS7 (16 dBm, -71 dBm)
CAT NB Bands B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66
CAT M Bands B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66

[/specifications]

[accesories]

Included 24 V 1.2 A Power Adapter; Wall Mount Set; DIN Rail Mount Set; USB OTG Cable

[/accesories]

Industrial IoT Connectivity for Smart Monitoring and Automation

The MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G kit is a compact industrial IoT gateway designed to connect sensors, assets, and remote equipment to modern cloud platforms. Combining LoRa connectivity, LTE Cat M1 and NB2 cellular networking, GNSS positioning, and WiFi, it provides reliable communication for distributed IoT deployments.

Built for environments where infrastructure is limited, the KNOT LR8G enables secure monitoring, automation, and data collection across industries such as healthcare, logistics, agriculture, and industrial automation. With RouterOS v7 and flexible powering options including PoE, MicroUSB, and DC input, it offers powerful edge connectivity in a compact and energy-efficient design.

Key Benefits & Features
  • LoRa 868 MHz IoT Connectivity: Designed for long-range, low-power IoT communication, enabling reliable data collection from sensors and devices across large industrial or outdoor environments.
  • LTE Cat M1 and NB2 Cellular Modem: Integrated BG770A modem provides low-bandwidth mobile connectivity optimized for IoT deployments, reducing operational costs compared to traditional LTE connections.
  • Concurrent GNSS and Cellular Tracking: Built-in GNSS GPS support allows accurate asset tracking while maintaining active LTE connectivity for real-time location and telemetry updates.
  • Flexible Network Interfaces: Dual 100 Mbps Ethernet ports support PoE-in and PoE-out, enabling network connectivity and the ability to power additional devices from the gateway.
  • RouterOS v7 Platform: MikroTik RouterOS provides advanced routing, scripting, monitoring, and remote management capabilities, giving administrators full control over IoT network infrastructure.
Ideal Use Cases
  • Industrial IoT monitoring and automation systems
  • Smart agriculture and environmental sensor networks
  • Cold chain monitoring and logistics tracking
  • Hospital equipment and asset tracking using Bluetooth beacons
  • Remote telemetry and infrastructure monitoring
Technical Specifications
  • Product Code: RB924iR-2nD-BT5&BG770A&R11e-LR8G
  • CPU: QCA9531 650 MHz
  • Memory: 64 MB DDR2 RAM
  • Storage: 128 MB NAND
  • Ethernet Ports: 2x 10/100 Mbps Fast Ethernet
  • Wireless: 2.4 GHz 802.11b/g/n WiFi
  • LoRa Band: 868 MHz
  • Bluetooth: Bluetooth 5.2
  • Cellular Modem: BG770A with LTE Cat M1 and NB2
  • Operating System: MikroTik RouterOS v7 License Level 4
  • Power Options: PoE In 18-57 V, MicroUSB 5 V, DC jack 12-57 V
  • Power Consumption: Up to 23 W maximum
  • Operating Temperature: -40C to +70C
Build Reliable IoT Networks with MikroTik KNOT

Deploy the MikroTik RB924iR-2nD-BT5&BG770A&R11e-LR8G KNOT LR8G gateway to connect sensors, assets, and industrial systems with secure and scalable IoT connectivity. Order today.
