MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)
Clique ou role para ampliar
Toque ou belisque para ampliar
MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)
Clique ou role para ampliar
Toque ou belisque para ampliar
MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)
Clique ou role para ampliar
Toque ou belisque para ampliar
MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)
MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)

MikroTik KNOT LR9G IoT Gateway (RB924iR-2nD-BT5&BG770A&R11e-LR9G)

por Mikrotik
R$ 2.100,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] LoRa 915 MHz, LTE CAT-M NB2, GPS GNSS, 2x Ethernet PoE, Bluetooth 5.2, RouterOS v7 [/shortdesc]

[properties]

Model KNOT LR9G kit
Product Code RB924iR-2nD-BT5&BG770A&R11e-LR9G
Product Type Industrial IoT Gateway
CPU Single-core QCA9531 650 MHz
CPU Architecture MIPSBE
RAM 64 MB DDR2
Storage 16 MB Flash
Ethernet Ports 2 x 100 Mbps
Wireless 2.4 GHz 802.11b/g/n dual-chain
Bluetooth 5.2
LoRa Band 915 MHz
GNSS GPS
IoT Modem BG770A
Cellular Support LTE CAT-M1, NB2
SIM Slot NanoSIM
Interfaces MicroUSB, MiniPCIe, RS485/Modbus, GPIO
Antenna Gain 1.5 dBi
Antenna Beam Width 360 deg
Operating System RouterOS v7 (License Level 4)
Dimensions 122 x 87 x 26 mm
Operating Temperature -40C to +70C

[/properties]

[specifications]

DC Inputs 3 (DC jack, Micro USB, PoE-In)
DC Jack Input Voltage 12-57 V
Micro USB Input Voltage 5 V
PoE-In Voltage 18-57 V
PoE Standard 802.3af/at
PoE-Out Supported (Ether2)
Max Output per Port (<30 V) 650 mA
Max Output per Port (>30 V) 450 mA
Power Adapter 24 V, 1.2 A
Max Power Consumption 23 W
Power Consumption (Idle) 6 W
MiniPCIe Slots 1
USB Ports 1 x MicroUSB type AB
Wireless Chipset QCA9531
Cat NB2 Bands B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66
Cat M1 Bands B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66
Wireless Data Rates Up to 54 Mbps (802.11g/n)
Wireless TX Power Up to 22 dBm
Receive Sensitivity -96 dBm

[/specifications]

[accessories]

Included 24 V 1.2 A power adapter, Wall mount set, DIN rail mount set, USB OTG cable

[/accessories]

The MikroTik KNOT LR9G is a versatile, industrial-grade gateway designed to bridge the gap between legacy wired hardware and modern cloud-based IoT networks. Supporting LoRa 915 MHz, LTE CAT-M/NB2, and Bluetooth 5.2, this compact device is an ideal centerpiece for smart asset tracking, remote monitoring, and efficient industrial automation. Powered by RouterOS v7, it provides advanced routing and custom scripting capabilities for infrastructure-light environments.

  • Unified IoT Connectivity: Combines LoRa 915 MHz, LTE CAT-M1/NB2, 2.4 GHz Wi-Fi, and Bluetooth 5.2 to connect a wide array of sensors and devices.
  • Concurrent GPS and LTE: Track high-value assets in motion with precise GNSS while maintaining a live LTE CAT-M1 connection for real-time data updates.
  • Versatile Powering Options: High flexibility with three DC inputs including PoE-in (802.3af/at), DC jack (12-57V), and MicroUSB. It also features PoE-out on Ether2 to power peripheral devices.
  • Enhanced 915 MHz LoRa Reception: Features improved sensitivity for stronger signal penetration and longer range, even in interference-heavy industrial environments.
  • Industrial Interface Support: Equipped with RS485/Modbus and GPIO interfaces to bridge legacy industrial equipment to the cloud via MQTT or HTTPS.
  • Hospital Asset Tracking: Use Bluetooth beacons and KNOT gateways to monitor critical medical equipment location and status.
  • Agriculture and Remote Sites: Gather soil and weather data from long-range LoRa sensors in rural fields via low-power LTE or NB-IoT.
  • Cold Chain Monitoring: Convert wired Modbus temperature sensors to TCP for secure data forwarding in refrigerated logistics.
  • Industrial Automation: Integrate KNOT into manufacturing environments using DIN rail mounting and GPIO monitoring for smarter cabinet management.
  • Processor: QCA9531 single-core 650 MHz
  • Memory: 64 MB RAM, 16 MB Flash storage
  • Networking: 2x 10/100 Mbps Ethernet ports (PoE-in and PoE-out)
  • Wireless Standards: 2.4 GHz 802.11b/g/n dual-chain
  • Mobile Data: LTE CAT-M1 and NB2 support for global bands
  • Antenna Connectors: SMA female connectors for LTE, GPS, and LoRa
  • Durability: Rugged design with an operating temperature range of -40C to +70C

Maximize your network efficiency with the MikroTik KNOT LR9G. Its low 6W power consumption and small footprint make it perfect for deployments where space and power are at a premium. Order today to simplify your remote monitoring and asset tracking infrastructure.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] LoRa 915 MHz, LTE CAT-M NB2, GPS GNSS, 2x Ethernet PoE, Bluetooth 5.2, RouterOS v7 [/shortdesc]

[properties]

Model KNOT LR9G kit
Product Code RB924iR-2nD-BT5&BG770A&R11e-LR9G
Product Type Industrial IoT Gateway
CPU Single-core QCA9531 650 MHz
CPU Architecture MIPSBE
RAM 64 MB DDR2
Storage 16 MB Flash
Ethernet Ports 2 x 100 Mbps
Wireless 2.4 GHz 802.11b/g/n dual-chain
Bluetooth 5.2
LoRa Band 915 MHz
GNSS GPS
IoT Modem BG770A
Cellular Support LTE CAT-M1, NB2
SIM Slot NanoSIM
Interfaces MicroUSB, MiniPCIe, RS485/Modbus, GPIO
Antenna Gain 1.5 dBi
Antenna Beam Width 360 deg
Operating System RouterOS v7 (License Level 4)
Dimensions 122 x 87 x 26 mm
Operating Temperature -40C to +70C

[/properties]

[specifications]

DC Inputs 3 (DC jack, Micro USB, PoE-In)
DC Jack Input Voltage 12-57 V
Micro USB Input Voltage 5 V
PoE-In Voltage 18-57 V
PoE Standard 802.3af/at
PoE-Out Supported (Ether2)
Max Output per Port (<30 V) 650 mA
Max Output per Port (>30 V) 450 mA
Power Adapter 24 V, 1.2 A
Max Power Consumption 23 W
Power Consumption (Idle) 6 W
MiniPCIe Slots 1
USB Ports 1 x MicroUSB type AB
Wireless Chipset QCA9531
Cat NB2 Bands B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/B19/B20/B25/B28/B66
Cat M1 Bands B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66
Wireless Data Rates Up to 54 Mbps (802.11g/n)
Wireless TX Power Up to 22 dBm
Receive Sensitivity -96 dBm

[/specifications]

[accessories]

Included 24 V 1.2 A power adapter, Wall mount set, DIN rail mount set, USB OTG cable

[/accessories]

Industrial IoT Gateway for Smart Tracking and Automation

The MikroTik KNOT LR9G is a versatile, industrial-grade gateway designed to bridge the gap between legacy wired hardware and modern cloud-based IoT networks. Supporting LoRa 915 MHz, LTE CAT-M/NB2, and Bluetooth 5.2, this compact device is an ideal centerpiece for smart asset tracking, remote monitoring, and efficient industrial automation. Powered by RouterOS v7, it provides advanced routing and custom scripting capabilities for infrastructure-light environments.

Key Features and Upgrades
  • Unified IoT Connectivity: Combines LoRa 915 MHz, LTE CAT-M1/NB2, 2.4 GHz Wi-Fi, and Bluetooth 5.2 to connect a wide array of sensors and devices.
  • Concurrent GPS and LTE: Track high-value assets in motion with precise GNSS while maintaining a live LTE CAT-M1 connection for real-time data updates.
  • Versatile Powering Options: High flexibility with three DC inputs including PoE-in (802.3af/at), DC jack (12-57V), and MicroUSB. It also features PoE-out on Ether2 to power peripheral devices.
  • Enhanced 915 MHz LoRa Reception: Features improved sensitivity for stronger signal penetration and longer range, even in interference-heavy industrial environments.
  • Industrial Interface Support: Equipped with RS485/Modbus and GPIO interfaces to bridge legacy industrial equipment to the cloud via MQTT or HTTPS.
Practical IoT Use Cases
  • Hospital Asset Tracking: Use Bluetooth beacons and KNOT gateways to monitor critical medical equipment location and status.
  • Agriculture and Remote Sites: Gather soil and weather data from long-range LoRa sensors in rural fields via low-power LTE or NB-IoT.
  • Cold Chain Monitoring: Convert wired Modbus temperature sensors to TCP for secure data forwarding in refrigerated logistics.
  • Industrial Automation: Integrate KNOT into manufacturing environments using DIN rail mounting and GPIO monitoring for smarter cabinet management.
Technical Specifications Overview
  • Processor: QCA9531 single-core 650 MHz
  • Memory: 64 MB RAM, 16 MB Flash storage
  • Networking: 2x 10/100 Mbps Ethernet ports (PoE-in and PoE-out)
  • Wireless Standards: 2.4 GHz 802.11b/g/n dual-chain
  • Mobile Data: LTE CAT-M1 and NB2 support for global bands
  • Antenna Connectors: SMA female connectors for LTE, GPS, and LoRa
  • Durability: Rugged design with an operating temperature range of -40C to +70C
Efficient, Cost-Effective IoT Deployment

Maximize your network efficiency with the MikroTik KNOT LR9G. Its low 6W power consumption and small footprint make it perfect for deployments where space and power are at a premium. Order today to simplify your remote monitoring and asset tracking infrastructure.
