Kioxia KPM61VUG1T60 PM6-V Series solid state drive delivers 1.6 TB of 96 layer BiCS FLASH TLC storage with a 24G SAS interface, sequential read speeds up to 4,150 MB/s, sequential write speeds up to 2,750 MB/s, and endurance rated for 3 DWPD. It also features up to 595,000 random read IOPS, power loss protection, end to end data protection, T10 DIF, Multi Stream Write support, and single or dual port connectivity for enterprise storage environments.
Specifications
Model Number: KPM61VUG1T60
Brand: Kioxia
Alt Part Number(s): KPM61VUG1T60
Product Type: Solid State Drive
Technical Description
Brand: Kioxia
Model: KPM61VUG1T60
Series: PM6-V
Capacity: 1.6 TB
Form Factor: 2.5-inch; 15 mm Z-height
Interface: 24G SAS; SAS-4; SAS 22.5 Gb/s; Backward compatible
Flash Memory: 96-layer BiCS FLASH TLC
Endurance: 3 DWPD (Drive Writes Per Day) for 100% random workloads
Random Read: Up to 595,000 IOPS
Random Write: Up to 265,000 IOPS
Sequential Read: Up to 4,150 MB/s
Sequential Write: Up to 2,750 MB/s
Features: Power Loss Protection (PLP); End-to-End Data Protection; T10 DIF; Multi-Stream Write
Port Support: Single or Dual-Port capability
