Kioxia KPM7WVUG3T20 PM7-V 3.2TB SAS-4 22.5Gbit/s 2.5-inch SSD

Kioxia KPM7WVUG3T20 PM7-V is a 3.2 TB enterprise SAS solid-state drive engineered for mission-critical data center and server storage environments in a 2.5-inch 15 mm form factor. This SAS-4 SSD utilizes BiCS FLASH TLC technology and delivers sustained sequential performance up to 4,200 MB/s read and 3,650 MB/s write with up to 720K IOPS random read, 340K IOPS random write, 3 DWPD endurance, and enterprise-grade reliability rated for 2,500,000 hours MTTF.

Specifications

Model Number:  KPM7WVUG3T20

Brand: Kioxia

Alt Part Number(s):  KPM7WVUG3T20

Product Type:  Solid State Drive

Technical Description

Brand:  Kioxia

Model:  KPM7WVUG3T20

Series:   PM7-V

Capacity: 3.2 TB

Form Factor: 2.5-inch; 15 mm thickness

Interface: SAS-4

Interface Speed: 22.5 Gbit/s; 12.0 Gbit/s; 6.0 Gbit/s; 3.0 Gbit/s; 1.5 Gbit/s

Flash Memory Type: BiCS FLASH TLC

Sustained 128 KiB Sequential Read: 4,200 MB/s

Sustained 128 KiB Sequential Write: 3,650 MB/s

Sustained 4 KiB Random Read: 720K IOPS

Sustained 4 KiB Random Write: 340K IOPS

Supply Voltage: 12 V +/- 10%; 5 V +10% / -7%

Power Consumption (Ready): 5 W typ.

MTTF: 2,500,000 hours

DWPD: 3

Thickness: 15.0 mm +0; -0.5 mm

Width: 69.85 mm +/- 0.25 mm

Length: 100.45 mm Max

Weight: 130 g Max

Operating Temperature: 0 °C to 70 °C

Non-operating Temperature: -40 °C to 80 °C

Operating Humidity: 5% to 95% R.H.

Operating Vibration: 21.27 m/s^2 {2.17 Grms} (5 to 800 Hz)

Operating Shock: 9.8 km/s^2 {1,000 G} (0.5 ms)
