Intel DC P4101 Series 512G M.2 PCI-Express NVMe 3.1 x4 Solid State Drive (3D TLC) - SSDPEKKA512G801

The Intel DC P4101 Series 512GB M.2 NVMe SSD is an enterprise-grade storage solution built for read-intensive workloads. Leveraging PCIe NVMe 3.1 x4 and Intel's 3D TLC NAND technology, it delivers high sequential read performance and consistent low-latency access in a compact M.2 2280 form factor, ideal for dense server deployments.

Key Features

• 512GB capacity in a compact M.2 2280 form factor
• PCIe NVMe 3.1 x4 interface for high-speed data transfer
• Intel 3D TLC NAND for reliable, high-density storage
• Optimized for read-intensive enterprise workloads
• Power-loss data protection for enterprise reliability

Product Specifications

• Part Number: SSDPEKKA512G801
• Manufacturer: Intel
• OEM Status: OEM
• Model: DC P4101 Series
• Capacity: 512GB
• Form Factor: M.2 2280
• Interface: PCIe NVMe 3.1 x4
• NAND Type: 3D TLC

Storage Specifications

• Capacity: 512GB
• Form Factor: M.2 2280
• Interface: PCIe 3.1 x4 NVMe
• NAND Technology: Intel 3D TLC
• Endurance (TBW): 290 TBW
• Power Loss Protection: Yes

Performance Specifications

• Sequential Read: Up to 1,500 MB/s
• Sequential Write: Up to 490 MB/s
• Random Read (4K): Up to 155,000 IOPS
• Random Write (4K): Up to 20,000 IOPS
• Latency (Read): ~120µs typical

Use Cases

• Read-intensive enterprise applications such as web serving and caching
• Boot drives for high-density server deployments
• Edge computing and embedded server environments
• Virtualization hosts requiring fast, reliable M.2 storage

Compatibility

• Compatible with servers and workstations supporting M.2 PCIe NVMe slots
• Supported on Intel Xeon Scalable and select AMD EPYC server platforms
• Compatible with VMware ESXi, Windows Server, and Linux-based OS environments

Frequently Asked Questions

Is the P4101 suitable for write-intensive workloads?

The P4101 is optimized for read-intensive workloads. For write-intensive applications, consider the Intel DC P4510 or P4610 series.

Does it include power-loss data protection?

Yes — the DC P4101 includes capacitor-based power-loss protection to safeguard in-flight data during unexpected power events.

What is the endurance rating?

The 512GB model is rated for 290 TBW (Terabytes Written), suitable for enterprise read-intensive deployments.

The Intel DC P4101 512GB M.2 NVMe SSD delivers enterprise-class read performance in a space-saving form factor. Get yours today and accelerate your server storage with proven Intel technology.
