The Huawei CR5DLPUF517E, also known as the LPUF-51-E, is a flexible line processing unit designed for Huawei's NE40E series routers, particularly the NE40E-X8 model.
This line card supports 50 Gbps line-rate forwarding and features two sub-slots for Flexible PICs (FPICs), allowing for adaptable interface configurations to meet diverse networking requirements.
Its design facilitates high-performance packet processing, making it suitable for deployment in WAN aggregation and service provider edge network scenarios.
Overview
Highlights
-
50 Gbps Line-Rate Forwarding: Ensures high-speed data processing for demanding network environments.
-
Dual FPIC Sub-Slots: Provides flexibility in interface configurations, supporting various networking modules.
-
Hot-Swappable Design: Allows for maintenance and upgrades without disrupting network operations.
-
Optimized for NE40E-X8 Routers: Seamlessly integrates with Huawei's NE40E-X8 series, enhancing overall system performance.
Compare to Similar Items
| Model | Port Density | Max Throughput | Form Factor | Power Consumption | Software Support | Target Use |
| Huawei CR5DLPUF517E | 2 FPIC slots | 50 Gbps | Line Card | 214.5W | VRP | WAN Aggregation |
| Huawei CR5DLPUF120A | 2 FPIC slots | 120 Gbps | Line Card | 300W | VRP | Service Provider Edge |
| Huawei CR5DLPUF240A | 2 FPIC slots | 240 Gbps | Line Card | 450W | VRP | Core Networks |
| Huawei CR5DLPUF480A | 2 FPIC slots | 480 Gbps | Line Card | 600W | VRP | High-Capacity Core Networks |
| Huawei CR5DLPUF960A | 2 FPIC slots | 960 Gbps | Line Card | 800W | VRP | Ultra-High-Capacity Cores |
Recommended Accessories
| Model | Description |
| CR5D0EFGFE70 | 24-Port 1000Base-X SFP FPIC Module |
| CR5D00E2NC70 | 2-Port 100G CFP FPIC Module |
| CR5D00LBXF71 | 12-Port 10G SFP+ FPIC Module |
| SFP-GE-LX-SM1310 | 1000Base-LX SFP Transceiver Module |
| SFP-GE-SX-MM850 | 1000Base-SX SFP Transceiver Module |
| LC-LC-OM3-3M | 3m LC-LC OM3 Multimode Fiber Patch Cable |
| LC-LC-OS2-5M | 5m LC-LC OS2 Singlemode Fiber Patch Cable |
Specifications
| Category | Specification |
| Model | CR5DLPUF517E |
| Product Type | Flexible Card Line Processing Unit |
| Compatible Router | Huawei NE40E-X8 |
| FPIC Sub-Slots | 2 |
| Dimensions (D x W x H) | 532 mm x 399 mm x 40 mm |
| Weight | Approximately 3.5 kg |
| Typical Power Consumption | 214.5W |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Software Compatibility | Huawei VRP |
| Hot-Swappable | Yes |
