Huawei CloudEngine S5735S-L32ST4X-A 24×GE SFP + 8×RJ45 & 4×10G SFP+ Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Huawei CloudEngine S5735S-L32ST4X-A | 32-Port Gigabit Fiber Enterprise Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Overview
The huawei cloudengine s5735 series introduces the s5735 l32st4x a, a versatile Layer 2+ Gigabit Ethernet enterprise switch designed for campus networks and high-density access scenarios. Offering a unique mixed-port configuration, this huawei s5735 switch features 24 GE SFP ports, 8 10/100/1000BASE-T RJ45 ports, and 4 dedicated 10GE SFP+ uplink ports. This specific huawei switch s5735 acts seamlessly as a specialized fiber switch or a lightweight aggregation switch for branches and multi-floor building layouts.
Operating on the trusted cloudengine s5735 architecture, the huawei cloudengine s5735 platform delivers a switching capacity of up to 432 Gbps and a forwarding rate of 108 Mpps. By integrating the huawei s5735 into your network, you gain highly efficient data handling, intelligent stacking (iStack), and comprehensive security. Whether upgrading an edge tier or linking optical endpoints, the s5735 ensures robust non-blocking connectivity, making the huawei s5735 an indispensable s5735 edge asset.
-
Related Reading & Architecture Resource Guides:
-
Need help with your 10G optical uplinks? Review our 10G SFP+ Transceivers Buying Guide: Huawei Compatible Modules.
-
Evaluating access layer visibility? Check out: Huawei Switch Management Features and Access Layer Performance Analysis.
-
Key Highlights
1. Mixed Port Fiber Configuration
The s5735 l32st4x a provides 24 GE SFP ports, 8 RJ45 copper ports, and 4 10GE SFP+ uplinks. As a highly capable fiber switch, this huawei cloudengine s5735 model guarantees flexible optical and copper deployment within the s5735 networking ecosystem.
2. High Performance Switching
With a switching capacity of up to 432 Gbps, the huawei s5735 processes enterprise data rapidly. The cloudengine s5735 backplane ensures the huawei s5735 switch maintains an impressive 108 Mpps forwarding rate across all interfaces.
3. Layer 2+ and Basic Layer 3 Features
The huawei switch s5735 supports IPv4/IPv6 static routing, RIP, and OSPF. These capabilities give the huawei cloudengine s5735 robust network routing intelligence without the cost overhead of a massive modular aggregation switch.
4. Comprehensive Edge Security
Every huawei s5735 switch includes advanced perimeter protection. The s5735 features 802.1X authentication, MAC address filtering, DHCP snooping, ARP inspection, and port isolation natively on the huawei s5735.
5. Intelligent Stacking (iStack)
The cloudengine s5735 series supports stacking of up to 9 switches. Clustering your huawei switch s5735 architecture simplifies management and drastically enhances the scalability of the s5735.
6. Energy-Efficient Design
Intelligent fan speed adjustment proactively reduces power consumption for the huawei s5735. This makes the huawei cloudengine s5735 highly suitable for quiet office environments and standard wiring closets.
7. Robust Centralized Management
The s5735 offers web-based management, SNMP v1/v2c/v3, RMON, and CLI.
Recommended Application Scenarios
The huawei cloudengine s5735 is exceptionally adaptable. The s5735 l32st4x a configuration is highly recommended for:
-
Enterprise campus networks operating on the huawei s5735.
-
Mixed fiber-copper topologies needing a reliable huawei s5735 switch.
-
Branch optical distribution leveraging the huawei switch s5735.
-
Education network aggregation via the cloudengine s5735.
-
Security control rooms and surveillance backhauls running the s5735.
Recommended Accessories
Pair your s5735 l32st4x a with genuine huawei cloudengine s5735 accessories to guarantee optimal optical performance.
| Product Model | Category | Description |
|---|---|---|
| SFP-10G-SR | SFP+ Transceiver | 10GBASE-SR SFP+, 850nm, multimode fiber, up to 300m |
| SFP-10G-LR | SFP+ Transceiver | 10GBASE-LR SFP+, 1310nm, single-mode fiber, up to 10km |
| SFP-GE-LX-SM1310 | SFP Transceiver | 1000BASE-LX SFP, 1310nm, single-mode fiber, up to 10km |
| SFP-GE-SX-MM850 | SFP Transceiver | 1000BASE-SX SFP, 850nm, multimode fiber, up to 550m |
| CAB-SFP-1M | SFP Cable | 1-meter SFP direct attach copper cable |
| CAB-SFP-3M | SFP Cable | 3-meter SFP direct attach copper cable |
| CAB-SFP-5M | SFP Cable | 5-meter SFP direct attach copper cable |
Comparison with Similar Items
| Feature | S5735S-L32ST4X-A | S5735S-L24T4X-A | S5735S-L48T4X-A |
|---|---|---|---|
| Downlink Ports | 24 × GE SFP + 8 × GE | 24 × GE | 48 × GE |
| Uplink Ports | 4 × 10GE SFP+ | 4 × 10GE SFP+ | 4 × 10GE SFP+ |
| PoE Support | No | No | No |
| Switching Capacity | 432 Gbps | 336 Gbps | 432 Gbps |
| Forwarding Rate | 108 Mpps | 96 Mpps | 132 Mpps |
| Stacking Support | Yes (iStack) | Yes (iStack) | Yes (iStack) |
| Ideal Use Case | Mixed fiber/copper access | Standard access | High-density access |
Specifications
| Parameter | Specification |
|---|---|
| Model | S5735S-L32ST4X-A |
| Downlink Ports | 24 × GE SFP ports and 8 × 10/100/1000BASE-T ports |
| Uplink Ports | 4 × 10GE SFP+ ports |
| Switching Capacity | Up to 432 Gbps |
| Forwarding Rate | 108 Mpps |
| MAC Address Table | 32K entries |
| VLANs | Supports up to 4,096 VLANs (IEEE 802.1Q) |
| QoS | 8 queues per port, SP, WRR, and SP+WRR scheduling algorithms |
| IPv6 Features | IPv6 host, static routes, OSPFv3, BGP4+, IS-ISv6 |
| Security Features | 802.1X, MAC filtering, DHCP snooping, ARP inspection, port isolation |
| Management | Web-based, CLI, Telnet, SNMP v1/v2/v3, RMON, SSHv2 |
| Power Supply | Built-in AC power module (non-pluggable) |
| Power Consumption | Typical: 53.2W |
| Operating Temperature | -5°C to 50°C (23°F to 122°F) |
| Dimensions (W×D×H) | 442 mm × 220 mm × 43.6 mm (17.4 in. × 8.7 in. × 1.7 in.) |
| Weight | ≤ 4.03 kg (8.89 lbs) |
| Warranty | Limited lifetime warranty |
