- Huawei CloudEngine S5735S-L24P4X-A | 24-Port PoE+ 10G Uplink Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Overview
The huawei cloudengine s5735 series introduces the s5735s-l24p4x-a, a robust Layer 2+ Gigabit Ethernet poe switch with foundational Layer 3 routing. Designed for enterprise campus networks, IP surveillance systems, and SMB office LAN environments, it provides 24 ports, acting as a premier 10g uplink poe switch.
As a highly versatile huawei s5735 switch, it delivers stable, high-throughput connectivity for bandwidth-intensive services. The huawei switch s5735 ensures smooth HD CCTV video streaming and Wi-Fi 6 AP backhaul. With a switching capacity of 336 Gbps, the huawei cloudengine s5735 handles IoT device aggregation effortlessly. The integrated PoE+ power system of the huawei s5735 supports up to a 380W power budget. Deploying this 24 port poe switch enables the simultaneous deployment of multiple IP cameras and wireless access points without external power sourcing. This makes the s5735 an ideal choice for edge networks. The cloudengine s5735 architecture ensures maximum uptime, ensuring the s5735 l24p4x a fits perfectly into any access layer.
-
Related Reading & Architecture Resource Guides:
-
Evaluating Huawei for your access layers? Check out: Choosing the Best Huawei Switch: Efficient and Reliable Enterprise-Level Solutions.
-
Need help optimizing your PoE power draw? Review: Huawei PoE Switches: Optimizing Enterprise Networks and Reducing Power Costs.
-
Key Highlights
1. Port Configuration
This 24 port poe switch includes 24 Gigabit PoE+ ports and 4 10GE SFP+ uplinks. As a premium huawei s5735 switch, it fits CCTV aggregation networks perfectly.
2. High Performance Switching
Delivers 336 Gbps system capacity. The cloudengine s5735 ensures stable multi-service traffic handling across the s5735 architecture. The huawei s5735 delivers reliable packet forwarding for critical operations.
3. PoE+ Power Delivery
The huawei cloudengine s5735 supports IEEE 802.3af/at with a 380W PoE budget, making this 10g uplink poe switch ideal for smart buildings and VoIP arrays.
4. Layer 2+ Routing Capability
The huawei switch s5735 supports static routing, RIP, and OSPF. The huawei s5735 natively enables inter-VLAN routing and campus network segmentation.
5. Enterprise-Grade Security
The cloudengine s5735 includes 802.1X authentication, DHCP snooping, and ARP inspection. Every huawei cloudengine s5735 switch secures enterprise LANs and guest networks.
6. Intelligent Stacking (iStack)
The huawei s5735 supports iStack technology, enabling highly scalable network expansion for hospitals and campuses relying on the s5735.
7. Centralized Network Management
The huawei switch s5735 supports Web UI, CLI, SSH, and SNMP for simplified, centralized management of the cloudengine s5735 deployment.
Recommended Application Scenarios
The cloudengine s5735 is highly adaptable. This configuration is highly recommended for:
-
Enterprise campus networks running the huawei cloudengine s5735.
-
IP surveillance systems requiring a reliable 24 port poe switch.
-
Wi-Fi AP deployment utilizing the huawei s5735 switch.
-
Smart building infrastructure unified by the huawei switch s5735.
-
SMB office LAN layers powered by the huawei s5735.
-
IoT edge aggregation environments leveraging the s5735.
Recommended Accessories
To maximize performance, pair your hardware with genuine compatible optical modules and cables.
| Category | Product Model | Description |
|---|---|---|
| SFP+ Transceiver | SFP-10G-SR | 10G multimode fiber module, up to 300m, for intra-building backbone |
| SFP+ Transceiver | SFP-10G-LR | 10G single-mode fiber module, up to 10km, for campus interconnect |
| SFP+ Transceiver | SFP-10G-ER | 10G extended reach module, up to 40km, metro access networks |
| SFP+ Transceiver | SFP-10G-ZR | 10G ultra-long reach module, up to 80km, backbone transmission |
| SFP+ Cable | CAB-SFP-1M | 1m DAC cable for rack-level interconnection |
| SFP+ Cable | CAB-SFP-3M | 3m DAC cable for equipment room wiring |
| SFP+ Cable | CAB-SFP-5M | 5m DAC cable for cabinet-to-cabinet links |
Comparison with Similar Items
| Feature | S5735S-L24P4X-A | S5735S-L24T4X-A1 | S5735S-L48P4X-A |
|---|---|---|---|
| Downlink Ports | 24 GE PoE+ | 24 GE | 48 GE PoE+ |
| Uplink Ports | 4 x 10GE SFP+ | 4 x 10GE SFP+ | 4 x 10GE SFP+ |
| PoE Support | Yes (380W) | No | Yes (Up to 874W) |
| Switching Capacity | 128 / 336 Gbps | 128 / 336 Gbps | 176 / 432 Gbps |
| Forwarding Rate | 96 Mpps | 96 Mpps | 132 Mpps |
| Stacking Support | Yes (iStack) | Yes (iStack) | Yes (iStack) |
| Ideal Use Case | Campus PoE access / CCTV / Wi-Fi AP networks | Standard enterprise access | High-density PoE campus & smart building networks |
Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | S5735S-L24P4X-A | Enterprise PoE+ access switch |
| Downlink Ports | 24 x 10/100/1000BASE-T PoE+ | IP cameras, APs, VoIP phones, IoT devices |
| Uplink Ports | 4 x 10GE SFP+ | High-speed uplink to aggregation/core network |
| Switching Capacity | 128 Gbps / 336 Gbps | System-level traffic forwarding capability |
| Forwarding Rate | 96 Mpps | Packet processing performance under load |
| MAC Address Table | 32K entries (32,896) | Large-scale device learning capability |
| VLANs | Up to 4,096 (802.1Q) | Network segmentation for enterprise environments |
| QoS | 8 queues per port (SP/WRR/SP+WRR) | Traffic prioritization for voice/video/data |
| IPv6 Features | IPv6 host, static routing, OSPFv3 | IPv6 enterprise network compatibility |
| Security Features | 802.1X, DHCP Snooping, ARP Inspection, ACL | Enterprise network security enforcement |
| Management | Web / CLI / SSH / SNMP / RMON | Multi-level network management |
| Power Supply | Built-in AC power module | Integrated PoE power architecture |
| PoE Power Budget | 380W | Powering APs, cameras, and terminals |
| Power Consumption | 56 W (without PD) / 458 W (with full PD) | Device-only operating power |
| Operating Temperature | -5°C to 50°C | Enterprise indoor deployment |
| Dimensions | 442 x 220 x 43.6 mm | Standard 1U rack mount design |
| Weight | 4.31 kg (with packaging) | Deployment and logistics planning |
| Warranty | Limited lifetime warranty | Huawei enterprise hardware support |
Why Choose Huawei S5735S-L24P4X-A?
This model is optimized for organizations requiring reliable PoE-powered access infrastructure combined with Layer 3 intelligence and scalable uplink capacity.
It is widely deployed in:
-
Enterprise campus networks (office buildings, R&D centers, headquarters)
-
IP surveillance systems (CCTV monitoring and security control rooms)
-
Wi-Fi AP deployment (Wi-Fi 5 / Wi-Fi 6 enterprise wireless networks)
-
Smart building infrastructure (lighting, sensors, automation systems)
-
Hospitality networks (hotels, resorts, conference centers)
-
Education networks (universities, schools, training institutions)
-
SMB office LAN and branch network access layers
-
IoT edge aggregation environments
Compared with non-PoE models, it significantly reduces cabling complexity while enabling unified power and data delivery, making it a preferred solution for modern converged enterprise networks.
