Overview
The huawei s5735 s48p4x is a high-density Layer 3 Gigabit PoE+ access switch designed for enterprise campuses, large-scale WiFi deployments, CCTV surveillance systems, hotel networks, and smart building infrastructures. As a premier model in the huawei cloudengine s5735 series, this 48 port poe switch provides 48 Gigabit RJ45 PoE+ ports and 4 dedicated 10G SFP+ uplink ports. The huawei s5735 s48p4x delivers integrated power and data transmission for edge devices such as WiFi 6 access points, IP cameras, VoIP phones, IoT sensors, and access control systems.
By deploying the s5735-s48p4x, administrators gain strong forwarding performance, intelligent stacking (iStack), advanced Layer 3 routing capabilities, and enterprise-grade security. Operating within the robust huawei s5735 architecture, this enterprise poe switch is widely deployed in campus networks, ISP access layers, healthcare systems, retail chains, and smart city environments. Ensure your network is scalable and secure with the huawei switch s5735.
-
Related Reading & Architecture Resource Guides:
-
Evaluating Huawei for your core and access layers? Check out: Choosing the Best Huawei Switch: Efficient and Reliable Enterprise-Level Solutions.
-
Need help optimizing your PoE power draw? Review: Huawei PoE Switches: Optimizing Enterprise Networks and Reducing Power Costs.
-
Key Highlights
1. 48 Gigabit PoE+ High-Density Access
The huawei s5735 s48p4x supports the IEEE 802.3af/at PoE+ standard, enabling simultaneous power and data delivery. As a premier 48 port poe switch, the huawei s5735 switch powers:
-
WiFi 5 / WiFi 6 access points (AP deployments)
-
HD IP surveillance cameras (CCTV systems)
-
VoIP phones and unified communication devices
-
Access control systems and smart building sensors attached to the huawei cloudengine s5735.
2. 4 x 10G SFP+ High-Speed Uplinks
The huawei s5735 s48p4x provides high-bandwidth uplink connectivity for campus core switch aggregation, data center access layers, and large enterprise distribution networks utilizing the s5735.
3. High Switching Performance
The s5735-s48p4x delivers exceptional enterprise performance:
-
Switching Capacity: 176 Gbps / 432 Gbps (system capacity)
-
Forwarding Rate: 132 Mpps
-
The huawei s5735 s48p4x ensures stable performance under large-scale PoE device aggregation and high-definition video surveillance traffic.
4. High-Capacity PoE Power System
As a heavy-duty enterprise poe switch, the huawei s5735 s48p4x supports an industry-leading PoE power budget of up to 1600W when equipped with dual 1000W AC power modules. This makes the huawei cloudengine s5735 ideal for high-density WiFi 6 coverage and 4K CCTV systems.
5. Intelligent Stacking (iStack)
The cloudengine s5735 series supports stacking of up to 9 switches. Clustering your huawei s5735 s48p4x units enables unified network management and scalable campus expansion within the huawei s5735 ecosystem.
6. Enterprise Security Framework
The huawei s5735 s48p4x features multi-layer perimeter protection. Every huawei switch s5735 includes 802.1X authentication, DHCP Snooping, ARP Inspection, ACL access control policies, MAC filtering, and Port isolation to secure the edge.
Recommended Application Scenarios
The huawei cloudengine s5735 is highly adaptable. The huawei s5735 s48p4x configuration is highly recommended for:
-
Enterprise campus PoE access networks using the s5735-s48p4x.
-
WiFi 6 / WiFi 7 wireless AP deployment utilizing a 48 port poe switch.
-
CCTV surveillance monitoring systems powered by the huawei s5735 s48p4x.
-
Hotel guest room and public area networks standardizing on the huawei s5735.
-
University infrastructure running the huawei switch s5735.
-
Hospital digital systems leveraging the huawei s5735 s48p4x.
-
Smart city IoT infrastructure powered by an enterprise poe switch.
Recommended Accessories
To maximize the performance of your huawei switch s5735, pair your huawei s5735 s48p4x with genuine huawei s5735 accessories.
| Category | Product Model | Description |
|---|---|---|
| SFP+ Transceiver | SFP-10G-SR | 10G multimode fiber module, up to 300m short-reach connections |
| SFP+ Transceiver | SFP-10G-LR | 10G single-mode fiber module, up to 10km campus interconnect |
| SFP+ Transceiver | SFP-10G-ER | 10G extended reach module, up to 40km metro access networks |
| SFP+ Transceiver | SFP-10G-ZR | 10G ultra-long reach module, up to 80km backbone networks |
| Power Module | PAC1000S56-CB | 1000W AC PoE power module for high-density deployments |
| Power Module | PDC1000S56-CB | 1000W DC PoE power module for industrial environments |
| Cooling Module | FAN-023A-B | Hot-swappable fan module for thermal stability |
Comparison with Similar Items
| Feature | S5735-S48P4X | S5735-S24P4X | S5735-S48T4X |
|---|---|---|---|
| Downlink Ports | 48GE PoE+ | 24GE PoE+ | 48GE |
| Uplink Ports | 4 x 10GE SFP+ | 4 x 10GE SFP+ | 4 x 10GE SFP+ |
| PoE Support | Yes (up to 1600W) | Yes | No |
| Switching Capacity | 176 Gbps / 432 Gbps | 128 Gbps / 336 Gbps | 176 Gbps / 432 Gbps |
| Forwarding Rate | 132 Mpps | 96 Mpps | 132 Mpps |
| MAC Table | 32K entries | 32K entries | 32K entries |
| Power Architecture | Dual 1000W AC (1600W PoE budget) | Dual PSU | Dual PSU |
| Stacking | iStack (up to 9) | iStack | iStack |
| Ideal Use Case | High-density PoE / WiFi / CCTV | Medium PoE access | Non-PoE enterprise access |
Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | S5735-S48P4X | Enterprise Layer 3 high-density PoE+ access switch |
| Downlink Ports | 48 x 10/100/1000BASE-T PoE+ | Provides power and data for edge devices |
| Uplink Ports | 4 x 10GE SFP+ | High-speed uplink to core or aggregation network |
| Switching Capacity | 176 Gbps / 432 Gbps | System-level and device switching capability |
| Forwarding Rate | 132 Mpps | Packet forwarding performance under full load |
| MAC Address Table | 32K entries | Layer 2 MAC learning capacity |
| VLAN Support | 4094 VLANs (802.1Q) | Network segmentation and isolation |
| Routing Features | Static, RIP, OSPF, BGP, IS-IS | Full Layer 3 routing protocol suite |
| IPv6 Support | Full IPv6 stack | Next-generation network compatibility |
| QoS | 8 queues per port | Traffic prioritization for voice, video, and data |
| Security Features | 802.1X, ACL, DHCP Snooping, ARP Inspection | Enterprise access control and protection |
| Stacking | iStack up to 9 units | Logical switch clustering architecture |
| Management | Web / CLI / SNMP / SSH / RMON | Network monitoring and configuration |
| Power Supply | Dual 1000W AC modular PSU | Redundant high-power system |
| PoE Power Budget | Up to 1600W | High-density PoE device support capability |
| Power Consumption | Max 77W (device only), 1661W (full PoE load) | Accurate device and system power usage |
| Operating Temperature | 0°C to 50°C (short-term -5°C to 55°C) | Certified enterprise operating environment |
| Dimensions | 442 x 420 x 43.6 mm | Standard 1U rackmount chassis |
| Weight | 7.64 kg (with packaging) | Physical deployment weight |
| Warranty | Limited lifetime warranty | Enterprise-grade manufacturer assurance |
Why Choose Huawei S5735-S48P4X?
The Huawei S5735-S48P4X is designed for high-density PoE environments requiring large-scale device connectivity, high power delivery, and carrier-grade reliability.
It is particularly suitable for:
-
Large WiFi 6 AP deployment scenarios
-
High-density CCTV surveillance systems
-
Enterprise campus network infrastructure
-
Hotel and hospitality network systems
-
Smart building and IoT integration projects
-
Government and enterprise multi-tenant environments
With 1600W PoE capacity, 432 Gbps switching performance, and iStack scalability, it provides a robust foundation for modern converged access networks.
