Overview
The huawei cloudengine s5735 series introduces the s5735-s32st4x, a high-performance Layer 3 Gigabit hybrid access switch designed for enterprise campuses, ISP fiber access networks, metro Ethernet systems, smart cities, and converged fiber-copper infrastructures. This dynamic huawei s5735 switch combines 24 Gigabit SFP fiber ports, 8 Gigabit RJ45 copper ports, and 4 dedicated 10G SFP+ uplink slots.
This model excels as a flexible fiber access switch enabling seamless deployment in environments where fiber backbone networks and copper edge devices coexist. With enterprise-grade reliability, dual modular power redundancy, intelligent stacking (iStack), and advanced Layer 3 routing, the huawei switch s5735 is widely deployed across ISP access networks, hotel infrastructures, CCTV aggregation systems, and industrial IoT environments. The cloudengine s5735 architecture ensures maximum uptime, making the s5735 s32st4x the ultimate aggregation switch for modern convergence. The huawei s5735 delivers unparalleled scalability.
-
Related Reading & Architecture Resource Guides:
-
Evaluating Huawei for your core and access layers? Check out: Choosing the Best Huawei Switch: Efficient and Reliable Enterprise-Level Solutions.
-
Need help choosing 10G optics? Review: 10G SFP+ Transceivers Buying Guide: Huawei Compatible Modules.
-
Key Highlights
1. Hybrid Fiber + Copper Access Architecture
The s5735-s32st4x supports dual-media networking. The huawei cloudengine s5735 utilizes 24 GE SFP Fiber Ports for ISP access networks, campus backbone distribution, and metro Ethernet access layers utilizing the huawei s5735.
2. 8 x RJ45 Gigabit Ports
The s5735 s32st4x offers 8 copper ports for enterprise office endpoints, VoIP phones, and CCTV NVR systems connected to the huawei s5735 switch.
3. 4 x 10G SFP+ High-Speed Uplinks
As a true 10g uplink switch, the huawei switch s5735 provides high-bandwidth uplink connectivity for core switch aggregation and ISP backbone networks via the cloudengine s5735.
4. Enterprise Switching Performance
The s5735 delivers 144 Gbps / 432 Gbps system capacity and 108 Mpps forwarding rate. The huawei cloudengine s5735 ensures stable performance for high-density fiber access traffic.
5. Dual Modular Power Redundancy
This aggregation switch supports a 1+1 pluggable redundant power system for carrier-grade availability. Supported power modules for the huawei s5735 include PAC60S12-AR, PAC150S12-R, and PDC1000S12-DB.
6. Intelligent Stacking (iStack)
The huawei switch s5735 supports stacking of up to 9 devices, enabling unified management architecture across the s5735.
7. Enterprise Security Framework
Multi-layer protection on the cloudengine s5735 includes 802.1X authentication, DHCP Snooping, ARP Inspection, ACL policies, and MAC filtering. The huawei s5735 protects enterprise and ISP environments.
Recommended Application Scenarios
The huawei cloudengine s5735 is highly adaptable. The s5735-s32st4x configuration is highly recommended for:
-
ISP fiber access networks (FTTx / Metro Ethernet) using the fiber access switch.
-
Enterprise campus backbone & access layers relying on the huawei s5735.
-
Hotel structured wired + fiber networks unified by the s5735 s32st4x.
-
Education campus optical distribution systems running the huawei cloudengine s5735.
-
CCTV surveillance aggregation networks powered by the huawei switch s5735.
-
Smart city infrastructure networks managed by the s5735.
-
Healthcare and hospital systems utilizing the huawei s5735 switch.
-
Carrier edge deployments operating as a 10g uplink switch.
Recommended Accessories
To maximize the performance of your deployment, pair your huawei cloudengine s5735 with genuine compatible components.
| Category | Product Model | Description |
|---|---|---|
| SFP+ Transceiver | SFP-10G-SR | 10G multimode fiber module, up to 300m, short-reach intra-building |
| SFP+ Transceiver | SFP-10G-LR | 10G single-mode fiber module, up to 10km, campus interconnect |
| SFP+ Transceiver | SFP-10G-ER | 10G extended reach module, up to 40km, metro access networks |
| SFP Transceiver | SFP-GE-LX-SM1310 | 1G single-mode fiber module, up to 10km |
| SFP Transceiver | SFP-GE-SX-MM850 | 1G multimode fiber module, up to 550m |
| SFP Cable | CAB-SFP-1M / 3M / 5M | DAC cables for short-range rack interconnect |
| Power Module | PAC60S12-AR | 60W AC modular power unit |
| Power Module | PAC150S12-R | 150W AC modular power unit for standard deployments |
| Power Module | PDC180S12-CR | 180W DC modular power unit for industrial environments |
| Power Module | PDC1000S12-DB | 1000W DC high-capacity redundant power module |
Comparison with Similar Items
| Feature | S5735-S32ST4X | S5735-S24T4X | S5735-S48T4X |
|---|---|---|---|
| Downlink Ports | 24GE SFP + 8 x RJ45 | 24GE RJ45 | 48GE RJ45 |
| Uplink Ports | 4 x 10GE SFP+ | 4 x 10GE SFP+ | 4 x 10GE SFP+ |
| PoE Support | No | No | No |
| Switching Capacity | 144 / 432 Gbps | 128 / 336 Gbps | 176 / 432 Gbps |
| Forwarding Rate | 108 Mpps | 96 Mpps | 132 Mpps |
| Power Architecture | Dual modular PSU | Dual PSU | Dual PSU |
| Stacking | iStack (up to 9) | iStack | iStack |
| Ideal Use Case | ISP / Fiber access / Hybrid campus | Office LAN | High-density enterprise LAN |
Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | S5735-S32ST4X | Enterprise Layer 3 hybrid fiber-copper access switch |
| Downlink Ports | 24 x GE SFP + 8 x GE RJ45 | Mixed fiber and copper access for enterprise and ISP endpoints |
| Uplink Ports | 4 x 10GE SFP+ | High-speed uplink to core or aggregation networks |
| Switching Capacity | 144 Gbps / 432 Gbps | System and device switching capability |
| Forwarding Rate | 108 Mpps | Packet processing performance under full load |
| MAC Address Table | 32K entries | Layer 2 learning capacity for large-scale networks |
| VLAN Support | 4094 VLANs (802.1Q) | Network segmentation and multi-tenant isolation |
| Routing Features | Static, RIP, OSPF, BGP, IS-IS | Full Layer 3 routing protocol suite |
| IPv6 Support | Full IPv6 stack | Next-generation network compatibility |
| QoS | 8 queues per port | Traffic prioritization for voice/video/data |
| Security Features | 802.1X, ACL, DHCP Snooping, ARP Inspection | Enterprise access control and protection |
| Stacking | iStack up to 9 units | Logical switch clustering architecture |
| Management | Web / CLI / SNMP / SSH / RMON | Network monitoring and configuration |
| Power Supply | 1+1 pluggable modular PSU | Dual redundant hot-swappable power system |
| Power Consumption | 47W (30% load) / 49W (100% load) / 66W (Max) | Accurate operating and peak power values |
| Operating Temperature | 0°C to 50°C (short-term -5°C to 55°C) | Certified enterprise operating environment |
| Dimensions | 442 x 420 x 43.6 mm | Standard 1U rackmount chassis |
| Weight | 7.47 kg (with packaging) | Accurate deployment weight |
| Warranty | Limited lifetime warranty | Enterprise-grade manufacturer assurance |
Why Choose Huawei S5735-S32ST4X?
The Huawei S5735-S32ST4X is designed for carrier-grade hybrid access environments requiring fiber + copper integration with high availability power redundancy and scalable architecture.
-
True fiber + copper hybrid access design
-
Dual modular redundant power system for zero downtime risk
-
High-performance 432 Gbps switching capacity
-
Ideal for ISP, campus fiber, smart city, and metro Ethernet networks
-
4 x 10G uplinks for scalable backbone connectivity
-
iStack support for large-scale deployments
-
Strong security for multi-tenant ISP environments
-
Optimized for CCTV + VoIP + fiber aggregation convergence
