Huawei CloudEngine S5735-S24T4X 24-Port Gigabit Layer 3 Managed Switch with 4 x 10G SFP+ Uplinks
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Huawei CloudEngine S5735-S24T4X | 24-Port Gigabit Enterprise Access Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Overview
The huawei cloudengine s5735 series introduces the s5735 s24t4x, a high-performance Layer 3 gigabit access switch designed for enterprise campus networks. As a premier huawei s5735 switch, it provides 24 Gigabit RJ45 ports and 4 10G SFP+ uplinks, acting as a powerful 10ge uplink switch.
Unlike entry-level models, this huawei switch s5735 supports a dual modular power supply design. The cloudengine s5735 architecture ensures advanced Layer 3 routing and intelligent stacking. By deploying the huawei s5735, your business secures a highly reliable enterprise access switch. The s5735 s24t4x is widely used in CCTV backhaul networks, ISP access layers, and retail chains. The s5735 provides an excellent foundation. The huawei cloudengine s5735 guarantees stable connectivity as a 24 port gigabit switch.
Key Highlights
1. 24 Gigabit Access Ports
The s5735 s24t4x operates as a dense endpoint connection layer for enterprise PCs and VoIP IP phones.
2. 4 x 10G SFP+ Uplinks
The huawei s5735 switch provides high-speed uplinks to core network infrastructure.
3. Enterprise Performance
The cloudengine s5735 delivers 128 Gbps switching capacity. The huawei s5735 ensures stable video streams and multi-service convergence.
4. Dual Power Redundancy
The huawei switch s5735 supports 1+1 modular power. The s5735 s24t4x ensures zero downtime for mission-critical deployments.
5. Intelligent Stacking (iStack)
The huawei cloudengine s5735 enables iStack, allowing scalable network expansion across your facility.
6. Enterprise-Grade Security
The s5735 includes 802.1X authentication and MAC filtering. Every huawei s5735 switch is secure from unauthorized access.
7. Robust Thermal Design
The s5735 s24t4x operates reliably 24/7 with optimized fan management.
Recommended Application Scenarios
-
Enterprise LAN using the s5735 s24t4x.
-
Campus network backbone powered by the huawei cloudengine s5735.
-
Hotel wired networks running the huawei s5735.
-
ISP access layer aggregation leveraging the s5735.
Recommended Accessories
To maximize performance, pair your hardware with genuine compatible components.
| Category | Product Model | Description |
|---|---|---|
| SFP+ Transceiver | SFP-10G-SR | 10G multimode fiber module, up to 300m, intra-building connections |
| SFP+ Transceiver | SFP-10G-LR | 10G single-mode module, up to 10km, campus interconnect |
| SFP+ Transceiver | SFP-10G-ER | 10G extended reach module, up to 40km, metro access |
| SFP+ Transceiver | SFP-10G-ZR | 10G ultra-long reach module, up to 80km, backbone networks |
| Power Module | PAC60S12-AR | 60W AC power module for low-load configurations |
| Power Module | PDC180S12-CR | 180W DC power module for industrial power environments |
| Power Module | PDC1000S12-DB | 1000W DC high-capacity redundant power module |
| SFP+ Cable | CAB-SFP-1M | 1m DAC cable for short rack connections |
| SFP+ Cable | CAB-SFP-3M | 3m DAC cable for equipment room connections |
| SFP+ Cable | CAB-SFP-5M | 5m DAC cable for flexible deployment |
Comparison with Similar Items
| Feature | S5735-S24T4X | S5735-S24P4X | S5735-S48T4X |
|---|---|---|---|
| Downlink Ports | 24GE | 24GE PoE+ | 48GE |
| Uplink Ports | 4 x 10GE SFP+ | 4 x 10GE SFP+ | 4 x 10GE SFP+ |
| PoE Support | No | Yes (up to 1600W) | No |
| Switching Capacity | 128 / 336 Gbps | 128 / 336 Gbps | 176 / 432 Gbps |
| Forwarding Rate | 96 Mpps | 96 Mpps | 132 Mpps |
| Power Design | Dual modular PSU | Dual modular PSU | Dual modular PSU |
| Stacking | iStack (up to 9) | iStack | iStack |
| Ideal Use Case | Office / Campus / ISP access | PoE / CCTV / WiFi | High-density enterprise access |
Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | S5735-S24T4X | Enterprise Layer 3 Gigabit access switch |
| Downlink Ports | 24 x 10/100/1000BASE-T | Provides wired access for enterprise endpoints |
| Uplink Ports | 4 x 10GE SFP+ | High-speed fiber uplinks to aggregation/core layer |
| Switching Capacity | 128 Gbps / 336 Gbps | System-level forwarding bandwidth capability |
| Forwarding Rate | 96 Mpps | Packet processing capability under full load |
| MAC Address Table | 32K entries | Layer 2 address learning capacity |
| VLAN Support | 4094 VLANs (802.1Q) | Network segmentation for enterprise isolation |
| Routing Features | Static, RIP, OSPF, BGP, IS-IS | Layer 3 routing protocols for enterprise networks |
| IPv6 Support | Full IPv6 stack | Next-generation IP addressing support |
| QoS | 8 queues per port | Traffic prioritization for voice/video/data |
| Security Features | 802.1X, ACL, DHCP Snooping, ARP Inspection | Network access control and protection |
| Stacking | iStack up to 9 units | Multi-device logical switch architecture |
| Management | Web / CLI / SNMP / SSH / RMON | Enterprise network management tools |
| Power Supply | Dual modular PSU (1+1 redundancy) | Ensures continuous operation without single point of failure |
| Power Modules | PAC60S12-AR / PDC180S12-CR / PDC1000S12-DB | Flexible AC/DC redundant power options |
| Power Consumption | 31W typical / 46W max | Device operating power (without PoE load) |
| Operating Temperature | 0°C to 50°C (short-term -5°C to 55°C) | Certified enterprise operating environment |
| Dimensions | 442 x 420 x 43.6 mm | Standard 1U rackmount depth chassis |
| Weight | 7.21 kg (with packaging) | Accurate shipping and installation weight |
| Warranty | Limited lifetime warranty | Enterprise-grade manufacturer assurance |
Why Choose Huawei S5735-S24T4X?
The Huawei S5735-S24T4X is designed for enterprises requiring a high-reliability, non-PoE Layer 3 access switch with redundant power architecture.
-
Dual power redundancy for mission-critical uptime
-
Full Layer 3 routing for scalable enterprise networks
-
High-performance 336 Gbps system switching capacity
-
4 x 10G uplinks for future-proof backbone connectivity
-
iStack support for simplified network expansion
-
Optimized for office, campus, hotel, ISP, CCTV backhaul, and enterprise LANs
-
Carrier-grade Huawei reliability for long-term deployment
-
Ideal for environments where stability > PoE power requirement
