Overview
The huawei cloudengine s5735 series presents the s5735-l12t4s-a, an ultra-quiet, fanless Layer 2+ compact access switch featuring foundational Layer 3 routing capabilities. Purpose-built for small business networks, branch offices, retail environments, clinics, and classrooms, this 12 port gigabit switch delivers reliable wired connectivity without the disruptive noise of active cooling.
As a highly versatile huawei s5735 switch, it provides 12 Gigabit RJ45 Ethernet ports and 4 Gigabit SFP uplink ports, enabling high-speed copper access with flexible fiber uplinks to aggregation or core switches. Operating seamlessly as a cloud managed switch, the huawei switch s5735 drastically simplifies network O&M. Built with a 4-core 1000 MHz CPU and 1 GB memory, the s5735-l12t4s-a delivers strong business-class processing power. By integrating the huawei s5735 into your edge infrastructure, you secure enterprise-grade performance in a space-saving form factor. The s5735 architecture ensures maximum uptime, making the huawei cloudengine s5735 the definitive choice for noise-sensitive commercial deployments.
-
Related Reading & Architecture Resource Guides:
-
Evaluating Huawei vs Cisco for your SMB access layer? Check out: How to Choose the Best Gigabit Switch for SMBs in 2025 - Ruijie vs Huawei vs Cisco.
-
Learn more about access layer performance: Huawei Switch Management Features and Performance Analysis.
-
Key Highlights
1. 12 Gigabit Ethernet Access Ports
The s5735-l12t4s-a is a premium 12 port gigabit switch providing stable wired connectivity for office desktops, POS terminals, and printers. This huawei s5735 switch is ideal for reception areas and guest network devices.
2. 4 Gigabit SFP Fiber Uplinks
The cloudengine s5735 supports flexible fiber connectivity for building-to-building fiber links, floor-to-floor backbone uplinks, and retail chain store interconnects via the s5735.
3. Fanless Silent Design
The huawei s5735 relies on natural heat dissipation with zero fan noise. This makes the huawei cloudengine s5735 perfect for open-plan offices, libraries, clinics, and hotel front desk cabinets.
4. Enterprise Hardware Platform
Equipped with a 4-Core 1000 MHz CPU, 1 GB RAM, and a USB 2.0 interface, the s5735-l12t4s-a provides stable control-plane performance and convenient local file management for the s5735.
5. Layer 2+ & Basic Layer 3 Network Features
The huawei switch s5735 supports advanced business networking features, including static routing, RIP, and OSPF. This allows the huawei cloudengine s5735 to handle VLAN segmentation and IPv6 smoothly.
6. Cloud Managed Switch Capabilities
Operating as a cloud managed switch, the cloudengine s5735 supports centralized visibility. The huawei s5735 utilizes Web UI, CLI, SNMP, and RMON for unified administration.
7. Enterprise Security Protection
The huawei cloudengine s5735 includes 802.1X authentication, ACL policy control, DHCP Snooping, ARP Inspection, and MAC filtering. The s5735 actively protects internal networks from unauthorized access.
Recommended Application Scenarios
The highly adaptable s5735-l12t4s-a configuration is recommended for:
-
Small office networks standardizing on the huawei cloudengine s5735.
-
Retail chain stores requiring a compact access switch.
-
Hotel rooms and floor cabinets relying on the silent huawei s5735.
-
Branch office LAN deployment managed by the huawei switch s5735.
-
Classroom and campus access networks leveraging the s5735.
-
Clinics and healthcare offices powered by the huawei s5735 switch.
Recommended Accessories
To maximize the performance of your huawei switch s5735, pair your s5735-l12t4s-a with genuine huawei s5735 components.
| Category | Product Model | Description |
|---|---|---|
| SFP Transceiver | SFP-GE-LX-SM1310 | 1G single-mode fiber module, up to 10km uplink |
| SFP Transceiver | SFP-GE-SX-MM850 | 1G multimode fiber module, up to 550m short-range link |
| SFP Transceiver | SFP-GE-T | 1G RJ45 copper SFP module, up to 100m |
| SFP Cable | CAB-SFP-1M | 1m DAC cable for cabinet interconnect |
| SFP Cable | CAB-SFP-3M | 3m DAC cable for rack interconnect |
| SFP Cable | CAB-SFP-5M | 5m DAC cable for equipment room deployment |
Comparison with Similar Items
| Feature | S5735-L12T4S-A | S5735-L24T4S-A | S5735-L12P4S-A |
|---|---|---|---|
| Downlink Ports | 12GE RJ45 | 24GE RJ45 | 12GE PoE+ |
| Uplink Ports | 4GE SFP | 4GE SFP | 4GE SFP |
| PoE Support | No | No | Yes (360W) |
| Switching Capacity | 32 / 336 Gbps | 56 / 336 Gbps | 32 / 336 Gbps |
| Forwarding Rate | 24 Mpps | 42 Mpps | 24 Mpps |
| Fanless Design | Yes | Yes | No |
| Ideal Use Case | Quiet compact office access | Silent 24-port office LAN | WiFi / CCTV PoE access |
Specifications
| Parameter | Specification | Description |
|---|---|---|
| Model | S5735-L12T4S-A | Compact enterprise Layer 3 access switch |
| Downlink Ports | 12 x 10/100/1000BASE-T | Wired access ports for endpoints |
| Uplink Ports | 4 GE SFP | Fiber uplinks to aggregation/core |
| Switching Capacity | 32 Gbps / 336 Gbps | Device and system switching throughput |
| Forwarding Rate | 24 Mpps | Packet forwarding performance |
| CPU | 4-Core 1000 MHz | Hardware platform for system control and routing |
| Memory | 1 GB RAM | Supports stable enterprise switching operations |
| USB Port | USB 2.0 1 | Local upgrade, log export, and file backup |
| MAC Address Table | 32K entries | Supports large Layer 2 device scale |
| VLAN Support | Up to 4094 VLANs (802.1Q) | Network segmentation and isolation |
| Routing Features | Static routing, RIP, OSPF | Layer 3 traffic forwarding |
| IPv6 Support | Supported | Future-ready network compatibility |
| QoS | 8 queues per port | Prioritizes voice, video, and data |
| Security Features | 802.1X, ACL, DHCP Snooping, ARP Inspection | Access control and protection |
| Management | Web UI, CLI, SNMP, SSH, RMON | Monitoring and administration |
| Power Supply | Built-in AC power module | Integrated internal power system |
| Power Consumption | 23W (30% load) / 29W (Max) | Real operating and budget planning values |
| Operating Temperature | -5°C to 45°C | Suitable commercial deployment range |
| Dimensions | 442 x 220 x 43.6 mm | Rackmount chassis size |
| Weight | 3.83 kg | Installation and logistics reference |
| Warranty | Limited lifetime warranty | Manufacturer support coverage |
Why Choose Huawei S5735-L12T4S-A?
The Huawei S5735-L12T4S-A is an excellent choice for businesses needing a compact, quiet, and professional managed Gigabit switch with fiber uplink capability.
It is especially suitable for:
-
Small offices needing reliable wired access
-
Retail stores with POS and camera systems
-
Hotels requiring silent floor network cabinets
-
Clinics and medical branches
-
Schools and training rooms
-
Security control rooms
-
Meeting room wired connectivity
-
Branch offices with fiber uplinks
With fanless silent cooling, 12 Gigabit access ports, 4 SFP uplinks, enterprise hardware resources, Layer 3 management features, and strong security protection, it delivers dependable business networking in space-sensitive environments.
