Overview
The Huawei CloudEngine S5731-S24T4X is a high-performance Layer 3 Gigabit Ethernet switch designed for enterprise campus access, aggregation layers, and high-density data networks where PoE is not required.
It provides 24 Gigabit Ethernet data ports (non-PoE) and 410G SFP+ uplinks, enabling high-speed connectivity for servers, workstations, aggregation switches, and core network devices.
With a switching capacity of 128 Gbps / 672 Gbps, support for iStack stacking, and advanced technologies such as SVF (Super Virtual Fabric) and CampusInsight telemetry, the S5731-S24T4X delivers scalable, intelligent, and highly efficient network operations.
Highlights
-
24 1G Non-PoE Ports
-
4 10G SFP+ Uplinks
-
128 Gbps / 672 Gbps Switching Capacity
-
96 Mpps Forwarding Rate
-
iStack (up to 9 switches)
-
SVF (Super Virtual Fabric)
-
CampusInsight Telemetry
-
Layer 3 Routing - OSPF, IS-IS, BGP
Use Cases & Deployment Scenarios
1. Enterprise Office Networks: Connect desktops, printers, and internal systems
2. Data Center Access Layer: Server connectivity and rack-level switching
3. Aggregation Layer: Aggregate access switches via 10G uplinks
4. Campus Networks: Classrooms, labs, administrative buildings (non-PoE)
5. ISP Edge Networks: Cost-effective Layer 3 edge deployment
6. Industrial Networks: Stable connectivity for structured cabling systems
HCIE Engineer's Perspective
From a network architecture perspective, the S5731-S24T4X is a strategic replacement for PoE switches in non-powered segments, helping reduce both capital and operational costs.
The addition of SVF and telemetry capabilities allows it to function beyond a traditional access switch-enabling centralized fabric management and intelligent O&M, which is particularly valuable in large-scale campus deployments.
Deployment & Compatibility
-
Standard 1U rack-mount design
-
Compatible with:
-
Servers and storage systems
-
Enterprise routers and firewalls
-
Third-party switches and controllers
-
-
Ideal for:
-
Huawei-based networks
-
Multi-vendor enterprise environments
-
Recommended Accessories
| Model | Category | Description |
|---|---|---|
| SFP-10G-SR | Transceiver | 10G multimode (300m) |
| SFP-10G-LR | Transceiver | 10G single-mode (10km) |
| PAC150S12-R | Power Module | 150W AC power supply |
| PAC600S12-CB | Power Module | 600W AC power supply |
| PDC180S12-CR | Power Module | 180W DC power supply |
| Pluggable Dual Fans | Cooling | Built-in hot-swappable fans |
Comparison with Similar Models
| Model | Ports | PoE | Uplinks | Best For |
|---|---|---|---|---|
| S5731-S24T4X | 24GE | No | 410G | Data / aggregation |
| S5731-S24P4X | 24GE | Yes | 410G | PoE deployments |
| S5731-S48T4X | 48GE | No | 410G | High-density data |
Specifications
| Parameter | Specification |
|---|---|
| Model | S5731-S24T4X |
| Ports | 24 GE (Non-PoE) |
| Uplink | 4 x 10GE SFP+ |
| Switching Capacity | 128 Gbps / 672 Gbps |
| Forwarding Rate | 96 Mpps |
| MAC Address Table | 64K |
| VLAN | 4,096 |
| QoS | 8 queues per port |
| Routing | Static, RIP, OSPF, IS-IS, BGP |
| IPv6 | OSPFv3, BGP4+, IS-ISv6 |
| Stacking | iStack (9 switches) |
| Power Supply | AC/DC pluggable |
| Max Power | 124W |
| Temperature | -5°C to 45°C |
| Dimensions | 442 x 420 x 43.6 mm |
| Weight | 8.4 kg (with packaging) |
Why Choose S5731-S24T4X?
1. Cost-Efficient Non-PoE Deployment
-
No PoE hardware cost lower CAPEX
-
Reduced power consumption
Ideal for:
-
Office desktops and endpoints
-
Server racks and storage access
-
Aggregation layers
-
Structured cabling environments
2. 10G Uplinks for Aggregation & Core Connectivity
-
4 10G SFP+ uplinks
Ensures:
-
High-speed aggregation
-
No bottlenecks in data-heavy environments
-
Smooth connectivity to core switches
3. iStack + SVF for Simplified Architecture
-
iStack: up to 9 switches
-
SVF: transforms access switches into remote line cards
Benefits:
-
Centralized management
-
Reduced configuration complexity
-
Scalable campus architecture
4. Advanced Layer 3 Routing
Supports:
-
Static routing
-
RIP / OSPF / IS-IS
-
BGP
Suitable for:
-
Campus Layer 3 access
-
VLAN segmentation
-
Multi-site enterprise routing
5. Intelligent O&M with Telemetry (CampusInsight)
-
Real-time network monitoring
-
Fault detection and root cause analysis
-
AI-driven performance optimization
6. Enterprise Security & Control
-
802.1X authentication
-
DHCP snooping
-
Dynamic ARP inspection
-
MAC filtering
-
Port isolation
