HPE Aruba Networking JL356A 2540 24G PoE+ 4SFP+ Switch
Clique ou role para ampliar
Toque ou belisque para ampliar
HPE Aruba Networking JL356A 2540 24G PoE+ 4SFP+ Switch
Clique ou role para ampliar
Toque ou belisque para ampliar
HPE Aruba Networking JL356A 2540 24G PoE+ 4SFP+ Switch
HPE Aruba Networking JL356A 2540 24G PoE+ 4SFP+ Switch

HPE Aruba Networking JL356A 2540 24G PoE+ 4SFP+ Switch

por HPE Aruba
Desconto de 51%
R$ 39.420,00
R$ 19.470,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x
[shortdesc]
  • Managed, Rack-mountable, 24 x 1G PoE+ ports, 4 x 1G/10G SFP+ Uplinks, PoE+ (370W), Layer 2 with Static/RIP Routing
[/shortdesc]

[properties]

Properties HPE Aruba 2540 24G PoE+ 4SFP+ Switch (JL356A)
Description Managed Layer 2 switch with basic Layer 3 features, 24x 10/100/1000 PoE+ ports, and 4x 1/10GbE SFP+ uplink ports.
Product Family Aruba 2540 Switch Series
Product Type Ethernet Switch
I/O ports and slots 24 RJ-45 autosensing 10/100/1000 PoE+ ports
4 SFP+ 1/10GbE ports; PHY-less
Additional ports and slots 1 dual-personality (RJ-45 or USB micro-B) serial console port
Dimensions (H x W x D) 4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in) (1U height)
Weight 3.9 kg (8.6 lb)
Memory and processor Dual Core ARM Coretex A9 @ 1016 MHz, 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB (4.5MB Ingress/7.785 Egress), 4 GB eMMC

[/properties]

[specifications]

Performance
1000 Mb Latency < 3.8 µs (64-byte packets)
10 Gbps Latency < 1.6 µs (64-byte packets)
Throughput up to 95.2 Mpps
Switching capacity 128 Gbps
Routing table size 2,000 entries (IPv4), 1,000 entries (IPv6)
MAC address table size 16,384 entries
Environment
Operating temperature 0° to 45°C (32° to 113°F) up to 5,000 ft;
0° to 40°C (32° to 104°F) up to 10,000 ft
Acoustic Power: 54.1 dB, Pressure: 40.6 dB
Airflow Direction Side-to-side
Electrical
Frequency 50/60 Hz
Voltage 100-127 / 200-240 VAC, rated
Current 4.9/2.4 A
Maximum Power Rating 445 W
Idle Power 36.8 W
PoE Power 370 W PoE+
Safety and Emissions
Safety UL 60950-1 2nd Edition; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; IEC 60950-1:2005 +A1:2009 +A2:2013; CSA 22.2 No. 60950-1-07 2nd; EN 60825-1:2007/IEC 60825-1:2007 Class 1
Emissions VCCI Class A; CNS 13438; ICES-003 Class A; FCC CFR 47 Part 15, Class A; EN 55022: 2010/CISPR-22, Class A

[/specifications]

The HPE Aruba 2540 24G PoE+ 4SFP+ Switch (JL356A) is a fully managed Gigabit access layer switch built for the modern digital workplace. Designed to support mobile users and IoT devices, it delivers reliable connectivity, advanced security, and simplified management. With 24 Gigabit PoE+ ports and a total power budget of 370W, it efficiently powers IP phones, wireless access points, and security cameras. Four 10GbE SFP+ uplinks provide flexible, high-speed fiber connectivity, making it ideal for small to medium-sized enterprises, branch offices, and campus networks.

Key Features:

  • 24 x PoE+ Gigabit Ports: Up to 30W per port, with 370W total budget for powering APs, VoIP phones, and IP cameras.
  • 4 x 10GbE SFP+ Uplinks: Scalable high-speed fiber uplinks to support future network growth.
  • Layer 2 with Basic Layer 3 Services: Includes Static and RIP routing, VLANs, ACLs, and QoS for optimized traffic control.
  • Simplified Deployment & Management: Zero Touch Provisioning with support for Aruba AirWave, Aruba Central, CLI, and Web GUI.
  • Energy-Efficient: IEEE 802.3az compliance lowers power usage during low activity.

Technical Overview:

  • Recommended for: Small to medium-sized enterprises, campus access layers, branch offices, and IoT-heavy deployments.
  • Ports: 24 x 10/100/1000 PoE+ RJ-45, 4 x 1/10GbE SFP+ uplinks.
  • PoE Budget: 370W PoE+.
  • Switching Capacity: 128 Gbps.
  • Forwarding Rate: 95.2 Mpps.
  • Latency: <3.8 µs (1 Gb), <1.6 µs (10 Gb).
  • Management: Aruba Central, Aruba AirWave, CLI, Web GUI, SNMP.
  • Routing: Static and RIP routing support.
  • Memory/Processor: Dual Core ARM Cortex-A9 @ 1016 MHz; 1 GB DDR3 SDRAM; 12.38 MB packet buffer; 4 GB eMMC.
  • Operating Range: 0–45°C (32–113°F) up to 5,000 ft / 0–40°C (32–104°F) up to 10,000 ft.
  • Power Consumption: Max 445W; Idle 36.8W.
  • Dimensions/Weight: 4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in); 3.9 kg (8.6 lb).

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto
[shortdesc]
  • Managed, Rack-mountable, 24 x 1G PoE+ ports, 4 x 1G/10G SFP+ Uplinks, PoE+ (370W), Layer 2 with Static/RIP Routing
[/shortdesc]

[properties]

Properties HPE Aruba 2540 24G PoE+ 4SFP+ Switch (JL356A)
Description Managed Layer 2 switch with basic Layer 3 features, 24x 10/100/1000 PoE+ ports, and 4x 1/10GbE SFP+ uplink ports.
Product Family Aruba 2540 Switch Series
Product Type Ethernet Switch
I/O ports and slots 24 RJ-45 autosensing 10/100/1000 PoE+ ports
4 SFP+ 1/10GbE ports; PHY-less
Additional ports and slots 1 dual-personality (RJ-45 or USB micro-B) serial console port
Dimensions (H x W x D) 4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in) (1U height)
Weight 3.9 kg (8.6 lb)
Memory and processor Dual Core ARM Coretex A9 @ 1016 MHz, 1 GB DDR3 SDRAM; Packet buffer size: 12.38 MB (4.5MB Ingress/7.785 Egress), 4 GB eMMC

[/properties]

[specifications]

Performance
1000 Mb Latency < 3.8 µs (64-byte packets)
10 Gbps Latency < 1.6 µs (64-byte packets)
Throughput up to 95.2 Mpps
Switching capacity 128 Gbps
Routing table size 2,000 entries (IPv4), 1,000 entries (IPv6)
MAC address table size 16,384 entries
Environment
Operating temperature 0° to 45°C (32° to 113°F) up to 5,000 ft;
0° to 40°C (32° to 104°F) up to 10,000 ft
Acoustic Power: 54.1 dB, Pressure: 40.6 dB
Airflow Direction Side-to-side
Electrical
Frequency 50/60 Hz
Voltage 100-127 / 200-240 VAC, rated
Current 4.9/2.4 A
Maximum Power Rating 445 W
Idle Power 36.8 W
PoE Power 370 W PoE+
Safety and Emissions
Safety UL 60950-1 2nd Edition; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; IEC 60950-1:2005 +A1:2009 +A2:2013; CSA 22.2 No. 60950-1-07 2nd; EN 60825-1:2007/IEC 60825-1:2007 Class 1
Emissions VCCI Class A; CNS 13438; ICES-003 Class A; FCC CFR 47 Part 15, Class A; EN 55022: 2010/CISPR-22, Class A

[/specifications]

HPE Aruba 2540 24G PoE+ 4SFP+ Switch (JL356A)

The HPE Aruba 2540 24G PoE+ 4SFP+ Switch (JL356A) is a fully managed Gigabit access layer switch built for the modern digital workplace. Designed to support mobile users and IoT devices, it delivers reliable connectivity, advanced security, and simplified management. With 24 Gigabit PoE+ ports and a total power budget of 370W, it efficiently powers IP phones, wireless access points, and security cameras. Four 10GbE SFP+ uplinks provide flexible, high-speed fiber connectivity, making it ideal for small to medium-sized enterprises, branch offices, and campus networks.

Key Features:

  • 24 x PoE+ Gigabit Ports: Up to 30W per port, with 370W total budget for powering APs, VoIP phones, and IP cameras.
  • 4 x 10GbE SFP+ Uplinks: Scalable high-speed fiber uplinks to support future network growth.
  • Layer 2 with Basic Layer 3 Services: Includes Static and RIP routing, VLANs, ACLs, and QoS for optimized traffic control.
  • Simplified Deployment & Management: Zero Touch Provisioning with support for Aruba AirWave, Aruba Central, CLI, and Web GUI.
  • Energy-Efficient: IEEE 802.3az compliance lowers power usage during low activity.

Technical Overview:

  • Recommended for: Small to medium-sized enterprises, campus access layers, branch offices, and IoT-heavy deployments.
  • Ports: 24 x 10/100/1000 PoE+ RJ-45, 4 x 1/10GbE SFP+ uplinks.
  • PoE Budget: 370W PoE+.
  • Switching Capacity: 128 Gbps.
  • Forwarding Rate: 95.2 Mpps.
  • Latency: <3.8 µs (1 Gb), <1.6 µs (10 Gb).
  • Management: Aruba Central, Aruba AirWave, CLI, Web GUI, SNMP.
  • Routing: Static and RIP routing support.
  • Memory/Processor: Dual Core ARM Cortex-A9 @ 1016 MHz; 1 GB DDR3 SDRAM; 12.38 MB packet buffer; 4 GB eMMC.
  • Operating Range: 0–45°C (32–113°F) up to 5,000 ft / 0–40°C (32–104°F) up to 10,000 ft.
  • Power Consumption: Max 445W; Idle 36.8W.
  • Dimensions/Weight: 4.39 x 44.25 x 30.42 cm (1.73 x 17.42 x 11.98 in); 3.9 kg (8.6 lb).
