HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch
Clique ou role para ampliar
Toque ou belisque para ampliar
HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch
Clique ou role para ampliar
Toque ou belisque para ampliar
HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch
Clique ou role para ampliar
Toque ou belisque para ampliar
HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch
HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch

HPE Aruba Networking JL254A 2930F 48G 4SFP+ Switch

por HPE Aruba
Desconto de 73%
R$ 73.548,00
R$ 19.740,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc] 48× 10/100/1000 RJ-45, 4× 1/10GbE SFP+, Layer 3 (static/RIP/Access OSPF), VSF 8-member stacking, 176 Gbps switching, 112 Mpps throughput [/shortdesc]

[properties]

Model HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A)
Product Type Layer 3 stackable access switch
Ports 48× RJ-45 autosensing 10/100/1000
Uplink Ports 4× SFP+ 1/10GbE
Stacking Up to 8-member VSF
Switching Capacity 176 Gbps
Throughput Up to 112 Mpps
Latency <3.8 μs (1 Gb); <1.6 μs (10 Gb)
Power Consumption (Max) 46.6 W
Heat Dissipation 157.2 BTU/hr (165.8 kJ/hr)
Input Voltage 100–127/200–240 VAC, rated
Dimensions (H × W × D) 4.39 × 44.25 × 24.63 cm
Weight 3.1 kg

[/properties]

[specifications]

Product Number JL254A
Differentiator Popular 52-port Gig + 10G access switch; 48× 10/100/1000 + 4× 1/10G SFP+
PHY PHY-less
Processor / Memory Dual-core ARM Cortex-A9 @ 1016 MHz; 1 GB DDR3 SDRAM; 4 GB eMMC
Packet Buffer 12.38 MB total (4.5 MB ingress / 7.875 MB egress)
Latency <3.8 μs (1000 Mb); <1.6 μs (10 Gbps)
Throughput Up to 112 Mpps
Switching Capacity 176 Gbps
Management (selected) Aruba AirWave; Central (cloud); IMC; CLI; Web; Config menu; SNMP manager; Telnet; RMON1; FTP; Out-of-band mgmt (serial RS-232C or micro USB)
Stacking Aruba Virtual Switching Framework (VSF), up to 8 members
Out-of-Band Ethernet Mgmt Port Dedicated RJ-45 Ethernet interface for out-of-band management; no user/data traffic.
Input Voltage 100–127/200–240 VAC, rated
Max Power / Heat 46.6 W max; 157.2 BTU/hr
Dimensions / Weight 4.39 × 44.25 × 24.63 cm; 3.1 kg

[/specifications]

[accesories]

Optional Transceivers
Optional Mounting / Other

[/accesories]

The HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A) delivers enterprise-grade Layer 3 access with simple deployment and unified management. Built on Aruba’s ProVision ASIC, it provides low latency, robust QoS, and automation-ready interfaces to scale campus, SMB, and branch networks without extra software licenses. Virtual Switching Framework (VSF) enables up to eight switches to operate as one for resilient, easy-to-manage stacks.

  • Enterprise Layer 3: Supports static routing, RIP, and Access OSPF to segment and scale networks efficiently.
  • High-speed uplinks: Four 1/10GbE SFP+ slots provide flexible fiber uplinks for aggregation or core connectivity.
  • VSF stacking: Combine up to 8 members into a single logical device for simplified operations and failover resilience.
  • Performance ASIC: ProVision architecture delivers low latency, deep buffers, and SDN optimizations for busy edges.
  • Operations ready: Zero-Touch Provisioning, Aruba Central/AirWave support, and REST/OpenFlow APIs streamline rollouts and monitoring.
  • Enterprise access layers needing reliable Layer 3 segmentation and 10G uplinks.
  • Branch or retail sites consolidating multiple switches into a resilient VSF stack.
  • Education and healthcare networks requiring simple, license-free advanced features.
  • SMBs standardizing on Aruba Central or AirWave for unified wired/wireless management.
  • Model / SKU: JL254A
  • Access Ports: 48× RJ-45 autosensing 10/100/1000
  • Uplinks: 4× SFP+ 1/10GbE
  • Switching Capacity: 176 Gbps
  • Forwarding Throughput: Up to 112 Mpps
  • Latency: <3.8 μs (1G), <1.6 μs (10G)
  • Stacking: VSF up to 8 members
  • Management: CLI, Web GUI, SNMP, AirWave, Aruba Central, ZTP
  • Power Consumption (Max): 46.6 W
  • Dimensions / Weight: 4.39 × 44.25 × 24.63 cm; 3.1 kg

Equip your access layer with a fast, stackable Layer 3 switch that’s easy to deploy and manage. Request a quote or order today.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] 48× 10/100/1000 RJ-45, 4× 1/10GbE SFP+, Layer 3 (static/RIP/Access OSPF), VSF 8-member stacking, 176 Gbps switching, 112 Mpps throughput [/shortdesc]

[properties]

Model HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A)
Product Type Layer 3 stackable access switch
Ports 48× RJ-45 autosensing 10/100/1000
Uplink Ports 4× SFP+ 1/10GbE
Stacking Up to 8-member VSF
Switching Capacity 176 Gbps
Throughput Up to 112 Mpps
Latency <3.8 μs (1 Gb); <1.6 μs (10 Gb)
Power Consumption (Max) 46.6 W
Heat Dissipation 157.2 BTU/hr (165.8 kJ/hr)
Input Voltage 100–127/200–240 VAC, rated
Dimensions (H × W × D) 4.39 × 44.25 × 24.63 cm
Weight 3.1 kg

[/properties]

[specifications]

Product Number JL254A
Differentiator Popular 52-port Gig + 10G access switch; 48× 10/100/1000 + 4× 1/10G SFP+
PHY PHY-less
Processor / Memory Dual-core ARM Cortex-A9 @ 1016 MHz; 1 GB DDR3 SDRAM; 4 GB eMMC
Packet Buffer 12.38 MB total (4.5 MB ingress / 7.875 MB egress)
Latency <3.8 μs (1000 Mb); <1.6 μs (10 Gbps)
Throughput Up to 112 Mpps
Switching Capacity 176 Gbps
Management (selected) Aruba AirWave; Central (cloud); IMC; CLI; Web; Config menu; SNMP manager; Telnet; RMON1; FTP; Out-of-band mgmt (serial RS-232C or micro USB)
Stacking Aruba Virtual Switching Framework (VSF), up to 8 members
Out-of-Band Ethernet Mgmt Port Dedicated RJ-45 Ethernet interface for out-of-band management; no user/data traffic.
Input Voltage 100–127/200–240 VAC, rated
Max Power / Heat 46.6 W max; 157.2 BTU/hr
Dimensions / Weight 4.39 × 44.25 × 24.63 cm; 3.1 kg

[/specifications]

[accesories]

Optional Transceivers
Optional Mounting / Other

[/accesories]

High-Performance Layer 3 Access for Modern Edge Networks

The HPE Aruba Networking 2930F 48G 4SFP+ Switch (JL254A) delivers enterprise-grade Layer 3 access with simple deployment and unified management. Built on Aruba’s ProVision ASIC, it provides low latency, robust QoS, and automation-ready interfaces to scale campus, SMB, and branch networks without extra software licenses. Virtual Switching Framework (VSF) enables up to eight switches to operate as one for resilient, easy-to-manage stacks.

Key Benefits & Features
  • Enterprise Layer 3: Supports static routing, RIP, and Access OSPF to segment and scale networks efficiently.
  • High-speed uplinks: Four 1/10GbE SFP+ slots provide flexible fiber uplinks for aggregation or core connectivity.
  • VSF stacking: Combine up to 8 members into a single logical device for simplified operations and failover resilience.
  • Performance ASIC: ProVision architecture delivers low latency, deep buffers, and SDN optimizations for busy edges.
  • Operations ready: Zero-Touch Provisioning, Aruba Central/AirWave support, and REST/OpenFlow APIs streamline rollouts and monitoring.
Ideal Use Cases
  • Enterprise access layers needing reliable Layer 3 segmentation and 10G uplinks.
  • Branch or retail sites consolidating multiple switches into a resilient VSF stack.
  • Education and healthcare networks requiring simple, license-free advanced features.
  • SMBs standardizing on Aruba Central or AirWave for unified wired/wireless management.
Technical Specifications
  • Model / SKU: JL254A
  • Access Ports: 48× RJ-45 autosensing 10/100/1000
  • Uplinks: 4× SFP+ 1/10GbE
  • Switching Capacity: 176 Gbps
  • Forwarding Throughput: Up to 112 Mpps
  • Latency: <3.8 μs (1G), <1.6 μs (10G)
  • Stacking: VSF up to 8 members
  • Management: CLI, Web GUI, SNMP, AirWave, Aruba Central, ZTP
  • Power Consumption (Max): 46.6 W
  • Dimensions / Weight: 4.39 × 44.25 × 24.63 cm; 3.1 kg
Boost your edge with proven Aruba performance

Equip your access layer with a fast, stackable Layer 3 switch that’s easy to deploy and manage. Request a quote or order today.
