[shortdesc] Wi-Fi 7 tri-band 2.4 5 6 GHz, 2x2 spatial streams, 10G uplink, PoE PSE port, Bluetooth LE Zigbee [/shortdesc]

[properties]

Model FortiAP-23JK
SKU FAP-23JK-A
Product Type Wireless Access Point (Wall Plate)
Wireless Standard Wi-Fi 7 (IEEE 802.11be)
Frequency Bands 2.4 GHz, 5 GHz, 6 GHz
Spatial Streams 2x2 MU-MIMO
Radio Configuration Tri-band (3 Wi-Fi Radios) + BLE/Zigbee
Maximum Throughput 688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
Ethernet Interfaces 1 x 10GbE RJ45 (WAN/PoE), 2 x 1GE RJ45 (LAN), 1 x RJ45 Pass-through
PoE Support Input: 802.3bt (Preferred), Output: 1x 802.3af PSE
IoT Technologies Bluetooth Low Energy (BLE), ZigBee
Antenna Type Internal
Mounting Wall plate mountable
Color White
Dimensions (H × W × D) 1.6 × 4.7 × 7.1 in
Weight 18.34 oz
Operating Temperature 0 °C to 45 °C (32 °F to 113 °F)
Region Code A

[/properties]

[specifications]

Wireless LAN Standards 802.11a/b/g/n/ac/ax/be, Wi-Fi Certified 7
Modulation BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, OFDMA
MIMO Technology 2x2 MU-MIMO (uplink/downlink)
Authentication EAP-AKA, EAP-FAST, EAP-GTC, EAP-SIM, EAP-TLS, EAP-TTLS, PEAPv0, PEAPv1, MS-CHAP v2
Encryption WEP, WPA, WPA2, WPA3, TLS, TTLS
Security Features WIDS, WIPS, Rogue AP detection, MAC filtering, Captive Portal
Processor ARM Cortex-A53, 1.5 GHz
Memory 2 GB RAM
Maximum SSIDs Up to 24
Wireless Clients Up to 512 per Wi-Fi radio
Status Indicators Power, WAN, Wi-Fi
Operating Humidity 5% to 90% non-condensing
Certifications FCC, RoHS, UL 2043, EU Low Voltage Directive

[/specifications]

[accesories]

Included Wall plate mounting kit included in the box

[/accesories]

The Fortinet FortiAP-23JK Wall Plate Access Point is designed for high-density indoor deployments where performance, aesthetics, and flexibility matter. Built on Wi-Fi 7 technology, it delivers multi-gigabit wireless speeds while blending seamlessly into wall-mounted installations such as offices, hotels, classrooms, and residential units. With integrated switching ports and IoT radios, it reduces cabling complexity while extending secure connectivity to users and devices.

  • Wi-Fi 7 tri-band architecture: Operates across 2.4 GHz, 5 GHz, and 6 GHz bands with 2x2 spatial streams per band for improved capacity and reduced latency.
  • Integrated multi-port wall plate design: Includes one 10G Ethernet uplink, two active Gigabit Ethernet ports, and one RJ-45 pass-through port. One active port supports 802.3af PoE PSE to power downstream devices.
  • High-density client handling: Supports up to 24 configured SSIDs and up to 512 clients per radio, optimized for shared environments.
  • Built-in IoT radio support: Bluetooth Low Energy and Zigbee radios enable direct integration with IoT sensors and smart building devices.
  • Enterprise wireless security: Features WIDS and WIPS, rogue AP detection, WPA3 support, and advanced authentication methods for secure access.
  • Hotel rooms and hospitality guest networks
  • Enterprise offices and meeting spaces
  • University dormitories and classrooms
  • Healthcare and clinical environments
  • Smart buildings with IoT device integration
  • Wireless standard: Wi-Fi 7 (IEEE 802.11be)
  • Frequency bands: 2.4 GHz, 5 GHz, 6 GHz
  • Maximum throughput: 688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
  • Ethernet interfaces: 1 x 10G RJ45 (Uplink), 2 x 10/100/1000 RJ45 (LAN), 1 x Pass-through
  • PoE support: 802.3bt Input recommended; 1 x 802.3af PoE PSE output port
  • IoT connectivity: Bluetooth 5.2 LE, Zigbee
  • Antenna type: Internal antennas
  • Mounting: Wall plate mounting kit included
  • Form factor: Indoor wall mountable access point

Deploy next-generation wireless with a compact design built for performance and flexibility. Order today.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc] Wi-Fi 7 tri-band 2.4 5 6 GHz, 2x2 spatial streams, 10G uplink, PoE PSE port, Bluetooth LE Zigbee [/shortdesc]

[properties]

Model FortiAP-23JK
SKU FAP-23JK-A
Product Type Wireless Access Point (Wall Plate)
Wireless Standard Wi-Fi 7 (IEEE 802.11be)
Frequency Bands 2.4 GHz, 5 GHz, 6 GHz
Spatial Streams 2x2 MU-MIMO
Radio Configuration Tri-band (3 Wi-Fi Radios) + BLE/Zigbee
Maximum Throughput 688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
Ethernet Interfaces 1 x 10GbE RJ45 (WAN/PoE), 2 x 1GE RJ45 (LAN), 1 x RJ45 Pass-through
PoE Support Input: 802.3bt (Preferred), Output: 1x 802.3af PSE
IoT Technologies Bluetooth Low Energy (BLE), ZigBee
Antenna Type Internal
Mounting Wall plate mountable
Color White
Dimensions (H × W × D) 1.6 × 4.7 × 7.1 in
Weight 18.34 oz
Operating Temperature 0 °C to 45 °C (32 °F to 113 °F)
Region Code A

[/properties]

[specifications]

Wireless LAN Standards 802.11a/b/g/n/ac/ax/be, Wi-Fi Certified 7
Modulation BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, OFDMA
MIMO Technology 2x2 MU-MIMO (uplink/downlink)
Authentication EAP-AKA, EAP-FAST, EAP-GTC, EAP-SIM, EAP-TLS, EAP-TTLS, PEAPv0, PEAPv1, MS-CHAP v2
Encryption WEP, WPA, WPA2, WPA3, TLS, TTLS
Security Features WIDS, WIPS, Rogue AP detection, MAC filtering, Captive Portal
Processor ARM Cortex-A53, 1.5 GHz
Memory 2 GB RAM
Maximum SSIDs Up to 24
Wireless Clients Up to 512 per Wi-Fi radio
Status Indicators Power, WAN, Wi-Fi
Operating Humidity 5% to 90% non-condensing
Certifications FCC, RoHS, UL 2043, EU Low Voltage Directive

[/specifications]

[accesories]

Included Wall plate mounting kit included in the box

[/accesories]

Wall-Integrated Wi-Fi 7 Performance for Modern Indoor Networks

The Fortinet FortiAP-23JK Wall Plate Access Point is designed for high-density indoor deployments where performance, aesthetics, and flexibility matter. Built on Wi-Fi 7 technology, it delivers multi-gigabit wireless speeds while blending seamlessly into wall-mounted installations such as offices, hotels, classrooms, and residential units. With integrated switching ports and IoT radios, it reduces cabling complexity while extending secure connectivity to users and devices.

Key Benefits & Features
  • Wi-Fi 7 tri-band architecture: Operates across 2.4 GHz, 5 GHz, and 6 GHz bands with 2x2 spatial streams per band for improved capacity and reduced latency.
  • Integrated multi-port wall plate design: Includes one 10G Ethernet uplink, two active Gigabit Ethernet ports, and one RJ-45 pass-through port. One active port supports 802.3af PoE PSE to power downstream devices.
  • High-density client handling: Supports up to 24 configured SSIDs and up to 512 clients per radio, optimized for shared environments.
  • Built-in IoT radio support: Bluetooth Low Energy and Zigbee radios enable direct integration with IoT sensors and smart building devices.
  • Enterprise wireless security: Features WIDS and WIPS, rogue AP detection, WPA3 support, and advanced authentication methods for secure access.
Ideal Use Cases
  • Hotel rooms and hospitality guest networks
  • Enterprise offices and meeting spaces
  • University dormitories and classrooms
  • Healthcare and clinical environments
  • Smart buildings with IoT device integration
Technical Specifications
  • Wireless standard: Wi-Fi 7 (IEEE 802.11be)
  • Frequency bands: 2.4 GHz, 5 GHz, 6 GHz
  • Maximum throughput: 688 Mbps (2.4 GHz), 2.88 Gbps (5 GHz), 5.76 Gbps (6 GHz)
  • Ethernet interfaces: 1 x 10G RJ45 (Uplink), 2 x 10/100/1000 RJ45 (LAN), 1 x Pass-through
  • PoE support: 802.3bt Input recommended; 1 x 802.3af PoE PSE output port
  • IoT connectivity: Bluetooth 5.2 LE, Zigbee
  • Antenna type: Internal antennas
  • Mounting: Wall plate mounting kit included
  • Form factor: Indoor wall mountable access point
