[shortdesc]Firewall, 1RU rack mount, 4x 25GE SFP28, 4x 10GE SFP+, 17x GE RJ45, 42 Gbps IPS, dual DC PSU[/shortdesc]
[properties]
| Product Name | FortiGate 900G-DC |
| SKU | FG-900G-DC |
| Form Factor | Rack Mount, 1 RU |
| Firewall Throughput (Max) | 164 Gbps (1518 byte UDP) |
| Interfaces | 4x 25GE/10GE SFP28/SFP+ (ULL), 4x 10GE/GE SFP+/SFP, 8x GE SFP, 17x GE RJ45 (16x switch + 1x MGMT), 1x 2.5GE/GE HA RJ45 |
| Power Input | 48–60 VDC |
| Dimensions | 1.5 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm) |
| Weight | 16.53 lbs (7.5 kg) |
| Operating Temperature | 32°F to 113°F (0°C to 45°C) |
| Certifications | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6 |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) |
| IPS Throughput | 42 Gbps |
| NGFW Throughput | 31 Gbps |
| Threat Protection Throughput | 30 Gbps |
| System Performance and Capacity |
| IPv4 Firewall Throughput | 164 / 163 / 153 Gbps (1518/512/64 byte, UDP) |
| Firewall Throughput (Packet per Second) | 229.5 Mpps |
| Firewall Latency (64 byte UDP) | 3.78 / 2.5 μs (ULL ports) |
| Concurrent Sessions (TCP) | 16 Million |
| New Sessions/Second (TCP) | 720,000 |
| Firewall Policies | 50,000 |
| IPsec VPN Throughput (512 byte) | 55 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 2,000 |
| Client-to-Gateway IPsec VPN Tunnels | 50,000 |
| SSL-VPN Throughput | 10 Gbps |
| Concurrent SSL-VPN Users (Recommended Max) | 10,000 (Tunnel Mode) |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 16.7 Gbps |
| SSL Inspection CPS (IPS, avg. HTTPS) | 18,000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 1.6 Million |
| Application Control Throughput (HTTP 64K) | 74.8 Gbps |
| CAPWAP Throughput (HTTP 64K) | 133 Gbps |
| Virtual Domains (Default/Maximum) | 10 / 50 |
| Maximum Number of FortiSwitches Supported | 196 (FortiOS 7.6.1+ required for up to 196; prior releases support up to 96) |
| Maximum Number of FortiAPs (Total/Tunnel) | 2048 / 1024 |
| Maximum Number of FortiTokens | 5,000 |
| High Availability Configurations | Active-Active, Active-Passive, Clustering |
| Hardware and Interfaces |
| Hardware Accelerated 25 GE SFP28/10 GE SFP+ Slots | 4 |
| Hardware Accelerated 10 GE SFP+/GE SFP Slots | 4 |
| Hardware Accelerated GE SFP Slots | 8 |
| Hardware Accelerated GE RJ45 Slots | 16 |
| 2.5 GE/GE HA Port | 1 |
| GE Management Port | 1 |
| USB Ports (Client/Server) | 2 / 2 |
| Console Port | 1 |
| Trusted Platform Module (TPM) | Yes |
| Bluetooth Low Energy (BLE) | Yes |
| Dimensions and Power |
| Power Consumption (Average/Maximum) | 184 W / 323 W |
| Heat Dissipation | 1103 BTU/h |
| Redundant Power Supplies | Yes (Hot swappable; comes with 2 PSUs) |
| Operating Environment and Certifications |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | 58 dBA |
| Forced Airflow | Side and Front to Back |
| Operating Altitude | Up to 10,000 ft (3,048 m) |
[/specifications]
[accesories]
| Included Accessories | 2x SFP SX Transceivers, Default Dual Internal DC Power Supplies |
| Optional Accessories | DC Power Supply (SP-FG400F-DC-PS), 1 GE SFP Transceivers (LX, RJ45, SX), 10 GE SFP+ Transceivers (RJ45, SR, LR, ER, ZR, BiDi), 25 GE SFP28 Transceivers (SR, LR), Direct Attach Cables (10 GE SFP+, 25 GE SFP28) |
[/accesories]
The Fortinet FortiGate 900G-DC Series Next-Generation Firewall (NGFW) utilizes advanced artificial intelligence (AI) and machine learning (ML) to provide comprehensive threat protection at scale. Driven by Fortinet’s patented Network Processor 7 (NP7) and the ninth-generation Content Processor (CP9), this appliance delivers superior performance, including up to 42 Gbps of IPS throughput and 74.8 Gbps of Application Control throughput. Featuring dual DC power supplies, the FG-900G-DC is purpose-built to integrate seamlessly into telecom and service provider data center environments, ensuring continuous, high-speed security for massive traffic volumes.
Tailored for high-bandwidth infrastructures, the FortiGate 900G-DC offers an extensive and flexible interface set, including four 25 GE SFP28 slots, four 10 GE SFP+ slots, eight GE SFP slots, 17x GE RJ45 ports (including 1x management port and 16x switch ports), and a dedicated 2.5GE/GE HA port. It incorporates a Trusted Platform Module (TPM), a dedicated hardware module that hardens the appliance by generating, storing, and authenticating cryptographic keys. The redundant dual internal DC power supplies included by default provide the mission-critical uptime and high availability required in modern carrier networks and core enterprise facilities.
