FortiGate 30G Firewall, desktop, SD-WAN, 4x GE RJ45, up to 4/4/3.9 Gbps IPv4, incl. 3 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)
| Feature | Details |
| Bundle SKU | FG-30G-BDL-950-36 |
| Form Factor | Desktop |
| Included Service | 3 Year FortiCare Premium + FortiGuard Unified Threat Protection (UTP) |
| Firewall Throughput | Up to 4 / 4 / 3.9 Gbps (IPv4, 1518/512/64 byte, UDP) |
| Interfaces | 4x GE RJ45 ports (1x WAN, 2x GE RJ45 ports, 1x GE RJ45 FortiLink port (default)) |
| Threat Protection | Up to 500 Mbps |
| Power Input | 12VDC, 2A |
| Dimensions (H x W x L) | 1.6 x 5.6 x 6.3 inches (40.5 x 142 x 160 mm) |
| Weight | 1.3 lbs (0.6 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| System Performance & Capacity |
| IPS Throughput | 800 Mbps |
| NGFW Throughput | 570 Mbps |
| Firewall Latency | 2.87 μs |
| Concurrent Sessions (TCP) | 600,000 |
| New Sessions/Second (TCP) | 30,000 |
| Firewall Policies | 2,000 |
| VPN Performance |
| IPsec VPN Throughput (512 byte) | 3.5 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels | 200 |
| Client-to-Gateway IPsec VPN Tunnels | 250 |
| SSL Inspection Throughput | 400 Mbps |
| Hardware & Environment |
| Console Port | 1x RJ45 |
| Power Consumption (Average / Max) | 6.8 W / 8.2 W |
| Heat Dissipation | 28 BTU/hr |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 20% to 90% non-condensing |
| Noise Level | N/A |
| Compliance & Certifications | FCC, IC, CE, UL/cUL, CB, VCCI, BSMI, RCM, UKCA; Certifications: USGv6/IPv6 |
| Accessory Type | Description |
| Optional | Wall Mount Kit (SP-FG60F-MOUNT-20) pack of 20; AC Power Adaptor (SP-FG-30G-PA-10(-XX)) pack of 10 with interchangeable power plugs (XX=various countries code) |
The FortiGate 30G series runs on FortiOS, the industry's first converged networking and security operating system, enabling businesses to gain benefits of operational efficiency and unified protection. As a cornerstone of the Fortinet Security Fabric platform, the FortiGate Firewall works seamlessly with FortiGuard AI-Powered Security Services to deliver coordinated, automated, end-to-end threat protection in real time.
This bundle includes a 3-year subscription to FortiGuard Unified Threat Protection (UTP) and FortiCare Premium. FortiGuard UTP provides a curated bundle of security services, including IPS, Anti-Malware Protection (AMP), URL/DNS/Video Filtering, and Anti-Spam.
