- Hardware plus 24x7 FortiCare and FortiGuard Enterprise Protection, 3Yr Bundle
[/shortdesc]
[properties]
| Properties |
FG-40F-BDL-811-36 |
| Description |
5 x GE RJ45 ports (including 4 x Internal Ports, 1 x WAN Ports)
|
| Product Family |
Early Level Fortigate Firewalls
|
| Product Type |
Firewall |
| GE RJ45 Internal Ports |
4 |
| GE RJ45 WAN Port |
1 |
| USB Port |
1 |
| Console (RJ45) |
1 |
| Wireless Interface |
0 |
| Bundle |
24x7 FortiCare and FortiGuard Enterprise Protection
|
| Bundle Duration |
3 Year |
[/properties][specifications]
|
Firewall Throughput (1518 / 512 / 64 byte, UDP)
|
5 / 5 / 5 Gbps |
| Firewall Latency (64 byte UDP packets) |
2.97 μs |
| Firewall Throughput (Packets Per Second) |
7.5 Mpps |
| Concurrent Sessions (TCP) |
700.000 |
| New Sessions/Second (TCP) |
35.000 |
| Firewall Policies |
5.000 |
| IPsec VPN Throughput (512 byte packets) |
4.4 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
200 |
| Client-to-Gateway IPsec VPN Tunnels |
250 |
| SSL-VPN Throughput |
490 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) |
200 |
| IPS Throughput |
1 Gbps |
| SSL Inspection Throughput |
310 Mbps |
| Application Control Throughput |
990 Mbps |
| NGFW Throughput |
800 Mbps |
| Threat Protection Throughput |
600 Mbps |
| CAPWAP Throughput |
3.5 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
16 / 8 |
| Maximum Number of FortiTokens |
500 |
| Maximum Number of FortiSwitches Supported |
8 |
| High Availability Configurations |
Active/Active, Active/Passive, Clustering |
| Dimensions in. |
1.5 x 8.5 x 6.3 |
| Form Factor |
Desktop |
| Power Required |
100240V AC, 6050 Hz (External DC Power Adapter)
|
| Maximum Current |
100V AC / 0.2A, 240V AC / 0.1A
|
| Power Consumption (Average / Maximum) |
7.74 W / 9.46 W |
| Operating Temperature |
32104°F (040°C) |
| Regulatory Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
|
| Certifications |
Certifications USGv6/IPv6
|
[/specifications][accesories]
| SP-RACKTRAY-02 |
Rack mount tray for all FortiGate E series and F series desktop models are backwards compatible with SP-RackTray-01. For list of compatible FortiGate products, visit our Documentation website, docs.fortinet.com
|
|
| SP-FG-40F-PA-10(-XX |
Pack of 10 AC power adaptors for FG/FWF-40F, come with interchangeable power plugs. (XX=various countries code)
|
|
| SP-FG60F-MOUNT-20 |
Pack of 20 wall mount kits for FG/FWF-40F series, FG/FWF-60F series, FG-80F, FG-81F and FG-80F-Bypass
|
|
[/accesories]
5 x GE RJ45 ports (including , 1 x WAN Port, 4 x Internal Ports), Hardware plus 24x7 FortiCare and FortiGuard Enterprise Protection, 3Yr Bundle, 24x7 Comprehensive Support, Advanced Hardware Replacement (NBD), Firmware and General Upgrades, Enterprise Services Bundle (IPS, AV, Botnet IP/Domain, Mobile Malware, FortiGate Cloud Sandbox including Virus Outbreak and Content Disarm & Reconstruct, Application Control, Web Filtering, Antispam, Security Rating, Industrial Security and FortiConverter Service) plus term of contract
