[shortdesc] FortiGate firewall, DC-powered 1RU rackmount, 18x GE RJ45, 8x GE SFP, 8x 10GE SFP+, 10 Gbps NGFW, including 5 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]
[properties]
| Model / SKU | FG-400F-DC-BDL-950-60 |
| Bundle / Subscription | BDL-950: Hardware + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (5 Year) |
| Form Factor | Rack Mount, 1 RU |
| Firewall Throughput | 79.5 / 78.5 / 70 Gbps (IPv4 & IPv6, 1518 / 512 / 64 byte, UDP) |
| NGFW Throughput | 10 Gbps |
| Interfaces | 18x GE RJ45, 8x GE SFP, 8x 10GE SFP+ |
| Power Input | 48-60VDC |
| Dimensions (H x W x L) | 1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm) |
| Weight | 14.11 lbs (6.4 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Certifications | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB, USGv6/IPv6 |
[/properties]
[specifications]
| System Performance |
| IPS Throughput | 12 Gbps |
| Threat Protection Throughput | 9 Gbps |
| Firewall Latency (64 byte, UDP) | 4.19 μs / 2.5 μs (ULL ports) |
| Firewall Throughput (Packet per Second) | 105 Mpps |
| IPsec VPN Throughput (512 byte) | 55 Gbps |
| SSL-VPN Throughput | 3.6 Gbps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 8 Gbps |
| Application Control Throughput (HTTP 64K) | 28 Gbps |
| CAPWAP Throughput (HTTP 64K) | 65 Gbps |
| System Capacity |
| Concurrent Sessions (TCP) |
7.8 Million |
| New Sessions/Second (TCP) |
500,000 |
| Firewall Policies |
10,000 |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| Concurrent SSL-VPN Users (Recommended Max) |
5,000 |
| Virtual Domains (Default/Maximum) |
10 / 25 |
| Maximum Number of FortiSwitches Supported |
96 (FortiOS 7.6.1+; otherwise 72) |
| Maximum Number of FortiAPs (Total/Tunnel) |
512 / 256 |
| Maximum Number of FortiTokens |
5,000 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| Hardware & Interfaces |
| Hardware Accelerated GE RJ45 Interfaces |
16 |
| GE RJ45 Management Ports |
2 |
| Hardware Accelerated GE SFP Slots |
8 |
| Hardware Accelerated 10GE SFP+ Slots |
4 |
| Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots |
4 |
| USB Ports |
1 |
| RJ45 Console Port |
1 |
| Onboard Storage |
0 |
| Trusted Platform Module (TPM) |
Yes |
| Dimensions & Environment |
| Power Supply |
Dual DC power supplies |
| DC Current (Maximum) |
12A |
| Power Consumption (Average / Maximum) |
154.8 W / 189.2 W |
| Heat Dissipation |
645.58 BTU/h |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
5% to 90% non-condensing |
| Noise Level |
LPA 48 dBA / LWA 55 dBA |
| Forced Airflow |
Side and Front to Back |
| Operating Altitude |
Up to 10,000 ft (3048 m) |
| Compliance |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
[/specifications]
[accesories]
| Included Accessories |
| Included Transceivers | 2x SFP (SX 1 GE) |
| Optional Accessories (Sold Separately) |
| DC Power Supply |
SP-FG400F-DC-PS |
| Transceivers |
FN-TRAN-LX (1 GE SFP LX), FN-TRAN-GC (1 GE SFP RJ45), FN-TRAN-SX (1 GE SFP SX); FN-TRAN-SFP+GC (10 GE SFP+ RJ45), FN-TRAN-SFP+SR (10 GE SFP+ Short Range), FN-TRAN-SFP+LR (10 GE SFP+ Long Range), FN-TRAN-SFP+ER (10 GE SFP+ Extended Range), FN-TRAN-SFP+ZR (10 GE SFP+ 80KM extreme long range) |
| Cables |
FN-CABLE-SFP+1 (10 GE SFP+ Passive Direct Attach Cable, 1m), FN-CABLE-SFP+3 (3m), FN-CABLE-SFP+5 (5m) |
[/accesories]
The Fortinet FortiGate FG-400F-DC-BDL-950-60 bundle includes hardware plus FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for a 5 Year term. The Fortinet FortiGate 400F-DC is specifically engineered for data centers and telecommunications environments that rely on DC power infrastructure. This next-generation firewall combines AI-powered security and machine learning to deliver threat protection at scale. Powered by Fortinet's patented NP7 and CP9 SPUs, the FortiGate 400F-DC delivers 10 Gbps of NGFW throughput and ultra-low latency to support mission-critical applications.
With integrated Secure SD-WAN and universal ZTNA capabilities, this appliance simplifies network operations while reducing complexity in hybrid IT environments. It features 8x 10GE SFP+ slots, including 4 dedicated ultra-low latency slots, to help handle high-bandwidth traffic efficiently. The device is built with dual redundant DC power supplies to support continuous operation in demanding deployments.
