[shortdesc] Firewall, 1RU rackmount, 18x GE RJ45, 8x 10GE SFP+, 10 Gbps NGFW, including 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP) [/shortdesc]
[properties]
| Model / SKU | FG-400F-BDL-950-12 |
| Bundle / Subscription | Appliance + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (1 Year) |
| Form Factor | Rack Mount, 1 RU |
| Firewall Throughput | IPv4: 79.5 / 78.5 / 70 Gbps (1518/512/64 byte, UDP); IPv6: 79.5 / 78.5 / 70 Gbps (1518/512/64 byte, UDP) |
| NGFW Throughput | 10 Gbps |
| Interfaces | 18x GE RJ45 (1x MGMT, 1x HA, 16x switch ports), 8x GE SFP, 8x 10GE SFP+ (4 Ultra Low Latency) |
| AC Power Input | 100-240V AC, 50/60Hz |
| Height x Width x Length | 1.75 x 17.0 x 15.0 inches (44.45 x 432 x 380 mm) |
| Weight | 14.11 lbs (6.4 kg) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Certifications | USGv6/IPv6 |
[/properties]
[specifications]
| System Performance |
| IPS Throughput | 12 Gbps |
| Threat Protection Throughput | 9 Gbps |
| IPv4 Firewall Throughput (1518/512/64 byte, UDP) | 79.5 / 78.5 / 70 Gbps |
| IPv6 Firewall Throughput (1518/512/64 byte, UDP) | 79.5 / 78.5 / 70 Gbps |
| Firewall Latency (64 byte, UDP) | 4.19 μs / 2.5 μs (ULL ports) |
| Firewall Throughput (Packet per Second) | 105 Mpps |
| IPsec VPN Throughput (512 byte) | 55 Gbps |
| SSL-VPN Throughput | 3.6 Gbps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 8 Gbps |
| Application Control Throughput (HTTP 64K) | 28 Gbps |
| CAPWAP Throughput (HTTP 64K) | 65 Gbps |
| System Capacity |
| Concurrent Sessions (TCP) |
7.8 Million |
| New Sessions/Second (TCP) |
500,000 |
| Firewall Policies |
10,000 |
| Gateway-to-Gateway IPsec VPN Tunnels |
2,000 |
| Client-to-Gateway IPsec VPN Tunnels |
50,000 |
| Concurrent SSL-VPN Users (Recommended Max) |
5,000 |
| Virtual Domains (Default/Maximum) |
10 / 25 |
| Maximum Number of FortiSwitches Supported |
96 (FortiOS 7.6.1+) |
| Maximum Number of FortiAPs (Total/Tunnel) |
512 / 256 |
| Maximum Number of FortiTokens |
5,000 |
| High Availability Configurations |
Active-Active, Active-Passive, Clustering |
| Hardware & Interfaces |
| Hardware Accelerated GE RJ45 Interfaces |
16 |
| GE RJ45 Management Ports |
2 |
| Hardware Accelerated GE SFP Slots |
8 |
| Hardware Accelerated 10GE SFP+ Slots |
4 |
| Hardware Accelerated 10GE SFP+ Ultra Low Latency Slots |
4 |
| USB Ports |
1 |
| RJ45 Console Port |
1 |
| Onboard Storage |
0 |
| Dimensions & Environment |
| Power Supply |
Redundant hot-swappable dual AC power supplies (1+1 redundancy) |
| AC Current (Maximum) |
6A |
| Power Consumption (Average / Maximum) |
154.8 W / 189.2 W |
| Heat Dissipation |
645.58 BTU/h |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
5% to 90% non-condensing |
| Noise Level |
LPA 48 dBA / LWA 55 dBA |
| Forced Airflow |
Side and Front to Back |
| Operating Altitude |
Up to 10,000 ft (3048 m) |
| Compliance |
FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
[/specifications]
[accesories]
| Included Accessories |
| Included Transceivers | 2x SFP (SX 1 GE) |
| Optional Accessories (Sold Separately) |
| AC Power Supply | SP-FG400F-PS |
| DC Power Supply | SP-FG400F-DC-PS |
| Transceivers | 1 GE SFP LX (FN-TRAN-LX); 1 GE SFP RJ45 (FN-TRAN-GC); 1 GE SFP SX (FN-TRAN-SX); 10 GE SFP+ RJ45 (FN-TRAN-SFP+GC); 10 GE SFP+ SR (FN-TRAN-SFP+SR); 10 GE SFP+ LR (FN-TRAN-SFP+LR); 10 GE SFP+ ER (FN-TRAN-SFP+ER); 10 GE SFP+ ZR 80KM (FN-TRAN-SFP+ZR) |
| Cables | 10 GE SFP+ Passive Direct Attach Cable: 1m (FN-CABLE-SFP+1), 3m (FN-CABLE-SFP+3), 5m (FN-CABLE-SFP+5) |
[/accesories]
The Fortinet FortiGate 400F Series Next-Generation Firewall (NGFW) combines AI-powered security and machine learning to deliver threat protection at any scale. This FG-400F-BDL-950-12 bundle includes FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 1 Year. Powered by Fortinet's patented NP7 and CP9 SPUs, it provides 10 Gbps of NGFW throughput and ultra-low latency, making it ideal for enterprise campus and branch deployments. The solution integrates seamlessly into the Fortinet Security Fabric, offering deep visibility into applications, users, and devices beyond traditional firewall techniques.
This rackmount appliance is designed to reduce complexity in hybrid IT networks through secure SD-WAN and network segmentation. With universal ZTNA, the FortiGate 400F automatically controls, verifies, and facilitates user access to applications, reducing lateral threats by providing access only to validated users. The device supports dual hot-swappable power supplies for mission-critical reliability and includes specialized ultra-low latency ports for demanding environments.
