[shortdesc]Firewall, DC power 2RU, 4x 100GE QSFP28, 16x 25GE SFP28, IPS 31 Gbps, including 1 Year FortiCare Premium and FortiGuard Unified Threat Protection (UTP)[/shortdesc]
[properties]
| Product SKU | FG-2600F-DC-BDL-950-12 |
| Bundle / Subscription | Appliance + FortiCare Premium + FortiGuard Unified Threat Protection (UTP) (1 Year) |
| Form Factor | Rack Mount, 2RU |
| IPS Throughput | 31 Gbps |
| NGFW Throughput | 27 Gbps |
| Threat Protection Throughput | 25 Gbps |
| Interfaces | 4x 100GE/40GE QSFP28 slots, 16x 25GE/10GE SFP28 slots, 8x 10GE SFP+ slots, 16x 10GE RJ45 ports, 2x 10G SFP+ HA slots, 2x 1G MGMT ports |
| Dimensions (H x W x L) | 3.5 x 17.25 x 21.1 inches (88.4 x 438 x 536 mm) |
| Weight | 30.6 lbs (13.9 kg) |
| Power Input | -48VDC to -60VDC |
[/properties]
[specifications]
| System Performance |
| IPv4 Firewall Throughput (1518/512/64 byte, UDP) | 198 / 196 / 140 Gbps |
| IPv6 Firewall Throughput (1518/512/86 byte, UDP) | 198 / 196 / 140 Gbps |
| Firewall Latency (64 byte, UDP) | 3.41 μs |
| Firewall Throughput (Packet per Second) | 210 Mpps |
| IPsec VPN Throughput (512 byte) | 55 Gbps |
| SSL-VPN Throughput | 16 Gbps |
| SSL Inspection Throughput (IPS, avg. HTTPS) | 20 Gbps |
| Application Control Throughput (HTTP 64K) | 64 Gbps |
| CAPWAP Throughput (HTTP 64K) | 62.5 Gbps |
| System Capacity |
| Concurrent Sessions (TCP) | 24 Million / 40 Million* |
| New Sessions/Second (TCP) | 1 Million / 2 Million* |
| Firewall Policies | 100,000 |
| Gateway-to-Gateway IPsec VPN Tunnels | 20,000 |
| Client-to-Gateway IPsec VPN Tunnels | 100,000 |
| Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) | 30,000 |
| Virtual Domains (Default / Maximum) | 10 / 500 |
| Hardware & Interfaces |
| 100 GE QSFP28 / 40 GE QSFP+ Slots | 4 |
| 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots | 16 |
| 10 GE SFP+ Slots | 8 |
| 10 GE / GE RJ45 Ports | 16 |
| 10 GE SFP+ / GE SFP HA Slots | 2 |
| GE RJ45 Management Ports | 2 |
| USB 3.0 Port | 1 |
| Console RJ45 Port | 1 |
| Trusted Platform Module (TPM) | Included |
| Environment & Power |
| Power Supply | Dual DC Power Supplies (-48VDC to -60VDC) |
| Power Consumption (Average / Maximum) | 416 W / 510 W |
| DC Current (Average / Maximum) | 15A@48V, 9A@240V |
| Heat Dissipation | 1740 BTU/h |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Storage Temperature | -31°F to 158°F (-35°C to 70°C) |
| Humidity | 10% to 90% non-condensing |
| Noise Level | 71.72 dBA |
| Operating Altitude | Up to 10,000 ft. (3048 m) |
| Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
| Certifications | USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories | Rack Mount Sliding Rails (SP-FG3040B-RAIL)
DC Power Supply (SP-FG1800F-DC-PS)
Hyperscale Firewall License (LIC-FGT-HYPSC-1K2K)
1 GE SFP LX Transceiver (FN-TRAN-LX)
1 GE SFP RJ45 Transceiver (FN-TRAN-GC)
1 GE SFP SX Transceiver (FN-TRAN-SX)
10 GE SFP+ RJ45 Transceiver (FN-TRAN-SFP+GC)
10 GE SFP+ Transceiver SR (FN-TRAN-SFP+SR)
10 GE SFP+ Transceiver LR (FN-TRAN-SFP+LR)
10 GE SFP+ Transceiver ER (FN-TRAN-SFP+ER)
25 GE SFP28 Transceiver SR (FN-TRAN-SFP28-SR)
25 GE SFP28 Transceiver LR (FN-TRAN-SFP28-LR)
40 GE QSFP+ Transceiver SR (FN-TRAN-QSFP+SR)
40 GE QSFP+ Transceiver LR (FN-TRAN-QSFP+LR)
100 GE QSFP28 Transceiver SR (FN-TRAN-QSFP28-SR)
100 GE QSFP28 Transceiver LR (FN-TRAN-QSFP28-LR)
100 GE QSFP28 BIDI Transceiver (FN-TRAN-QSFP28-BIDI) |
[/accesories]
The FortiGate 2600F-DC is engineered to provide security-driven networking for large enterprises, service providers, and data centers requiring DC power infrastructure. Powered by Fortinet’s proprietary SPU NP7 (Network Processor) and CP9 (Content Processor), this appliance delivers hyperscale performance, including 31 Gbps IPS throughput and up to 198 / 196 / 140 Gbps IPv4 firewall throughput (1518/512/64 byte, UDP), ensuring that security never becomes a bottleneck in high-speed environments.
This bundle includes the appliance plus FortiCare Premium and FortiGuard Unified Threat Protection (UTP) for 1 Year.
With a robust set of interfaces including 100 GE QSFP28, 25 GE SFP28, and additional 10 GE SFP+ slots specific to the DC model, the FG-2600F-DC simplifies network architecture by reducing the need for additional switches or bridges. It supports consolidated security functions, integrated Zero Trust Network Access (ZTNA) enforcement, and ultra-scalable, low latency, VXLAN segmentation, making it an ideal solution for securing hybrid clouds, telco edges, and core networks.
