[shortdesc]
- Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP), 3Yr Bundle
[/shortdesc]
[properties]
| Properties |
FG-200E-BDL-950-36 |
| Description |
18x GE RJ45 (including 2x WAN ports, 1x Mgmt port, 1x HA port, 14x switch ports), 4x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated.
|
| Product Family |
Mid Range Firewalls |
| Product Type |
Firewall |
| GE RJ45 Ports |
14 |
| GE RJ45 Management/DMZ/HA Ports |
2 |
| GE RJ45/SFP Shared Media Pairs |
4 |
| GE RJ45 WAN Port |
2 |
| USB Port |
1 |
| Console (RJ45) |
1 |
| Wireless Interface |
0 |
| Bundle |
24x7 FortiCare and FortiGuard Unified Threat Protection (UTP)
|
| Bundle Duration |
3 Years |
[/properties][specifications]
|
Firewall Throughput (1518 / 512 / 64 byte, UDP)
|
20 / 20 / 9 Gbps |
| Firewall Latency (64 byte UDP packets) |
3 μs |
| Firewall Throughput (Packets Per Second) |
13.5 Mpps |
| Concurrent Sessions (TCP) |
2 Million |
| New Sessions/Second (TCP) |
135.000 |
| Firewall Policies |
10.000 |
| IPsec VPN Throughput (512 byte packets) |
7.2 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
2000 |
| Client-to-Gateway IPsec VPN Tunnels |
10000 |
| SSL-VPN Throughput |
900 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) |
500 |
| SSL Inspection Throughput |
820 Mbps |
| SSL Inspection CPS (IPS, avg. HTTPS) |
1000 |
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) |
240000 |
| Application Control Throughput |
3.5 Gbps |
| IPS Throughput |
2.2 Gbps |
| NGFW Throughput |
1.8 Gbps |
| Threat Protection Throughput |
1.2 Gbps |
| CAPWAP Throughput |
1.5 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiSwitches Supported |
64 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
256 / 128 |
| Maximum Number of FortiTokens |
5000 |
| Maximum Number of Registered FortiClients |
- |
| High Availability Configurations |
Active/Active, Active/Passive, Clustering |
| Dimensions in. |
1.75 x 17.0 x 11.9 |
| Form Factor |
Rack Mount, 1 RU |
| Power Required |
100240V AC, 5060 Hz |
| Maximum Current |
100V / 3A, 240V / 0.42A |
| Power Consumption (Average / Maximum) |
70.98 / 109.9 W |
| Operating Temperature |
32104°F (040°C) |
| Regulatory Compliance |
FCC Part 15B, Class A, CE, RCM, VCCI, UL/ cUL, CB, BSMI
|
| Certifications |
USGv6/IPv6 |
[/specifications][accesories]
| FN-TRAN-GC |
1 GE SFP RJ45 transceiver module for all systems with SFP and SFP/SFP+slots.
|
| FN-TRAN-SX |
1 GE SFP SX transceiver module for all systems with SFP and SFP/SFP+ slots
|
| FN-TRAN-LX |
1 GE SFP LX transceiver module for all systems with SFP and SFP/SFP+ slots.
|
[/accesories]
18 x GE RJ45 (including 2 x WAN ports, 1 x MGMT port, 1 X HA port, 14 x switch ports), 4 x GE SFP slots. SPU NP6Lite and CP9 hardware accelerated., Hardware plus 24x7 FortiCare and FortiGuard Unified Threat Protection (UTP), 3Yr Bundle, 24x7 Comprehensive Support, Advanced Hardware Replacement (NBD), Firmware and General Upgrades, UTP Services Bundle (IPS, AV, Botnet IP/Domain, Mobile Malware, FortiGate Cloud Sandbox including Virus Outbreak and Content Disarm & Reconstruct, Application Control, Web Filtering and Antispam Service) plus term of contract.
This product has been discontinued.
