[shortdesc]Firewall, 2RU rack, 198 Gbps, NP7/CP9 SPU, 2x100GE + 8x25GE, including 3 Year FortiCare Premium and FortiGuard Enterprise Protection[/shortdesc]
[properties]
| Product Name | FortiGate 1000F |
| SKU | FG-1000F-BDL-809-36 |
| Bundle / Subscription | Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year) |
| Form Factor | Rack Mount, 2 RU |
| Firewall Throughput (IPv4) | 198 Gbps |
| Interfaces | 2x 100 GE QSFP28, 8x 25 GE SFP28, 16x 10 GE SFP+, 8x 10 GE RJ45 (Multi-rate) |
| Power Input | 100–240 VAC, 50/60 Hz |
| Dimensions (H x W x L) | 88.9 mm x 443 mm x 447.4 mm (3.5 in x 17.44 in x 17.63 in) |
| Weight | 9.95 kg (21.94 lbs) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Certifications | FCC Part 15 Class A, CE, RCM, VCCI, UL/cUL, CB, USGv6/IPv6 |
[/properties]
[specifications]
| System Performance & Capacity |
| IPv4 Firewall Throughput (1518 / 512 / 64 byte UDP) | 198 / 196 / 134 Gbps |
| IPv6 Firewall Throughput (1518 / 512 / 86 byte UDP) | 198 / 196 / 134 Gbps |
| Firewall Latency (64 byte UDP) | 3.45 µs |
| Firewall Throughput (Packets Per Second) | 201 Mpps |
| IPS Throughput | 19 Gbps |
| NGFW Throughput | 15 Gbps |
| Threat Protection Throughput | 13 Gbps |
| IPsec VPN Throughput (512 byte) | 55 Gbps |
| SSL-VPN Throughput | 5.3 Gbps |
| SSL Inspection Throughput (IPS, avg HTTPS) | 10 Gbps |
| Application Control Throughput (HTTP 64K) | 44 Gbps |
| Concurrent Sessions (TCP) | 7.5 Million |
| New Sessions/Second (TCP) | 650,000 |
| Firewall Policies | 100,000 |
| IPsec VPN Tunnels (Gateway-to-Gateway) | 20,000 |
| Virtual Domains (Default / Max) | 10 / 250 |
| Hardware Specifications |
| 100 GE QSFP28 / 40 GE QSFP+ Slots | 2 |
| 25 GE SFP28 / 10 GE SFP+ / GE SFP Slots | 8 |
| 10 GE SFP+ / GE SFP Slots | 16 |
| 10 GE / 5 GE / 2.5 GE / GE / 100M RJ45 Ports | 8 |
| Management / HA Ports | 1x GE RJ45 MGMT, 1x 2.5 GE / GE HA |
| USB / Console Ports | 2x USB, 1x Console |
| Trusted Platform Module (TPM) | Included |
| Environment & Power |
| Power Supply | Dual AC (Hot Swappable), 100-240VAC, 50/60 Hz |
| Power Consumption (Average / Max) | 210 W / 408 W |
| Heat Dissipation | 1211 BTU/h |
| Noise Level | 66.7 dBA |
| Operating Altitude | Up to 10,000 ft (3048 m) |
| Compliance | FCC Part 15 Class A, RCM, VCCI, CE, UL/cUL, CB |
[/specifications]
[accesories]
| Included Accessories | 2x SFP SX Transceivers |
| Optional Accessories | Rack Mount Sliding Rails (SP-FG3040B-RAIL), AC Power Supply (SP-FG400F-PS), 100 GE QSFP28 Transceivers, 25 GE SFP28 Transceivers, 10 GE SFP+ Transceivers |
[/accesories]
The FortiGate 1000F Series delivers ultra-high-performance Next-Generation Firewall (NGFW) capabilities designed for large enterprises and service providers. Powered by Fortinet’s patented SPU NP7 and CP9 hardware acceleration, the FG-1000F achieves breakthrough speeds with up to 198 Gbps of firewall throughput and 19 Gbps of IPS performance. This appliance serves as the foundation for a robust Hybrid Mesh Firewall architecture, weaving deep security into data centers and across hybrid IT environments to protect any edge at any scale.
The FortiGate 1000F Series is engineered for hyperscale security, offering deep visibility and protection for data centers and hybrid IT architectures. Utilizing Fortinet’s custom SPU NP7 network processors, the 1000F delivers offloaded performance for VXLAN, IPsec, and firewall functions, ensuring that security never becomes a network bottleneck. The appliance supports native 100 GE connectivity to simplify network designs without relying on additional bridges or switches.
Integrated with AI/ML-powered FortiGuard Services, the FG-1000F detects and prevents known and unknown attacks, including ransomware and zero-day threats. It features the industry's first integrated Zero Trust Network Access (ZTNA) enforcement within an NGFW solution, automatically verifying user access to applications for a seamless and secure user experience.
This bundle includes Hardware + FortiCare Premium + FortiGuard Enterprise Protection (3 Year).
