Fluke-77-IV Industrial Digital Multimeter
Fluke-77-IV Industrial Digital Multimeter

Fluke-77-IV Industrial Digital Multimeter

por Fluke
R$ 4.200,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

  • Fluke 77-IV is a versatile digital multimeter designed for industrial maintenance, field service, and bench repair, featuring high accuracy and robust safety compliance

[/shortdesc]

[properties]

Property
Model Fluke 77-IV
Product Type Digital Multimeter
Display 6000-count digital display with 33-segment bar graph
Voltage Measurement Range Up to 1000 V (AC/DC)
Current Measurement Range Up to 10 A (for 30 seconds)
Continuity Test Audible beep <25 Ω, detects 250 µs opens/shorts
Resistance Measurement Up to 50 MΩ
Capacitance Measurement Up to 9999 µF
Frequency Measurement 2 Hz to 99.99 kHz (AC voltage input)
MIN/MAX/AVG Function Available for tracking signal variation
Safety Compliance CAT III 1000 V, CAT IV 600 V
EMC Compliance EN 61326-1
Power Source 9V battery (installed)
Battery Life 400 hours typical (alkaline)
Dimensions (H x W x L) 4.3 x 9 x 18.5 cm
Weight 420 g
Operating Temperature -10°C to +50°C
Storage Temperature -40°C to +60°C
Operating Altitude 2000 m
Storage Altitude 12,000 m

[/properties]


[specifications]

Specification
DC Voltage 0.1 mV to 1000 V ±(0.3% + 1)
AC Voltage (Avg Responding) 0.001 V to 1000 V ±(2.0% + 2) (45 Hz – 1 kHz)
DC Current 0.01 mA to 10.00 A ±(1.5% + 2)
AC Current (Avg Responding) 0.01 mA to 10.00 A ±(2.5% + 2) (45 Hz – 1 kHz)
Resistance Up to 50 MΩ ±(0.5% to 2.0%) depending on range
Capacitance 1 nF to 9999 µF ±(1.2% + 2) to ±10% typical
Frequency 0.01 Hz to 99.99 kHz ±(0.1% + 1)
Diode Test 2.400 V max, ±(1.0% + 2)
Fuse Protection (mA input) 440 mA, 1000 V fast fuse
Fuse Protection (A input) 11 A, 1000 V fast fuse
Burden Voltage (typical) 2 mV/mA (400 mA), 37 mV/A (10 A input)
Overload Capability 400 mA up to 600 mA; >10 A not specified
Temperature Coefficient 0.1 x specified accuracy / °C outside 18–28°C range



[/specifications]

Fluke 77-IV Industrial Digital Multimeter

The Fluke 77-IV is a rugged and reliable digital multimeter designed for industrial and commercial applications. With a broad measurement range, advanced features, and high safety compliance, this multimeter is ideal for electricians, technicians, and engineers working in demanding environments.

  • Wide Voltage Range: Measures up to 1000V AC/DC with ±0.3% accuracy.
  • Current Measurement: Supports up to 10A AC/DC with overload protection (20A for 30 seconds).
  • Resistance & Continuity: Measures resistance up to 50MΩ with audible continuity test.
  • Capacitance & Frequency: Capable of measuring capacitance up to 9,999μF and frequency up to 99.99kHz.
  • Large Digital Display: 6000-count LCD with a 33-segment analog bar graph for real-time readings.
  • Auto & Manual Ranging: Ensures accurate measurements with selectable ranges.
  • Min/Max Recording: Captures signal fluctuations over time for troubleshooting.
  • Industrial Safety Compliance: Rated for CAT III 1000V and CAT IV 600V environments.
  • Durable Design: Rugged, ergonomic build for one-handed operation.
  • Extended Battery Life: Provides up to 400 hours of operation on a 9V battery.
  • DC Voltage Range: 6.000V – 1000V (±0.3% + 1 digit)
  • AC Voltage Range: 600.0mV – 1000V (±2.0% + 2 digits)
  • DC Current Range: 60.00mA – 10A (±1.5% + 2 digits)
  • AC Current Range: 60.00mA – 10A (±2.5% + 2 digits)
  • Resistance: 600.0Ω – 50MΩ (±0.5% + 1 digit)
  • Capacitance: 1nF – 9,999μF (±1.2% + 2 digits)
  • Frequency: 99.99Hz – 99.99kHz (±0.1% + 1 digit)
  • Continuity Test: Audible beep below 25Ω
  • Display: 6000-count LCD with 4 updates/sec
  • Safety Ratings: CAT III 1000V / CAT IV 600V
  • Battery Life: 400 hours (typical, alkaline)
  • Operating Temperature: -10°C to +50°C
  • Dimensions: 4.3 x 9 x 18.5 cm
  • Weight: 420 g

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc]

  • Fluke 77-IV is a versatile digital multimeter designed for industrial maintenance, field service, and bench repair, featuring high accuracy and robust safety compliance

[/shortdesc]

[properties]

Property
Model Fluke 77-IV
Product Type Digital Multimeter
Display 6000-count digital display with 33-segment bar graph
Voltage Measurement Range Up to 1000 V (AC/DC)
Current Measurement Range Up to 10 A (for 30 seconds)
Continuity Test Audible beep <25 Ω, detects 250 µs opens/shorts
Resistance Measurement Up to 50 MΩ
Capacitance Measurement Up to 9999 µF
Frequency Measurement 2 Hz to 99.99 kHz (AC voltage input)
MIN/MAX/AVG Function Available for tracking signal variation
Safety Compliance CAT III 1000 V, CAT IV 600 V
EMC Compliance EN 61326-1
Power Source 9V battery (installed)
Battery Life 400 hours typical (alkaline)
Dimensions (H x W x L) 4.3 x 9 x 18.5 cm
Weight 420 g
Operating Temperature -10°C to +50°C
Storage Temperature -40°C to +60°C
Operating Altitude 2000 m
Storage Altitude 12,000 m

[/properties]


[specifications]

Specification
DC Voltage 0.1 mV to 1000 V ±(0.3% + 1)
AC Voltage (Avg Responding) 0.001 V to 1000 V ±(2.0% + 2) (45 Hz – 1 kHz)
DC Current 0.01 mA to 10.00 A ±(1.5% + 2)
AC Current (Avg Responding) 0.01 mA to 10.00 A ±(2.5% + 2) (45 Hz – 1 kHz)
Resistance Up to 50 MΩ ±(0.5% to 2.0%) depending on range
Capacitance 1 nF to 9999 µF ±(1.2% + 2) to ±10% typical
Frequency 0.01 Hz to 99.99 kHz ±(0.1% + 1)
Diode Test 2.400 V max, ±(1.0% + 2)
Fuse Protection (mA input) 440 mA, 1000 V fast fuse
Fuse Protection (A input) 11 A, 1000 V fast fuse
Burden Voltage (typical) 2 mV/mA (400 mA), 37 mV/A (10 A input)
Overload Capability 400 mA up to 600 mA; >10 A not specified
Temperature Coefficient 0.1 x specified accuracy / °C outside 18–28°C range



[/specifications]

Fluke 77-IV Industrial Digital Multimeter

The Fluke 77-IV is a rugged and reliable digital multimeter designed for industrial and commercial applications. With a broad measurement range, advanced features, and high safety compliance, this multimeter is ideal for electricians, technicians, and engineers working in demanding environments.

Key Features:
  • Wide Voltage Range: Measures up to 1000V AC/DC with ±0.3% accuracy.
  • Current Measurement: Supports up to 10A AC/DC with overload protection (20A for 30 seconds).
  • Resistance & Continuity: Measures resistance up to 50MΩ with audible continuity test.
  • Capacitance & Frequency: Capable of measuring capacitance up to 9,999μF and frequency up to 99.99kHz.
  • Large Digital Display: 6000-count LCD with a 33-segment analog bar graph for real-time readings.
  • Auto & Manual Ranging: Ensures accurate measurements with selectable ranges.
  • Min/Max Recording: Captures signal fluctuations over time for troubleshooting.
  • Industrial Safety Compliance: Rated for CAT III 1000V and CAT IV 600V environments.
  • Durable Design: Rugged, ergonomic build for one-handed operation.
  • Extended Battery Life: Provides up to 400 hours of operation on a 9V battery.
Technical Specifications:
  • DC Voltage Range: 6.000V – 1000V (±0.3% + 1 digit)
  • AC Voltage Range: 600.0mV – 1000V (±2.0% + 2 digits)
  • DC Current Range: 60.00mA – 10A (±1.5% + 2 digits)
  • AC Current Range: 60.00mA – 10A (±2.5% + 2 digits)
  • Resistance: 600.0Ω – 50MΩ (±0.5% + 1 digit)
  • Capacitance: 1nF – 9,999μF (±1.2% + 2 digits)
  • Frequency: 99.99Hz – 99.99kHz (±0.1% + 1 digit)
  • Continuity Test: Audible beep below 25Ω
  • Display: 6000-count LCD with 4 updates/sec
  • Safety Ratings: CAT III 1000V / CAT IV 600V
  • Battery Life: 400 hours (typical, alkaline)
  • Operating Temperature: -10°C to +50°C
  • Dimensions: 4.3 x 9 x 18.5 cm
  • Weight: 420 g
