EBMPAPST A2D300-AD20-49 Axial Fan

Dual Voltage 230/400V

High-performance dual voltage axial fan with 2650/2900 RPM speed for efficient cooling in both commercial and industrial applications.
🔌

Dual Voltage Operation

Compatible with both 230V and 400V power systems, offering flexibility for various installation environments and regions.

 ⚡

High-Speed Performance

2650 RPM (50Hz) to 2900 RPM (60Hz) operation delivers powerful airflow for effective heat dissipation in demanding applications.

 📊

Optimized Power Range

220W (50Hz) to 320W (60Hz) power rating balances performance with energy efficiency across different operating conditions.

 🏗️

Compact & Lightweight

2.8kg lightweight design with compact dimensions (40×40×25cm) for easy installation in space-constrained environments.
Model Number A2D300-AD20-49
Motor Number M2D068-EC
Manufacturer EBMPAPST GERMANY
Product Type Axial Fan
Condition Original new from manufacturer
Rated Power (50/60 Hz) 220 W / 320 W
Rated Voltage 3~ 230/400 V
Rated Current (50/60 Hz) 0.4 A / 0.87 A
Speed (50/60 Hz) 2650 rpm / 2900 rpm
Frequency 50/60 Hz
Net Weight 2.8 kg
Shipping Dimension 40 × 40 × 25 cm
Country of Origin Germany
HS Code 8414599099

Shipping Hub: Dispatched from Hong Kong for efficient global distribution.

Processing Time: Orders are processed and ready to ship within 5 business days.

Express Delivery: Estimated delivery in 3-8 business days worldwide via DHL or UPS.

Warranty: Backed by a full 1-year manufacturer's warranty.

Our Promise: We sell only genuine EBMPAPST products guaranteed to meet all factory specs. Enjoy a 30-day return policy and our commitment to 100% satisfaction.

For Large Quantity Inquiries: Please contact our sales team at sales@axialfanz.com for volume pricing and custom quotation.

Q1: What does the dual voltage capability (230/400V) mean for installation?

A: The A2D300-AD20-49 can be connected to both 230V and 400V three-phase power systems. This flexibility allows installation in diverse environments - 230V for commercial/light industrial applications and 400V for standard industrial facilities. Always ensure proper wiring configuration based on your local voltage supply.

Q2: Why is the speed so high (2650-2900 RPM) compared to other axial fans?

A: The high rotational speed (2650-2900 RPM) is designed to deliver maximum airflow in compact form factors. This makes it ideal for applications requiring high static pressure cooling, such as densely packed electronics, server racks, or equipment with significant airflow resistance where space is limited but cooling demand is high.

Q3: What does the "AD20-49" suffix indicate in the model number?

A: In EBMPAPST's nomenclature, "AD20-49" typically denotes specific technical characteristics including the dual voltage capability, motor winding configuration, and performance profile optimized for high-speed operation with balanced power consumption across different voltage inputs.

Q4: Is this fan suitable for continuous 24/7 operation?

A: Yes. With German engineering and quality components, the A2D300-AD20-49 is designed for reliable continuous operation. Its robust construction and efficient thermal management make it suitable for applications requiring uninterrupted cooling, such as data centers, telecommunications equipment, and industrial machinery that operate around the clock.

Contact us for detailed performance data, application recommendations, or volume pricing for your project requirements.

Request Technical Information Request Volume Pricing



Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

EBMPAPST A2D300-AD20-49 Axial Fan

Dual Voltage 230/400V

High-performance dual voltage axial fan with 2650/2900 RPM speed for efficient cooling in both commercial and industrial applications.
Versatile Performance for Multiple Applications
🔌

Dual Voltage Operation

Compatible with both 230V and 400V power systems, offering flexibility for various installation environments and regions.

 ⚡

High-Speed Performance

2650 RPM (50Hz) to 2900 RPM (60Hz) operation delivers powerful airflow for effective heat dissipation in demanding applications.

 📊

Optimized Power Range

220W (50Hz) to 320W (60Hz) power rating balances performance with energy efficiency across different operating conditions.

 🏗️

Compact & Lightweight

2.8kg lightweight design with compact dimensions (40×40×25cm) for easy installation in space-constrained environments.
Technical Specifications
Model Number A2D300-AD20-49
Motor Number M2D068-EC
Manufacturer EBMPAPST GERMANY
Product Type Axial Fan
Condition Original new from manufacturer
Rated Power (50/60 Hz) 220 W / 320 W
Rated Voltage 3~ 230/400 V
Rated Current (50/60 Hz) 0.4 A / 0.87 A
Speed (50/60 Hz) 2650 rpm / 2900 rpm
Frequency 50/60 Hz
Net Weight 2.8 kg
Shipping Dimension 40 × 40 × 25 cm
Country of Origin Germany
HS Code 8414599099
Shipping, Warranty & Service

Shipping Hub: Dispatched from Hong Kong for efficient global distribution.

Processing Time: Orders are processed and ready to ship within 5 business days.

Express Delivery: Estimated delivery in 3-8 business days worldwide via DHL or UPS.

Warranty: Backed by a full 1-year manufacturer's warranty.

Our Promise: We sell only genuine EBMPAPST products guaranteed to meet all factory specs. Enjoy a 30-day return policy and our commitment to 100% satisfaction.

For Large Quantity Inquiries: Please contact our sales team at sales@axialfanz.com for volume pricing and custom quotation.
Frequently Asked Questions

Q1: What does the dual voltage capability (230/400V) mean for installation?

A: The A2D300-AD20-49 can be connected to both 230V and 400V three-phase power systems. This flexibility allows installation in diverse environments - 230V for commercial/light industrial applications and 400V for standard industrial facilities. Always ensure proper wiring configuration based on your local voltage supply.

Q2: Why is the speed so high (2650-2900 RPM) compared to other axial fans?

A: The high rotational speed (2650-2900 RPM) is designed to deliver maximum airflow in compact form factors. This makes it ideal for applications requiring high static pressure cooling, such as densely packed electronics, server racks, or equipment with significant airflow resistance where space is limited but cooling demand is high.

Q3: What does the "AD20-49" suffix indicate in the model number?

A: In EBMPAPST's nomenclature, "AD20-49" typically denotes specific technical characteristics including the dual voltage capability, motor winding configuration, and performance profile optimized for high-speed operation with balanced power consumption across different voltage inputs.

Q4: Is this fan suitable for continuous 24/7 operation?

A: Yes. With German engineering and quality components, the A2D300-AD20-49 is designed for reliable continuous operation. Its robust construction and efficient thermal management make it suitable for applications requiring uninterrupted cooling, such as data centers, telecommunications equipment, and industrial machinery that operate around the clock.
Need High-Speed Cooling Solutions?

Contact us for detailed performance data, application recommendations, or volume pricing for your project requirements.

Request Technical Information Request Volume Pricing
