Cisco Industrial IE3400-8T2S-E Rugged DIN-Rail 8-Port GE PoE 2x1G SFP
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco IE3400-8T2S-E Industrial Ethernet Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
The Cisco Catalyst IE-3400-8T2S-E is a compact, ruggedized industrial switch engineered for U.S. infrastructure—from transit control centers in Chicago to energy sites in Texas.
Part of the Cisco IE3400 Rugged Series, it delivers 8 auto-sensing 10/100/1000 RJ-45 ports plus 2 Gigabit SFP uplinks in a convection-cooled, fanless DIN-rail chassis rated IP30.
Built to withstand –40 °C to +75 °C operating temperatures with vibration, shock, and surge immunity, it runs Cisco IOS XE with the Network Essentials license for core Layer 2 and basic Layer 3 services, and integrates seamlessly with Cisco Catalyst Center and Cisco DNA Center for centralized management.
Overview
Core Highlights
-
Rugged Industrial Design
Fanless, convection-cooled metal housing; IP30-rated; –40 °C to +75 °C; hardened against vibration, shock, surge, and electrical noise. -
Modular Gigabit Interfaces
8 × 10/100/1000 RJ-45 downlinks + 2 × 1 Gbps SFP uplinks; expandable to 26 ports via Cisco IEM modules. -
UADP ASIC & IOS XE
Built on Cisco’s Unified Access Data Plane (UADP) ASIC and Cisco IOS XE for software-defined access, automation, and high security. -
Advanced Resiliency Protocols
Supports Media Redundancy Protocol (MRP), Resilient Ethernet Protocol (REP), Device Level Ring (DLR), Parallel Redundancy Protocol (PRP), and High-Availability Seamless Redundancy (HSR). -
Zero-Touch Replacement (SwapDrive)
True plug-and-play swap-out with zero configuration required for fast field recovery. -
Full Flexible NetFlow
Real-time flow and threat visibility for capacity planning and security incident detection. -
Unified Management
GUI (WebUI), CLI, SNMP v1/v2c/v3, RMON, USB/SD console, plus Cisco Catalyst Center and Cisco DNA Center integration. -
High Performance
20 Gbps full-duplex switching capacity and 14.88 Mpps wire-speed forwarding ensure rapid packet delivery in industrial environments.
Recommended Accessories
| Accessory | Category | Description |
|---|---|---|
| IEM-3400-8T | Expansion Module | 8 GE copper ports to scale base switch up to 18 ports |
| IEM-3400-8S | Expansion Module | 8 GE SFP fiber ports to scale base switch up to 18 ports |
| SD-IE-16GB | Removable Storage | 16 GB SD flash card for storing IOS images and configs |
| STK-RACK-DINRAIL | Mounting Hardware | 19″ DIN-rail mounting kit for rack or cabinet installations |
Comparison with Similar Models
| Feature | IE-3400-8T2S-E | IE-3400-8P2S-E | IE-3400-8T2S-A |
|---|---|---|---|
| Ports & Uplinks | 8 × 1 GbE + 2 × 1 GbE SFP | 8 × 1 GbE PoE+ + 2 × 1 GbE SFP | 8 × 1 GbE + 2 × 1 GbE SFP |
| PoE Budget | N/A | 240 W (base) / 480 W (with module) | N/A |
| License | Network Essentials | Network Essentials | Network Advantage |
| Switching Capacity | 20 Gbps full-duplex | 20 Gbps full-duplex | 20 Gbps full-duplex |
| Forwarding Rate | 14.88 Mpps | 14.88 Mpps | 14.88 Mpps |
| Power Consumption | 36 W (excl. PoE) | 47 W (excl. PoE) | 36 W |
| Dimensions (HxWxD) | 6.0″×3.6″×5.3″ | 6.0″×4.4″×5.3″ | 6.0″×3.6″×5.3″ |
| Ideal Use Case | High-speed non-PoE edge in harsh sites | Industrial PoE+ deployments at the edge | Advanced routing & segmentation |
Specifications
| Specification | Details |
|---|---|
| Product Code | IE-3400-8T2S-E |
| Product Type | Industrial Managed Switch – Modular |
| Copper Ports | 8 × 10/100/1000 Mbps |
| SFP Uplink Ports | 2 × 100/1000 Mbps |
| Expansion Capability | Up to 26 total ports with Cisco IEM modules |
| Switching Capacity | 20 Gbps full-duplex |
| Forwarding Rate | 14.88 Mpps |
| Memory | 4 GB DRAM / 1.5 GB Flash; SD card slot |
| Power Input | 9.6–60 V DC dual redundant input |
| Power Consumption | 36 W (non-PoE model, measured at 12 V) |
| Operating Temperature | –40 °C to +75 °C |
| Operating Humidity | 0–100% condensing |
| Mounting | DIN-rail or wall-mountable |
| Enclosure | Rugged fanless metal, IP30-rated |
| Console Ports & Alarms | 1 × RS-232 (RJ-45), 1 × USB Mini Type-B; 2 dry-contact inputs, 1 Form-C output |
| Removable Storage | USB 2.0/3.0, SD card (optional) |
| Certifications | IEC 60068, IEEE 1613, EN 55032, UL, CE, RoHS |
| Dimensions (HxWxD) | 6.0″ × 3.6″ × 5.3″ (152 × 91 × 135 mm) |
| Weight | 3.8 lbs (1.7 kg) |
| Management | CLI, SNMP v1/v2c/v3, Web GUI, Cisco Catalyst Center, Cisco DNA Center |
| License Type | Network Essentials (Cisco IOS XE) |
