Cisco Catalyst IEM-3500-8S Expansion Module
Cisco Catalyst IEM-3500-8S Expansion Module

Cisco Catalyst IEM-3500-8S Expansion Module

por Cisco
Desconto de 40%
R$ 31.112,76
R$ 18.540,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

  • Expansion module, Managed (inherits L2/L3), 8 × 1G/100M SFP, IP30 rugged, fanless, DIN-rail, powered by base switch

[/shortdesc]

[properties]

Property Details
Product Line Cisco Catalyst IE3500 Expansion Module
Use Case Port expansion for IE3500 series (industrial/harsh environments)
Management Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center)
PoE Support No PoE
Layer Support Inherits Layer 2 & Layer 3 from base switch
Scalability Expands total system ports up to 19 (with compatible base)
Operating System Inherits Cisco IOS XE from base switch
Software Licence Inherits from base switch
Form Factor Ruggedized, fanless, DIN-rail module (IP30)
Default Power Supply Powered by base switch

[/properties]

[specifications]

Specification Details
Model Number IEM-3500-8S
Port Count 8 (8 × 1G/100M SFP)
Downlink Ports & Speeds 8 × 1G/100M SFP
Uplink Ports & Speeds —
PoE Power Budget No PoE
Switching Capacity —
Forwarding Rate Line-rate on all ports (all packet sizes)
Stacking Bandwidth —
DRAM 8 GB
Flash Memory 5.1 GB
MAC Address Table Size 24,000 entries
VLAN Support 4096 VLAN IDs (up to 1024 active)
Power Requirements Powered by base switch; module power consumption 9 W
Dimensions (H × W × D) 6.00 × 2.51 × 5.29 in (15.24 × 6.38 × 13.44 cm)
Weight 1.95 lb (0.88 kg)
MTBF 4,268,192 hours

[/specifications]

[accesories]

Cabling & connectors

Item Details
SFP fiber patch cord (LC) Data cable for 8× 1G/100M SFP ports

SFP transceivers (1G / 100M only)

Item Details
GLC-FE-100FX-RGD= / GLC-FE-100LX-RGD= Industrial FE SFPs (100BASE-FX, 100BASE-LX10)
GLC-FE-100FX= / GLC-FE-100LX= / GLC-FE-100EX= / GLC-FE-100ZX= / GLC-FE-100BX-U= / GLC-FE-100BX-D= Commercial/EXT FE SFPs
GLC-SX-MM-RGD= / GLC-LX-SM-RGD= / GLC-ZX-SM-RGD= Industrial GE SFPs (SX/LX/ZX)
SFP-GE-S / SFP-GE-L / SFP-GE-Z / GLC-BX-U= / GLC-BX-D= / GLC-EX-SMD= / GLC-ZX-SMD= GE SFPs (SX/LX/ZX/BiDi/EX)
GLC-TE= / GLC-T= / GLC-T-RGD= 1G copper SFPs (note: may reduce PTP performance)
CWDM-SFP-xxxx= / DWDM-SFP-xxxx= CWDM/DWDM 1G SFP optics (various wavelengths)

[/accesories]

The Cisco Catalyst IEM-3500-8S Expansion Module adds high-density fiber connectivity to IE3500 base switches for industrial and harsh environments. Providing 8 × 1G/100M SFP ports, it delivers reliable line-rate performance in a rugged, fanless IP30 DIN-rail form factor. The module is powered by the host switch (9 W module consumption) and inherits IOS XE features, licensing, and management for seamless integration—ideal for extending fiber access/aggregation where copper is impractical.

Key Features:

  • 8 × 1G/100M SFP Ports: Flexible fiber connectivity for resilient aggregation/backbone links.
  • Ruggedized, Fanless Design (IP30): Built for space-constrained industrial sites with DIN-rail mounting.
  • Inherits IOS XE Features & Licensing: Operates as part of the IE3500 system for consistent L2/L3 capabilities.
  • Easy Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).
  • Scalable Architecture: Helps expand total system ports up to 19 with compatible IE3500 bases.

Technical Overview:

  • Recommended for: Fiber port-density expansion on Cisco IE3500 deployments in industrial/harsh environments.
  • Ports: 8 × 1G/100M SFP.
  • PoE Budget: No PoE.
  • Switching Capacity: —
  • Forwarding Rate: Line-rate on all ports (all packet sizes).
  • Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).
  • Security: Inherits features and license tier from the base IE3500 switch.
  • Energy Efficiency: Fanless operation; powered by base switch (module consumption 9 W).
