Cisco Catalyst IEM-3500-6T2S Expansion Module
Cisco Catalyst IEM-3500-6T2S Expansion Module

Cisco Catalyst IEM-3500-6T2S Expansion Module

por Cisco
Desconto de 34%
R$ 27.371,76
R$ 17.940,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x
  • Expansion module, Managed (inherits L2/L3), 6 × 10/100/1000 + 2 × 1G SFP, IP30 rugged, fanless, DIN-rail, powered by base switch
Property Details
Product Line Cisco Catalyst IE3500 Expansion Module
Use Case Port expansion for IE3500 series (industrial/harsh environments)
Management Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center)
PoE Support No PoE
Layer Support Inherits Layer 2 & Layer 3 from base switch
Scalability Expands total system ports up to 19 (with compatible base)
Operating System Inherits Cisco IOS XE from base switch
Software Licence Inherits from base switch
Form Factor Ruggedized, fanless, DIN-rail module (IP30)
Default Power Supply Powered by base switch
Specification Details
Model Number IEM-3500-6T2S
Port Count 8 (6 × 10/100/1000 + 2 × 1G/100M SFP)
Downlink Ports & Speeds 6 × 10/100/1000 Mbps RJ45
Uplink Ports & Speeds 2 × 1G/100M SFP
PoE Power Budget No PoE
Switching Capacity —
Forwarding Rate Line-rate on all ports (all packet sizes)
Stacking Bandwidth —
DRAM 8 GB
Flash Memory 5.1 GB
MAC Address Table Size 24,000 entries
VLAN Support 4096 VLAN IDs (up to 1024 active)
Power Requirements Powered by base switch; module power consumption 10 W
Dimensions (H × W × D) 6.00 × 2.51 × 5.29 in (15.24 × 6.38 × 13.44 cm)
Weight 1.95 lb (0.88 kg)
MTBF 2,438,014 hours

Cabling & connectors

Item Details
Cat5e/Cat6/Cat6A RJ-45 patch cable Data cable for 6× copper downlink ports (1G)
SFP fiber patch cord (LC) Data cable for 2× 1G/100M SFP ports

SFP transceivers (1G / 100M only)

Item Details
GLC-FE-100FX-RGD= / GLC-FE-100LX-RGD= Industrial FE SFPs (100BASE-FX, 100BASE-LX10)
GLC-FE-100FX= / GLC-FE-100LX= / GLC-FE-100EX= / GLC-FE-100ZX= / GLC-FE-100BX-U= / GLC-FE-100BX-D= Commercial/EXT FE SFPs
GLC-SX-MM-RGD= / GLC-LX-SM-RGD= / GLC-ZX-SM-RGD= Industrial GE SFPs (SX/LX/ZX)
SFP-GE-S / SFP-GE-L / SFP-GE-Z / GLC-BX-U= / GLC-BX-D= / GLC-EX-SMD= / GLC-ZX-SMD= GE SFPs (SX/LX/ZX/BiDi/EX)
GLC-TE= / GLC-T= / GLC-T-RGD= 1G copper SFPs (note: may reduce PTP performance)
CWDM-SFP-xxxx= / DWDM-SFP-xxxx= CWDM/DWDM 1G SFP optics (various wavelengths)

The Cisco Catalyst IEM-3500-6T2S Expansion Module adds a balanced mix of copper and fiber connectivity to IE3500 base switches for industrial and harsh environments. Providing 6 Gigabit RJ45 downlinks and 2 fixed 1G/100M SFP uplinks, it delivers reliable line-rate performance in a rugged, fanless IP30 DIN-rail form factor. The module is powered by the host switch (10 W module consumption) and inherits IOS XE features, licensing, and management for seamless integration—ideal for right-sizing access where a compact copper/fiber combination is required.

Key Features:

  • 6 × Gigabit Ethernet Downlinks (Non-PoE): Cost-efficient port expansion for endpoints that don’t require inline power.
  • 2 × 1G/100M SFP Uplinks: Flexible fiber connectivity for resilient aggregation/backbone links.
  • Ruggedized, Fanless Design (IP30): Built for space-constrained industrial sites with DIN-rail mounting.
  • Inherits IOS XE Features & Licensing: Operates as part of the IE3500 system for consistent L2/L3 capabilities.
  • Easy Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).

Technical Overview:

  • Recommended for: Mixed copper/fiber port-density expansion on Cisco IE3500 deployments in industrial/harsh environments.
  • Ports: 6 × 10/100/1000 Mbps RJ45 downlinks with 2 × 1G/100M SFP uplinks.
  • PoE Budget: No PoE.
  • Switching Capacity: —
  • Forwarding Rate: Line-rate on all ports (all packet sizes).
  • Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).
  • Security: Inherits features and license tier from the base IE3500 switch.
  • Energy Efficiency: Fanless operation; powered by base switch (module consumption 10 W).

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto
  • Expansion module, Managed (inherits L2/L3), 6 × 10/100/1000 + 2 × 1G SFP, IP30 rugged, fanless, DIN-rail, powered by base switch
Property Details
Product Line Cisco Catalyst IE3500 Expansion Module
Use Case Port expansion for IE3500 series (industrial/harsh environments)
Management Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center)
PoE Support No PoE
Layer Support Inherits Layer 2 & Layer 3 from base switch
Scalability Expands total system ports up to 19 (with compatible base)
Operating System Inherits Cisco IOS XE from base switch
Software Licence Inherits from base switch
Form Factor Ruggedized, fanless, DIN-rail module (IP30)
Default Power Supply Powered by base switch
Specification Details
Model Number IEM-3500-6T2S
Port Count 8 (6 × 10/100/1000 + 2 × 1G/100M SFP)
Downlink Ports & Speeds 6 × 10/100/1000 Mbps RJ45
Uplink Ports & Speeds 2 × 1G/100M SFP
PoE Power Budget No PoE
Switching Capacity —
Forwarding Rate Line-rate on all ports (all packet sizes)
Stacking Bandwidth —
DRAM 8 GB
Flash Memory 5.1 GB
MAC Address Table Size 24,000 entries
VLAN Support 4096 VLAN IDs (up to 1024 active)
Power Requirements Powered by base switch; module power consumption 10 W
Dimensions (H × W × D) 6.00 × 2.51 × 5.29 in (15.24 × 6.38 × 13.44 cm)
Weight 1.95 lb (0.88 kg)
MTBF 2,438,014 hours

Cabling & connectors

Item Details
Cat5e/Cat6/Cat6A RJ-45 patch cable Data cable for 6× copper downlink ports (1G)
SFP fiber patch cord (LC) Data cable for 2× 1G/100M SFP ports

SFP transceivers (1G / 100M only)

Item Details
GLC-FE-100FX-RGD= / GLC-FE-100LX-RGD= Industrial FE SFPs (100BASE-FX, 100BASE-LX10)
GLC-FE-100FX= / GLC-FE-100LX= / GLC-FE-100EX= / GLC-FE-100ZX= / GLC-FE-100BX-U= / GLC-FE-100BX-D= Commercial/EXT FE SFPs
GLC-SX-MM-RGD= / GLC-LX-SM-RGD= / GLC-ZX-SM-RGD= Industrial GE SFPs (SX/LX/ZX)
SFP-GE-S / SFP-GE-L / SFP-GE-Z / GLC-BX-U= / GLC-BX-D= / GLC-EX-SMD= / GLC-ZX-SMD= GE SFPs (SX/LX/ZX/BiDi/EX)
GLC-TE= / GLC-T= / GLC-T-RGD= 1G copper SFPs (note: may reduce PTP performance)
CWDM-SFP-xxxx= / DWDM-SFP-xxxx= CWDM/DWDM 1G SFP optics (various wavelengths)
Cisco Catalyst IEM-3500-6T2S Expansion Module

The Cisco Catalyst IEM-3500-6T2S Expansion Module adds a balanced mix of copper and fiber connectivity to IE3500 base switches for industrial and harsh environments. Providing 6 Gigabit RJ45 downlinks and 2 fixed 1G/100M SFP uplinks, it delivers reliable line-rate performance in a rugged, fanless IP30 DIN-rail form factor. The module is powered by the host switch (10 W module consumption) and inherits IOS XE features, licensing, and management for seamless integration—ideal for right-sizing access where a compact copper/fiber combination is required.

Key Features:

  • 6 × Gigabit Ethernet Downlinks (Non-PoE): Cost-efficient port expansion for endpoints that don’t require inline power.
  • 2 × 1G/100M SFP Uplinks: Flexible fiber connectivity for resilient aggregation/backbone links.
  • Ruggedized, Fanless Design (IP30): Built for space-constrained industrial sites with DIN-rail mounting.
  • Inherits IOS XE Features & Licensing: Operates as part of the IE3500 system for consistent L2/L3 capabilities.
  • Easy Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).

Technical Overview:

  • Recommended for: Mixed copper/fiber port-density expansion on Cisco IE3500 deployments in industrial/harsh environments.
  • Ports: 6 × 10/100/1000 Mbps RJ45 downlinks with 2 × 1G/100M SFP uplinks.
  • PoE Budget: No PoE.
  • Switching Capacity: —
  • Forwarding Rate: Line-rate on all ports (all packet sizes).
  • Management: Managed (Cisco IOS XE WebUI/CLI; optional Cisco Catalyst Center).
  • Security: Inherits features and license tier from the base IE3500 switch.
  • Energy Efficiency: Fanless operation; powered by base switch (module consumption 10 W).
