Cisco Catalyst C9300-24P-A Advantage License 24-Port PoE+ Switch
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco Catalyst 9300 24-Port PoE+ Switch, Network Advantage (C9300-24P-A)
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Quick Buying Guide - Best for Advanced Enterprise Access
-
Network Advantage License: Delivers advanced Layer 3 routing (BGP, EIGRP, OSPF), flexible network segmentation (VRF, VXLAN, LISP), and full SD-Access capabilities.
-
Modular Uplinks Flexibility: Unlike fixed-uplink models, this high-performance 24 port poe switch allows you to swap uplink modules (1G, 10G, 25G, or 40G) as your network scales.
-
StackWise-480 & StackPower: Industry-leading 480 Gbps stacking bandwidth and power-sharing capabilities for maximum high-availability.
-
PoE+ Powered: Ships with a 715W PSU delivering a 445W PoE+ budget (up to 30W per port), easily powering Wi-Fi 6/6E APs, IP cameras, and VoIP phones.
-
Pro Tip: If your enterprise requires BGP routing, VXLAN fabric, or Cisco DNA Center/Catalyst Center automation (SD-Access), the Advantage license is mandatory. If you only need basic routing, consider the C9300-24P-E (Essentials) to save costs. Learn more details in our comprehensive Cisco Catalyst FAQ: Power, Stacking & Licensing Guide
Overview
As a flagship model in the Cisco Catalyst 9300 family, the Cisco C9300-24P-A is a purpose-built hardware platform purpose-built for advanced enterprise environments. This reliable cisco 24 port PoE switch delivers up to 30W PoE+ per port and runs the Network Advantage license for full SD-Access and BGP routing capabilities. If you are looking to upgrade your edge network, implementing cisco c9300 24p deployments provides the ultimate cloud-ready security and 480 Gbps stacking scale.
Related Reading & Architecture Guides:
-
Evaluating an upgrade? Check out our hardware breakdown: Cisco Catalyst 9200 vs 9300 Series Switches.
-
Migrating from older technology? Read our migration blueprint: Cisco Catalyst 2960X vs Catalyst 9300 Series.
-
Explore the entire portfolio structure: Cisco 9300 Series Switches Deep Dive.
📥 Download Technical Specifications: Planning a high-density PoE+ wireless deployment? Enter your work email below to download the official cisco 9300 datasheet (also available as the detailed cisco c9300 datasheet PDF) to review exact power budgets, module compatibility, and routing scale.
Powered by the multicore x86 CPU and Cisco UADP 2.0 ASIC, it delivers deep telemetry, zero-touch automation, and enterprise-grade security. With 24 auto-sensing Gigabit PoE+ downlinks and a hot-swappable uplink module slot, the C9300-24P-A guarantees cloud-ready performance, 480 Gbps stacking scale, and sub-50 ms failover for your most critical network services.
Highlights
-
24 Gigabit PoE+ Downlinks: Up to 30W per port (IEEE 802.3at) with a default 445W PoE budget, upgradeable to 720W.
-
Flexible Modular Uplinks: 1 network-module slot supporting 41G (C9300-NM-4G), 810G (C9300-NM-8X), 225G (C9300-NM-2Y), or 240G (C9300-NM-2Q).
-
Wire-Speed Switching: 208 Gbps non-blocking switch fabric (688 Gbps with stacking) and 154.76 Mpps forwarding rate (511.90 Mpps with stacking).
-
StackWise-480 & StackPower: Connect up to 8 switches with 480 Gbps bidirectional bandwidth. Cisco StackPower pools power supplies across the stack for ultimate redundancy.
-
Zero-Trust Security: Line-rate AES-256 MACsec encryption, Encrypted Traffic Analytics (ETA), Secure Boot, and Trust Anchor Module.
-
SD-Access & Programmability: Full support for VXLAN, LISP, NETCONF/RESTCONF, Python scripting, and ThousandEyes network assurance.
-
Advanced Routing: BGP, OSPF, EIGRP, IS-IS, VRF, and Multicast routing enabled out of the box via Network Advantage.
Use Cases & Deployment Scenarios
-
Advanced Enterprise Campus: Serve as the foundation for Cisco SD-Access architecture with full micro-segmentation and automation.
-
High-Density Wi-Fi 6/6E Deployments: Reliable PoE+ delivery for powering high-performance wireless access points.
-
Mission-Critical Branch Offices: Utilize StackWise-480 and StackPower for environments that demand 99.999% uptime and zero-disruption failover.
-
IoT & Surveillance Networks: Connect and power IP security cameras, access control systems, and IP phones with centralized policy management.
Recommended Accessories
To configure your cisco c9300-24p-a asset effectively, match your system layouts with original Cisco spare parts and expansion cards. For a comprehensive list of configurations, read our guide on How to Select Modules and Cables for Cisco 9300 Series.
| Accessory Category | Model / Part Number | Description |
| Network Module | C9300-NM-8X | Build a high-speed campus backbone with the official cisco c9300 nm 8x module (8x 10G SFP+). |
| Network Module | C9300-NM-2Y | 2 x 25G/10G/1G SFP28 uplinks for ultra-low latency aggregation. |
| Network Module | C9300-NM-4G | 4 x 1G SFP uplinks for standard fiber connectivity. |
| Stacking Cable | STACK-T1-50CM | Enable StackWise-480 high availability using dedicated cisco 9300 stack cables.Review our Cisco 9300 Stack Kit Compatibility Guide. |
| Power Supply (Redundancy) | PWR-C1-715WAC-P | 715W AC Platinum PSU (Adds redundancy or extra PoE budget). |
| Power Supply (Upgrade) | PWR-C1-1100WAC-P | 1100W AC Platinum PSU (Upgrades PoE+ budget from 445W to 720W). |
Comparison with Similar Models
| Feature | C9300-24P-A | C9300-24P-E | C9300-24T-A |
| Downlinks | 24 x 1G PoE+ | 24 x 1G PoE+ | 24 x 1G Data-only |
| License | Network Advantage | Network Essentials | Network Advantage |
| Advanced Routing (BGP/VRF) | Supported | Not Supported | Supported |
| Default PSU | 715W AC | 715W AC | 350W AC |
| Default PoE Budget | 445W (Upgradable to 720W) | 445W (Upgradable to 720W) | None |
| Stacking | StackWise-480 (480 Gbps) | StackWise-480 (480 Gbps) | StackWise-480 (480 Gbps) |
Specifications
| Parameter | Specification |
| Product Code | C9300-24P-A |
| Software License | Cisco IOS XE with Network Advantage |
| Downlink Ports | 24 x 10/100/1000 Mbps RJ-45 PoE+ auto-sensing |
| Uplink Expansion | 1 modular slot (C9300-NM-4G / 8X / 2Y / 2Q / 4M) |
| Default Power Supply | 1 PWR-C1-715WAC-P (715W AC Platinum) |
| Available PoE Budget | 445W default (Up to 30W per port); Upgradeable to 720W with 1100W PSU |
| Switching Capacity | 208 Gbps (688 Gbps with stacking) |
| Forwarding Rate | 154.76 Mpps (511.90 Mpps with stacking) |
| Stacking Bandwidth | 480 Gbps (StackWise-480); Up to 8 members |
| MAC Address Table | 32,000 entries |
| IPv4 Routes | 32,000 (24,000 direct + 8,000 indirect) |
| IPv6 Routes | 16,000 entries |
| Multicast Routing | 8,000 groups |
| DRAM / Flash | 8 GB / 16 GB |
| CPU & ASIC | Multicore x86 CPU; Cisco UADP 2.0 ASIC |
| Dimensions (HWD) | 1.73 x 17.5 x 17.7 (4.4 x 44.5 x 44.9 cm) with default PSU |
| Weight | 16.33 lb (7.4 kg) |
| Operating Temp | 23 F to 113 F (-5°C to 45°C) at sea level |
| MTBF | 299,000 hours |
