Cisco Catalyst C9300-24P 24-Port PoE+ Enterprise Switch Network Advantage & Essential
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco Catalyst 9300 Series 24-Port PoE+ Enterprise Switches (C9300-24P-A / C9300-24P-E)
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Quick Buying Guide - Choosing the Right License
-
Shared Enterprise Hardware: Both the C9300-24P-A and C9300-24P-E are built on the exact same high-performance hardware-delivering 24 Gigabit PoE+ ports, 480 Gbps of stacking bandwidth, and flexible modular uplinks.
-
Network Advantage (C9300-24P-A): Best for Advanced Networks. Choose this model if your enterprise requires advanced Layer 3 routing (BGP, EIGRP, OSPF), flexible network segmentation (VRF, VXLAN), full Cisco SD-Access capabilities, or ThousandEyes deep telemetry.
-
Network Essentials (C9300-24P-E): Cost-Effective Access. Choose this model for traditional branch offices or basic campus access. It provides robust Layer 2 switching and essential Layer 3 routing (Static, OSPF Stub, RIP), saving your budget without compromising on hardware performance.
Overview
The Cisco Catalyst 9300 Series is Cisco's flagship stackable enterprise switching platform, purpose-built to handle the challenges of security, IoT, mobility, and cloud environments. Powered by the multicore x86 CPU architecture and Cisco's UADP 2.0 ASIC, the C9300-24P models deliver unparalleled cloud-ready performance.
Unlike older legacy switches, these models completely eliminate fixed uplinks in favor of a highly flexible modular uplink slot (supporting 1G, 10G, 25G, and 40G speeds). Equipped with 24 IEEE 802.3at PoE+ ports, both the Advantage and Essentials models offer industry-leading reliability, wire-speed performance, and the ability to host third-party containers and applications natively on the switch.
Highlights
-
24 Gigabit PoE+ Ports: Ships with a 715W Platinum-rated power supply, providing a default 445W PoE budget (up to 30W per port), which is easily upgradeable to 720W.
-
StackWise-480 Resiliency: Stack up to 8 switches with an industry-leading 480 Gbps bidirectional stacking bandwidth and sub-50 ms failover.
-
Cisco StackPower: An innovative interconnect system that pools power supplies across the stack, dynamically sharing power for ultimate redundancy.
-
Modular Uplink Flexibility: Swap network modules (NM) easily as your bandwidth needs grow. Upgrade from 1G to 10G, 25G (SFP28), or 40G (QSFP+) without replacing the core switch.
-
Zero-Trust Security: Features line-rate AES-256 MACsec encryption, Secure Boot, and a hardware-anchored Trust Anchor Module to protect against sophisticated threats.
-
Future-Ready Programmability: Runs Cisco IOS XE, natively supporting model-driven programmability, NETCONF/RESTCONF APIs, and Python scripting for zero-touch automation.
Use Cases & Deployment Scenarios
-
High-Density Wi-Fi 6/6E Deployments: Delivers robust PoE+ power and a non-blocking switch fabric to support the heavy traffic and concurrency of next-generation access points.
-
Large Campus & SD-Access Core (Advantage Model): Acts as the foundational boundary node for Cisco's Software-Defined Access architecture, enabling full network automation and micro-segmentation.
-
Mission-Critical Branch Offices: Utilize StackWise-480 and StackPower to ensure 99.999% uptime for environments like finance, healthcare, or government edges where downtime is unacceptable.
-
IoT & Security Infrastructure: Centralize power delivery and policy-based network access for IP surveillance cameras, VoIP phones, and building management systems.
Recommended Accessories & Modules
(Note: The following accessories are compatible with both Advantage and Essentials models)
| Accessory Category | Model / Part Number | Description |
| Network Module | C9300-NM-8X | 8 x 10G/1G SFP+ uplinks for high-speed campus aggregation. |
| Network Module | C9300-NM-2Y | 2 x 25G/10G/1G SFP28 uplinks for higher bandwidth and low latency. |
| Network Module | C9300-NM-4G | 4 x 1G SFP uplinks for standard fiber connectivity. |
| Network Module | C9300-NM-2Q | 2 x 40G QSFP+ uplinks for ultra-high-speed aggregation. |
| Power Supply (Redundancy) | PWR-C1-715WAC-P | 715W AC Platinum PSU (Adds N+1 redundancy). |
| Power Supply (Upgrade) | PWR-C1-1100WAC-P | 1100W AC Platinum PSU (Upgrades PoE+ budget to 720W max). |
C9300-24P-A vs. C9300-24P-E Feature Comparison
| Feature & Specification | C9300-24P-A (Advantage) | C9300-24P-E (Essentials) |
| Downlinks & PoE Budget | 24 x 1G PoE+ (445W Default) | 24 x 1G PoE+ (445W Default) |
| Uplink Architecture | Modular Slot (1G/10G/25G/40G) | Modular Slot (1G/10G/25G/40G) |
| Stacking & StackPower | StackWise-480 Supported | StackWise-480 Supported |
| Advanced L3 (BGP/EIGRP/VRF) | Fully Supported | Not Supported |
| SD-Access (VXLAN/LISP) | Fully Supported | Not Supported |
| Micro-Segmentation (TrustSec) | Supported | Not Supported |
| Target Audience | Enterprise networks needing deep automation and complex routing. | SMBs and branches needing reliable, cost-effective Layer 2/3 access. |
Shared Technical Specifications
| Parameter | Specification (Applies to both A and E models) |
| Downlink Ports |
24 x 10/100/1000 Mbps RJ-45 PoE+ auto-sensing |
| Default Power Supply |
1 PWR-C1-715WAC-P (715W AC Platinum) |
| Available PoE Budget |
445W default (Up to 30W per port); Upgradeable to 720W |
| Switching Capacity |
208 Gbps (688 Gbps with stacking) |
| Forwarding Rate |
154.76 Mpps (511.90 Mpps with stacking) |
| MAC Address Table |
32,000 entries |
| CPU & Memory |
Multicore x86 CPU; 8 GB DRAM; 16 GB Flash |
| IPv4 / IPv6 Routes |
32,000 IPv4 / 16,000 IPv6 entries |
| Dimensions (HWD) |
1.73" x 17.5" x 17.7" (4.4 x 44.5 x 44.9 cm) with default PSU |
| Weight |
16.33 lb (7.4 kg) |
| Operating Temp |
23 F to 113 F (-5°C to 45°C) |
| MTBF |
299,000 hours |
