Overview
The Cisco Catalyst C9200L-48T-4G-A is a fixed-configuration Layer 3 access switch built for high-density, data-only enterprise environments such as SMB networks, branch offices, education campuses, financial back offices, and enterprise wiring closets.
It features 48 Gigabit Ethernet data ports and 41G SFP uplinks, delivering reliable wired connectivity without PoE overhead - making it ideal for PCs, printers, servers, and non-powered endpoints.
Powered by Cisco's UADP 2.0 Mini ASIC, the switch provides a programmable forwarding pipeline, enabling long-term investment protection and future-ready feature upgrades via Cisco IOS XE.
With the Network Advantage license, it unlocks advanced enterprise capabilities including EIGRP, IS-IS, full OSPF, VRF, VXLAN, LISP, and SGT, making it a strong choice for segmented enterprise networks and SD-Access edge deployments.
The platform supports StackWise-80, allowing up to 8 switches to operate as a single logical unit with 80 Gbps stacking bandwidth and sub-50 ms failover, ensuring high availability in mission-critical environments.
Highlights
High-Density Data Access (Non-PoE)
-
48 x 10/100/1000 RJ-45 ports
-
Optimized for wired office users, trading desks, classrooms, and lab environments
41G Flexible Uplinks
-
Fixed SFP uplinks for fiber aggregation, ISP connectivity, and campus distribution layers
Energy-Efficient & Quiet Operation
-
No PoE power overhead
-
Default PWR-C5-125WAC (125W PSU) reduces power consumption, heat, and noise
-
Ideal for SMB offices and silent network closets
StackWise-80 High Availability
-
Up to 8 switches stacked
-
80 Gbps bandwidth + sub-50 ms failover
-
Simplified management with single IP
UADP 2.0 Mini ASIC
-
Programmable pipeline
-
Future-ready L2/L3 forwarding and QoS scalability
Advanced Layer 3 (Network Advantage)
-
Routing: EIGRP, IS-IS, OSPF, RIP (⚠ no BGP support on C9200L)
-
Segmentation: VRF, VXLAN, LISP, SGT
-
Ideal for enterprise segmentation & SD-Access edge
Enterprise Security
-
AES-128 MACsec encryption
-
Secure Boot + Trust Anchor
-
802.1X, DHCP Snooping, DAI, IP Source Guard
Flexible Management
-
CLI / Web UI / SNMP / NETCONF / RESTCONF
-
Cisco Catalyst Center & Meraki Dashboard integration
Recommended Accessories
| Model | Description | Use Case |
|---|---|---|
| C9200L-STACK-KIT | Stack kit | Enable StackWise-80 |
| STACK-T4-50CM / 1M / 3M | Stacking cables | Switch stacking |
| PWR-C5-125WAC | 125W PSU | Default / spare power |
| GLC-SX-MMD | 1G SFP | Short-distance fiber uplink |
| GLC-LH-SMD | 1G SFP | Long-distance uplink |
Comparison with Similar Models
| Model | Downlinks | Uplinks | PoE | License | Best For |
|---|---|---|---|---|---|
| C9200L-48T-4G-A | 481G data | 41G | None | Advantage | Advanced L3 data networks |
| C9200L-48P-4G-A | 481G PoE+ | 41G | 740W | Advantage | AP / camera deployments |
| C9200L-48T-4X-A | 481G data | 410G | None | Advantage | High-speed aggregation |
Specifications
| Parameter | Specification | Value |
|---|---|---|
| Product Code | C9200L-48T-4G-A | Advantage SKU |
| Ports | 48 x 10/100/1000 RJ-45 | Data access |
| Uplinks | 4 x 1G SFP | Aggregation |
| Switching Capacity | 104 Gbps | Non-blocking |
| Forwarding Rate | 77.38 Mpps | Wire-speed |
| Stacking | 80 Gbps | StackWise-80 |
| DRAM / Flash | 2 GB / 4 GB | System memory |
| MAC Table | 16,000 | Network scale |
| IPv4 Routes | 11,000 | Branch routing |
| IPv6 Routes | 1,500 | Future-ready |
| ACL Entries | 1,500 | Security scale |
| NetFlow Entries | 16,000 | Monitoring |
| Jumbo Frame | 9198 bytes | Large packets |
| Power Supply | PWR-C5-125WAC | Default |
| Weight | 9.97 lb (4.53 kg) | Rack deployment |
| MTBF | 508,700 hours | High reliability |
Why Choose C9200L-48T-4G-A?
Lower Power, Lower Cost for Data-Only Networks
Perfect for environments that do not require PoE, reducing CAPEX and OPEX.
Enterprise Routing Without Compromise
Network Advantage enables advanced routing and segmentation, ideal for multi-VLAN enterprises and secure campus designs.
Reliable for Always-On Business
With 508,700 hours MTBF, it is designed for continuous operation in enterprise environments.
Ideal for Channel & Local Stocking
A high-demand, standardized SKU - perfect for resellers, system integrators, and local inventory deployment.
Cisco E-LLW Warranty
Backed by Cisco Enhanced Limited Lifetime Warranty, including hardware replacement and TAC support.
