Cisco Catalyst C9200L-48T-4G | 48-Port Gigabit Data Switch | 4 x 1G SFP Uplinks | L3 Essentials & Advantage
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco Catalyst C9200L-48T-4G | 48-Port Gigabit Data Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Overview
The Cisco Catalyst C9200L-48T-4G is a fixed-configuration Layer 3 access switch designed for high-density, data-only environments such as corporate offices, call centers, financial trading floors, education labs, and engineering networks where PoE is not required.
It provides 48 Gigabit Ethernet data ports and 41G SFP uplinks, delivering stable and scalable connectivity for desktops, servers, and enterprise endpoints, while significantly reducing power consumption, heat output, and noise levels compared to PoE-based switches.
Built on the UADP 2.0 Mini ASIC, the switch delivers 104 Gbps switching capacity and 77.38 Mpps forwarding performance, ensuring smooth traffic handling for business-critical applications, internal systems, and high-density wired workloads.
Running Cisco IOS XE, it supports StackWise-80 (80 Gbps) for scalable deployments and flexible Layer 3 routing:
-
Network Essentials: OSPF (up to 1000 routes), EIGRP Stub, RIP, static routing
-
Network Advantage: Full OSPF, EIGRP, IS-IS, plus advanced segmentation (VRF, VXLAN, LISP, SGT)
Note: BGP is not supported on C9200L series switches.
Highlights
-
48 Gigabit RJ-45 data-only ports (no PoE, optimized for wired endpoints)
-
4 1G SFP uplinks for aggregation and WAN connectivity
-
104 Gbps switching capacity, 77.38 Mpps forwarding rate
-
StackWise-80 (80 Gbps) for scalable multi-switch deployment
-
UADP 2.0 Mini ASIC with programmable forwarding pipeline
-
Advanced Layer 3 routing (OSPF, EIGRP Stub / full L3 with Advantage)
-
AES-128 MACsec encryption + Trust Anchor security
-
Low-power 125W PSU (PWR-C5-125WAC) for energy-efficient operation
-
Optimized for quiet office environments and compact wiring closets
Use Cases & Deployment Scenarios
-
Corporate Offices - high-density desktop connectivity
-
Call Centers - stable wired infrastructure for voice/data systems
-
Financial Trading Floors - low-latency, high-availability networking
-
R&D Labs / Engineering Networks - secure, data-only environments
-
Education Labs / Computer Rooms - cost-efficient wired access
-
Branch Offices (Non-PoE) - standardized deployments
-
System Integrators & Resellers - ideal for bulk inventory and fast delivery projects
Recommended Accessories
| Model | Description | Use Case |
|---|---|---|
| PWR-C5-125WAC | 125W AC PSU (default) | Standard deployment |
| PWR-C5-125WAC (Secondary) | Redundant PSU | 1+1 power redundancy |
| C9200L-STACK-KIT | Stack kit | Enable StackWise-80 |
| STACK-T4-1M | Stacking cable | Switch stacking |
| GLC-SX-MMD | 1G SFP | Short-distance fiber |
| GLC-LH-SMD | 1G SFP | Long-distance uplink |
Comparison with Similar Models
| Model | Uplinks | PoE | Performance | License | Best For |
|---|---|---|---|---|---|
| C9200L-48T-4G | 41G | None | 104 Gbps / 77.38 Mpps | Essentials / Advantage | Offices, labs, data-only |
| C9200L-48P-4G | 41G | 740W | Same hardware | Essentials / Advantage | Wi-Fi, cameras, PoE devices |
| C9200L-48T-4X | 410G | None | Higher uplink bandwidth | Essentials / Advantage | High-bandwidth aggregation |
Specifications
| Parameter | Specification | Value |
|---|---|---|
| Ports | 48 x 10/100/1000 RJ-45 | Data-only access |
| Uplinks | 4 x 1G SFP | Aggregation |
| Switching Capacity | 104 Gbps | Non-blocking |
| Forwarding Rate | 77.38 Mpps | Wire-speed |
| Stacking | 80 Gbps | StackWise-80 |
| Virtual Networks | 1 | SD-Access entry |
| MAC Table | 16,000 | Network scale |
| IPv4 Routes | 11,000 | Branch routing |
| IPv6 Routes | 1,500 | Future-ready |
| DRAM / Flash | 2 GB / 4 GB | System performance |
| Jumbo Frame | 9198 bytes | Large data transfer |
| Power Supply | PWR-C5-125WAC | 125W default PSU |
| Weight | 9.97 lb (4.53 kg) | Rack deployment |
| MTBF | 508,700 hours | High reliability |
Why Choose C9200L-48T-4G Ethernet Switch?
The C9200L-48T-4G is purpose-built for organizations that require high-density access without PoE overhead, making it a cost-effective, energy-efficient, and highly reliable solution.
Key Advantages:
-
Lower Power & Cooling Costs
Equipped with a 125W PSU, significantly reducing electricity usage compared to PoE switches - ideal for SMBs and green IT deployments -
Quiet Operation for Office Environments
Reduced heat and noise make it suitable for open offices, classrooms, and small network rooms -
High Reliability
With an MTBF of 508,700 hours, it ensures long-term stability for mission-critical wired infrastructure -
Flexible Licensing Options
Choose Essentials for basic routing or Advantage for advanced Layer 3 and segmentation -
Perfect for Standardized Deployment
A strong SKU for multi-site rollout, enterprise standardization, and reseller stocking -
Backed by Cisco Enhanced Limited Lifetime Warranty (E-LLW)
Ideal for data-only enterprise networks prioritizing efficiency, scalability, and reliability
More Details
Quality Certifications
Warranty
100% Low Price Guarantee
Network-switch.com provides high-quality products at low wholesale prices
100% Quality Assurance
All items are ORIGINAL and GENUINE only.
Item conditions are "New Sealed". They are fully tested by CCIE Engineers.
Free Technical Support
Our FREE Expert Consultancy Support is over the phone, by chat, by email or by login remotely.
100% Money Back Guarantee
You can contact our customer service team to exchange or return any product that you bought from us.
Flexible Secure Payment & Shipment
Verified authorization: Mcafee Secure, VeriSign Secured
Return Material Authorization (RMA) Process
Standard Warranty Policy
Original New Sealed Enterprise Hardware: 3 Years
Original New Sealed Consumer Devices: 1 Year
The Support Contacts
If your Cisco products failed, you must contact your sales representative to verify product failure. If the problem still can't correct by remote support methods i.e. email or phone support, the RMA procedure will issue.
