Cisco Catalyst C9200L-48PXG-2Y | 48-Port PoE+ mGig Switch | 2 x 25G SFP28 Uplinks | Essentials & Advantage
- Compra 100% segura
- Produtos originais com garantia
- Emitimos NFe • Faturamos a prazo p/ empresas
- Impostos inclusos • até 12x sem juros
- Site seguro · SSL
Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil e faturamos a prazo para empresas, com impostos inclusos. Emitimos NFe (nota fiscal eletrônica) e parcelamos em até 12x sem juros no cartão. Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.
- Cisco Catalyst C9200L-48PXG-2Y | 48-Port PoE+ mGig Switch
- Informações e formas de pagamento
- Estabelecemos parcerias com revendas
Overview
The Cisco Catalyst C9200L-48PXG-2Y is a high-density multigigabit PoE+ access switch purpose-built for Wi-Fi 6/6E deployments, enterprise campus networks, smart buildings, and large-scale branch environments.
It features 48 PoE+ access ports, including 8 multigigabit ports (100M/1G/2.5G/5G/10G) and 40 Gigabit Ethernet ports, enabling full performance for high-throughput wireless access points, video surveillance systems, VoIP deployments, and IoT devices.
The switch integrates 2 x 1/10/25G SFP28 uplinks (backward compatible), delivering high-speed aggregation for core connectivity, data-intensive workloads, and latency-sensitive applications.
With a default PoE budget of 740W (expandable to 1440W with dual PSUs), it is ideal for dense AP deployments, IP cameras, smart retail systems, and industrial IoT environments.
Powered by the Cisco UADP 2.0 Mini ASIC and running Cisco IOS XE, the platform supports both Network Essentials and Network Advantage licenses, enabling scalable Layer 2/Layer 3 networking, segmentation, and automation.
Highlights
-
48-Port High-Density Access (mGig + 1G)
8 x mGig (100M-10G) + 40 x 1G PoE+ ports for wireless-first enterprises and high-density endpoint environments -
2 x 25G Uplinks (1/10/25G Compatible)
Future-proof aggregation for campus core, data distribution, and edge computing -
Enterprise Performance (340 Gbps / 252.97 Mpps)
Non-blocking architecture ensures wire-speed forwarding for high-bandwidth applications -
Scalable PoE+ Power (Up to 1440W)
740W default, expandable to 1440W - ideal for Wi-Fi APs, IP cameras, VoIP, and IoT -
StackWise-80 High Availability
Stack up to 8 switches with 80 Gbps bandwidth and sub-50 ms failover -
UADP 2.0 Mini ASIC
Programmable pipeline for QoS, ACL, and future-ready networking -
Advanced Security Architecture
MACsec, Secure Boot, Trust Anchor, segmentation, 802.1X, DHCP Snooping -
Automation & Cloud Management
Cisco DNA Center + Meraki Dashboard for centralized monitoring and rapid deployment
Use Cases & Deployment Scenarios
1. Wi-Fi 6 / Wi-Fi 6E High-Density Networks
-
Multigig ports unlock full AP throughput
-
Ideal for universities, hospitals, enterprise campuses
2. Enterprise Campus Access Layer
-
High port density for employees, endpoints, and collaboration devices
-
25G uplinks eliminate aggregation bottlenecks
3. Retail Chains & Distributed Branches
-
Supports POS systems, cameras, and IoT devices
-
Perfect for standardized multi-site deployments
4. Smart Buildings & IoT Infrastructure
-
Powers lighting, sensors, security systems
-
Enables automation and energy-efficient operations
5. SMB & Regional Enterprise Networks
-
Reliable, scalable architecture for growing business networks
Recommended Accessories
| Model | Description | Use Case |
|---|---|---|
| PWR-C5-1KWAC | 1000W AC PSU (default) | Standard PoE deployment |
| PWR-C5-1KWAC (Secondary) | Redundant PSU | Increase PoE to 1440W |
| C9200L-STACK-KIT | Stack kit | Enable StackWise-80 |
| STACK-T4-1M | Stacking cable | Switch stacking |
| SFP-10G-SR | 10G SFP+ | Short-distance uplink |
| SFP-25G-SR-S | 25G SFP28 | High-speed aggregation |
Comparison with Similar Models
| Model | Downlinks | Uplinks | PoE Budget | Performance | License | Best For |
|---|---|---|---|---|---|---|
| C9200L-48PXG-2Y | 8 x mGig + 40 x 1G | 2 x 25G | 740W / 1440W | 340G / 252.97 Mpps | Ess / Adv | High-density campus |
| C9200L-24PXG-2Y | 8 x mGig + 16 x 1G | 2 x 25G | 370W / 740W | 292G / 229.16 Mpps | Ess / Adv | SMB / branch |
| C9200L-48PXG-4X | 8 x mGig + 40 x 1G | 4 x 10G | Same | Lower uplink tier | Ess / Adv | 10G aggregation |
Specifications
| Parameter | Specification | Value |
|---|---|---|
| Ports | 8 x mGig + 40 x 1G PoE+ | High-density access |
| mGig Speeds | 100M / 1G / 2.5G / 5G / 10G | Wi-Fi 6/6E ready |
| Uplinks | 2 x 1/10/25G SFP28 | Core aggregation |
| Switching Capacity | 340 Gbps | Non-blocking |
| Forwarding Rate | 252.97 Mpps | Wire-speed |
| PoE Budget | 740W / 1440W | Device power |
| Stacking | 80 Gbps | Scalability |
| Virtual Networks | 1 | SD-Access limitation |
| MAC Table | 16,000 | Network scale |
| IPv4 Routes | 11,000 (8,000 direct + 3,000 indirect) | Branch routing |
| IPv6 Routes | 1,500 | Future-ready |
| DRAM / Flash | 2 GB / 4 GB | System |
| Jumbo Frame | 9198 bytes | Large data |
| Power Supply | PWR-C5-1KWAC | Default |
| Fans | Fixed redundant (not field-replaceable) | Hardware design |
| Operating Temp | -5°C to +45°C | Enterprise environment |
| Weight | 12.6 lb (5.71 kg) | Rack deployment |
| MTBF | 337,260 hours | Reliability |
Why Choose the Cisco C9200L-48PXG-2Y Switch?
-
High-Turnover SKU for Channel Partners
Ideal for local stocking, fast fulfillment, and repeat deployments -
Optimized for Wireless-First Environments
mGig + 25G uplinks eliminate Wi-Fi bottlenecks -
Flexible Licensing (Essentials vs Advantage)
Adapt to basic L3 access or full enterprise segmentation -
Enterprise Reliability & Warranty
Backed by Cisco Enhanced Limited Lifetime Warranty (E-LLW) -
Future-Proof Investment
Ready for SD-Access, automation, and telemetry evolution
