Cisco Catalyst C9200L-24PXG-2Y-A 24-Port mGig PoE+ Switch, 2x25G Uplinks, Network Advantage
Clique ou role para ampliar
Toque ou belisque para ampliar
Cisco Catalyst C9200L-24PXG-2Y-A 24-Port mGig PoE+ Switch, 2x25G Uplinks, Network Advantage
Clique ou role para ampliar
Toque ou belisque para ampliar
Cisco Catalyst C9200L-24PXG-2Y-A 24-Port mGig PoE+ Switch, 2x25G Uplinks, Network Advantage
Cisco Catalyst C9200L-24PXG-2Y-A 24-Port mGig PoE+ Switch, 2x25G Uplinks, Network Advantage

Cisco Catalyst C9200L-24PXG-2Y-A 24-Port mGig PoE+ Switch, 2x25G Uplinks, Network Advantage

por Cisco
Desconto de 43%
R$ 127.942,92
R$ 72.936,00
Frete gratis para todo o Brasil
  • Compra 100% segura
  • Produtos originais com garantia
  • Emitimos NFe • Faturamos a prazo
  • Site seguro · SSL

Compre com segurança, procedência e garantia. Fornecemos para todo o Brasil, faturamos a prazo no boleto e emitimos NFe (nota fiscal eletrônica). Despachamos ou retiramos em São Paulo, SP. Produtos originais, valores unitários. Temos experiência e suporte.

Formas de pagamento
Pix VISA elo Hiper AMEX PayPal ate 12x

[shortdesc]

Cisco C9200L-24PXG-2Y-A delivers 8× mGig PoE+ and 16× 1G PoE+ ports with 2× 25G uplinks, 370W PoE budget, StackWise-80 support, and advanced Layer 3 with Network Advantage.

[/shortdesc]

[properties]
Properties C9200L-24PXG-2Y-A
Description Catalyst 9200L 24-port 8× mGig, 16× 1G, 2× 25G, PoE+, Network Advantage
Product Family Catalyst 9200L
Product Type Ethernet Switch
Number of Ports 24
Downlinks total 10/100/1000
or PoE+ copper ports		 24 ports full PoE+ (8 mGig up to 10G, 16 × 1G)
Uplink configuration 2 × 1/10/25G SFP28 fixed uplinks
Cisco IOS Software Network Advantage
Default primary AC
power supply		 PWR-C5-600WAC
Available PoE power with
additional secondary
power supply		 740W (with 1000W PSU)
Fans Fixed redundant
Chassis + FEP +
Fan Dimensions (HxWxD) Inches		 1.73 × 17.5 × 13.8
[/properties]

[specifications]

Specifications C9200L-24PXG-2Y-A
Console Ports RJ-45-to-DB9 cable for PC connections, USB-C console, USB Type-A
DRAM 2 GB
Flash Memory 4 GB
Switching capacity 292 Gbps
Forwarding rate 229.16 Mpps
MAC addresses 16,000
Operating Temperature
Up to 5,000 ft (1500 m)		 -5°C to +45°C
Operating Temperature
Up to 10,000 ft (3000 m)		 -5°C to +40°C
Safety IEC 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950-1
EN 60950-1
AS/NZS 60950.1
Class I Equipment
Electromagnetic compatibility
certifications		 47 CFR Part 15
CISPR 32 Class A
CNS 13438
EN 300 386*
EN 55032 Class A
EN61000-3-2
EN61000-3-3
ICES-003 Class A
KN 32
TCVN 7189 Class A
V-3 Class A
CISPR 35
EN 300 386*
EN 55035
KN 35
TCVN 7317
EMC
compliance		 FCC Part 15 (CFR 47) Class A
ICES-003 Class A
EN 55032 Class A
CISPR 32 Class A
AS/NZS 3548 Class A
BSMI Class A
VCCI Class A
CISPR 35
EN 55035, EN300 386*
EN 61000-3-2, EN 61000-3-3
Safety
compliance		 UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
Environmental Reduction of Hazardous Substances (ROHS) 5

[/specifications]

[accesories]

Stacking Support StackWise-80
Stacking bandwidth support 80 Gbps
Stacking hardware C9200L-STACK-KIT
Number of
members		 8
Supported stack members Other C9200L models with same license level

C9200L-STACK-KIT Stack kit for C9200L SKUs only: Two data stack adapters and one data stack cable
STACK-T4-50CM Data stack 50 cm cable (default cable with Stack Kit)
STACK-T4-1M Data stack 1 m cable
STACK T4-3M Data stack 3 m cable

[/accesories]

[specifications] [/specifications]

  • Ports: 8 × Multigigabit PoE+ & 16 × 1G PoE+
  • Uplinks: 2 × 1/10/25G SFP28 fixed uplinks
  • Stacking: StackWise-80 with 80 Gbps bandwidth
  • PoE Budget: Up to 370W (with included 600W PSU)

The Cisco C9200L-24PXG-2Y-A is a next-generation Layer 3 managed switch built to deliver high-speed access for modern enterprise networks. Featuring 8 Multigigabit PoE+ ports, 16 standard 1G PoE+ ports, and two fixed 25G SFP28 uplinks, this model is ideal for high-performance wireless (Wi-Fi 6/6E) and endpoint aggregation.

Designed for enterprise access layers, it supports StackWise-80 technology for seamless stacking of up to 8 switches and simplifies management through Cisco IOS XE and DNA Center integration. Powered by the UADP 2.0 Mini ASIC, the switch offers consistent security, automation, and rich telemetry. This model includes the Network Advantage license, unlocking advanced routing, segmentation, and enterprise-class security capabilities.

Hardware

  • Model: C9200L-24PXG-2Y
  • Ports: 8 × mGig (up to 10G) + 16 × 1G PoE+ Ethernet ports
  • Uplinks: 2 × 1/10/25G SFP28 fixed uplinks
  • Stacking Support: StackWise-80
  • Stacking Bandwidth: 80 Gbps
  • Power Supply: 1 × 600W AC (PWR-C5-600WAC)
  • PoE Budget: Up to 370W
  • Fan Modules: Fixed
  • Physical Dimensions: 1.73 × 17.5 × 13.8 in (4.4 × 44.5 × 35.0 cm)
  • Weight: 12.0 lbs (5.44 kg)

Performance

  • Switching Capacity: 292 Gbps
  • Forwarding Rate: 229.16 Mpps
  • DRAM: 2 GB
  • Flash Memory: 4 GB
  • VLAN Support: 4094 VLANs
  • MAC Address Table Size: 16,000 entries
  • Jumbo Frame Support: Up to 9198 bytes

Software & Features

  • Operating System: Cisco IOS XE
  • License Tier: Network Advantage
  • Routing Protocols: OSPF, EIGRP, IS-IS, RIP, VRF
  • Security Features: MACsec-128, 802.1X, ACLs, Trustworthy Solutions

How many multigigabit ports does this switch support?

It includes 8 multigigabit PoE+ ports that support speeds up to 10G, plus 16 standard 1G PoE+ ports.

What uplinks are included on this model?

The switch includes 2 fixed 1/10/25G SFP28 uplink ports.

Can this switch be stacked with other C9200L models?

Yes. It supports StackWise-80 and can stack with other C9200L switches, up to 8 units in total.

What power supply is included?

This model comes with a 600W AC power supply (PWR-C5-600WAC) by default, delivering up to a 370W PoE budget.

Frete grátis. Clique em SOLICITAR COTAÇÃO PROPOSTA para enviar sua cotação e receber nossa proposta em seu email. Faturamos a prazo, desconto para pagamento à vista. Impostos inclusos, parcelamos em até 12x sem juros no cartão.

Produtos originais, garantimos a compatibilidade. Somos especialistas em TI. Atendemos e fornecemos para todo o Brasil.

Emitimos NFe, nota fiscal eletrônica. Enviamos ou retira os produtos na cidade de São Paulo, SP. Compre com segurança e procedência. Produtos com garantia, temos experiência e suporte. Somos especialistas em TI.

Por favor clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Estabelecemos parcerias com revendas. Somos distribuidores e temos preços diferenciados. Fornecemos para revendas de todo o Brasil.

Oferecemos opcionalmente o faturamos direto para seu cliente com fidelização para sua empresa (vendas e atendimento exclusivo seu) e com comissionamento (pagamos comissão pela intermediação) para a revenda.

Clique em Solicitar proposta. Desta forma receberá a proposta em seu email.

Descrição, características do produto

[shortdesc]

Cisco C9200L-24PXG-2Y-A delivers 8× mGig PoE+ and 16× 1G PoE+ ports with 2× 25G uplinks, 370W PoE budget, StackWise-80 support, and advanced Layer 3 with Network Advantage.

[/shortdesc]

[properties]
Properties C9200L-24PXG-2Y-A
Description Catalyst 9200L 24-port 8× mGig, 16× 1G, 2× 25G, PoE+, Network Advantage
Product Family Catalyst 9200L
Product Type Ethernet Switch
Number of Ports 24
Downlinks total 10/100/1000
or PoE+ copper ports		 24 ports full PoE+ (8 mGig up to 10G, 16 × 1G)
Uplink configuration 2 × 1/10/25G SFP28 fixed uplinks
Cisco IOS Software Network Advantage
Default primary AC
power supply		 PWR-C5-600WAC
Available PoE power with
additional secondary
power supply		 740W (with 1000W PSU)
Fans Fixed redundant
Chassis + FEP +
Fan Dimensions (HxWxD) Inches		 1.73 × 17.5 × 13.8
[/properties]

[specifications]

Specifications C9200L-24PXG-2Y-A
Console Ports RJ-45-to-DB9 cable for PC connections, USB-C console, USB Type-A
DRAM 2 GB
Flash Memory 4 GB
Switching capacity 292 Gbps
Forwarding rate 229.16 Mpps
MAC addresses 16,000
Operating Temperature
Up to 5,000 ft (1500 m)		 -5°C to +45°C
Operating Temperature
Up to 10,000 ft (3000 m)		 -5°C to +40°C
Safety IEC 60950-1
UL 60950-1
CAN/CSA C22.2 No. 60950-1
EN 60950-1
AS/NZS 60950.1
Class I Equipment
Electromagnetic compatibility
certifications		 47 CFR Part 15
CISPR 32 Class A
CNS 13438
EN 300 386*
EN 55032 Class A
EN61000-3-2
EN61000-3-3
ICES-003 Class A
KN 32
TCVN 7189 Class A
V-3 Class A
CISPR 35
EN 300 386*
EN 55035
KN 35
TCVN 7317
EMC
compliance		 FCC Part 15 (CFR 47) Class A
ICES-003 Class A
EN 55032 Class A
CISPR 32 Class A
AS/NZS 3548 Class A
BSMI Class A
VCCI Class A
CISPR 35
EN 55035, EN300 386*
EN 61000-3-2, EN 61000-3-3
Safety
compliance		 UL 60950-1, CAN/CSA-C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, CCC, CE Marking
Environmental Reduction of Hazardous Substances (ROHS) 5

[/specifications]

[accesories]

Stacking Support StackWise-80
Stacking bandwidth support 80 Gbps
Stacking hardware C9200L-STACK-KIT
Number of
members		 8
Supported stack members Other C9200L models with same license level

C9200L-STACK-KIT Stack kit for C9200L SKUs only: Two data stack adapters and one data stack cable
STACK-T4-50CM Data stack 50 cm cable (default cable with Stack Kit)
STACK-T4-1M Data stack 1 m cable
STACK T4-3M Data stack 3 m cable

[/accesories]

[specifications] [/specifications]

At a Glance
  • Ports: 8 × Multigigabit PoE+ & 16 × 1G PoE+
  • Uplinks: 2 × 1/10/25G SFP28 fixed uplinks
  • Stacking: StackWise-80 with 80 Gbps bandwidth
  • PoE Budget: Up to 370W (with included 600W PSU)
Product Overview

The Cisco C9200L-24PXG-2Y-A is a next-generation Layer 3 managed switch built to deliver high-speed access for modern enterprise networks. Featuring 8 Multigigabit PoE+ ports, 16 standard 1G PoE+ ports, and two fixed 25G SFP28 uplinks, this model is ideal for high-performance wireless (Wi-Fi 6/6E) and endpoint aggregation.

Designed for enterprise access layers, it supports StackWise-80 technology for seamless stacking of up to 8 switches and simplifies management through Cisco IOS XE and DNA Center integration. Powered by the UADP 2.0 Mini ASIC, the switch offers consistent security, automation, and rich telemetry. This model includes the Network Advantage license, unlocking advanced routing, segmentation, and enterprise-class security capabilities.

Technical Specifications

Hardware

  • Model: C9200L-24PXG-2Y
  • Ports: 8 × mGig (up to 10G) + 16 × 1G PoE+ Ethernet ports
  • Uplinks: 2 × 1/10/25G SFP28 fixed uplinks
  • Stacking Support: StackWise-80
  • Stacking Bandwidth: 80 Gbps
  • Power Supply: 1 × 600W AC (PWR-C5-600WAC)
  • PoE Budget: Up to 370W
  • Fan Modules: Fixed
  • Physical Dimensions: 1.73 × 17.5 × 13.8 in (4.4 × 44.5 × 35.0 cm)
  • Weight: 12.0 lbs (5.44 kg)

Performance

  • Switching Capacity: 292 Gbps
  • Forwarding Rate: 229.16 Mpps
  • DRAM: 2 GB
  • Flash Memory: 4 GB
  • VLAN Support: 4094 VLANs
  • MAC Address Table Size: 16,000 entries
  • Jumbo Frame Support: Up to 9198 bytes

Software & Features

  • Operating System: Cisco IOS XE
  • License Tier: Network Advantage
  • Routing Protocols: OSPF, EIGRP, IS-IS, RIP, VRF
  • Security Features: MACsec-128, 802.1X, ACLs, Trustworthy Solutions
Frequently Asked Questions

How many multigigabit ports does this switch support?

It includes 8 multigigabit PoE+ ports that support speeds up to 10G, plus 16 standard 1G PoE+ ports.

What uplinks are included on this model?

The switch includes 2 fixed 1/10/25G SFP28 uplink ports.

Can this switch be stacked with other C9200L models?

Yes. It supports StackWise-80 and can stack with other C9200L switches, up to 8 units in total.

What power supply is included?

This model comes with a 600W AC power supply (PWR-C5-600WAC) by default, delivering up to a 370W PoE budget.
